Apr. 2009
6
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[LOGIC UNIT]
[MAIN UNIT]
REF PARTS
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
REF PARTS
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
EP1006 6910014690 S.BEA MPZ1608S221A-T T 160.6/26.1
EP1007 6910014690 S.BEA MPZ1608S221A-T T 163.1/26.1
EP1008 6910014690 S.BEA MPZ1608S221A-T T 179.1/29.9
EP1009 6910014690 S.BEA MPZ1608S221A-T T 185.1/26.1
IC1201 1110003870 S.IC NJM2058M-TE1-#ZZZB B 43.2/129.3
IC1301 1110003870 S.IC NJM2058M-TE1-#ZZZB B 18.8/131.1
IC1401 1130011530 S.IC CD74HC4094M96 B 54.9/96.2
IC1402 1130011530 S.IC CD74HC4094M96 B 54.9/108.1
IC1403 1130012000 S.IC M62352AGP C60Q T 58.6/95
IC1404 1120002830 S.IC NJM2125F-TE1-#FZZB T 168.4/132.6
IC2001 1110003870 S.IC NJM2058M-TE1-#ZZZB B 174.6/75.2
IC2101 1190002261 S.IC USB2502-AEZG T 162.7/34.5
IC2102 1130013010 S.IC SN74AHC1G08DCK3 T 162.3/40.3
IC2103 1180003480 S.REG NJU7772F33-TE1-#ZZZB T 176/33.9
IC2104 1180003480 S.REG NJU7772F33-TE1-#ZZZB T 176.4/27.9
IC2121 1190002730 S.IC CP2102-GMR <MAC> T 177.2/41.5
IC2131 1130007021 S.IC TC7S66FU(TE85L,F) T 174.4/58.6
IC2132 1190002240 S.IC PCM2901E/2K T 160.5/53.1
IC2201 1130005252 S.IC TC74HC08AF(EL,F) B 182/47.7
IC2202 1130005721 S.IC TC7W04F(TE12L,F) B 184.1/39.6
IC2301 1110003870 S.IC NJM2058M-TE1-#ZZZB B 97.7/18.9
IC2312 1110003091 IC LA4425A-E
IC2331 1110006300 S.IC NJM2172V-TE1-#ZZZB T 92.6/10.2
IC2362 1120002830 S.IC NJM2125F-TE1-#FZZB T 100.6/19.3
IC2601 1110006300 S.IC NJM2172V-TE1-#ZZZB T 11.6/63.4
IC3001 1130012900 S.IC TC74LCX00FT (EL) T 144.2/38.8
IC3002 1130013110 S.IC KIC7W53FK-RTK/P T 89/22.1
IC3201 1110007390 S.IC NJM2114M-TE1-#ZZZB B 124/41.4
IC3202 1110006190 S.IC NJM074M-TE1-#ZZZB B 124/51.6
IC3203 1110007390 S.IC NJM2114M-TE1-#ZZZB B 124/61.2
IC3301 1110005100 S.IC NJM072BM-TE1-#ZZZB B 129.8/30.7
IC3303 1110007390 S.IC NJM2114M-TE1-#ZZZB B 121.2/30.7
IC3401 1110007390 S.IC NJM2114M-TE1-#ZZZB B 104.1/35.1
IC3402 1110005461 S.IC TA4107F(TE12L,F) T 108.3/48.8
IC3501 1130013110 S.IC KIC7W53FK-RTK/P T 107.8/59.6
IC3502 1130013110 S.IC KIC7W53FK-RTK/P T 109.4/76.3
IC3651 1180003210 S.REG NJM2831F10 T 167.8/80.1
IC3715 1110006420 S.IC UPC2708TB-E3-A T 144/101.5
IC4001 1110007390 S.IC NJM2114M-TE1-#ZZZB B 79.3/21.6
IC4002 1110007390 S.IC NJM2114M-TE1-#ZZZB B 79.2/12.2
IC4003 1180003490 S.REG NJM2871BF04-TE1-#ZZZB T 63.8/9.1
IC4004 1190002920 S.IC PCM4220PFB T 65.9/19.5
IC4005 1130013440 S.IC SN74LVC2G74DCTR T 58.4/12.9
IC4101 1130005971 S.IC TC74HC4053AF(F) S B 90.8/71.4
IC4201 1110007390 S.IC NJM2114M-TE1-#ZZZB B 78.3/52.8
IC4202 1110007390 S.IC NJM2114M-TE1-#ZZZB B 71.1/44.9
IC4204 1110007390 S.IC NJM2114M-TE1-#ZZZB B 80/44.9
IC4205 1110001901 S.IC UPC4570G2-E1-A B 79.4/73.4
IC4301 1190002650 S.IC AK4620BVFP-E2/P T 67.3/37.7
IC4302 1110004770 S.IC BU9480F-E2 B 78.1/62.7
IC4401 1110007390 S.IC NJM2114M-TE1-#ZZZB B 79.3/31.5
IC4402 1110003870 S.IC NJM2058M-TE1-#ZZZB B 91.2/59.9
IC4501 1130015150 S.IC CY22381FXC(SX-3073G) B 66.4/89.1
IC4502 1130011930 S.IC SN74LVC1G04DCKR T 67.3/86.7
IC5001 1140014800 S.IC TMS320C6726BRFP266 T 41.5/23.4
IC5002 1130015210 S.IC EN29LV040A-70SCP(SX-3073C) T 17.4/23.1
IC5101 1140014320 S.IC TMS320C6720BRFP200 T 50.8/62.9
IC5102 1130015220 S.IC EN29LV040A-70SCP(SX-3073D) T 26.7/62.7
IC6001 1120002830 S.IC NJM2125F-TE1-#FZZB T 151.2/113.4
IC6002 1180000720 S.IC AN79L05M-(E1) B 110.4/90.9
IC6003 1190002880 S.IC AD9834CRUZ-REEL7 <FE> T 80.6/128
IC6004 1190002890 S.IC ADF4360-8BCPZRL7 <FE> T 79.7/106
IC6005 1110006131 S.IC UPC4094G2-E1-A B 104.6/81
IC6006 1110006131 S.IC UPC4094G2-E1-A B 96.1/81
IC6007 1190002900 S.IC ADS7886SDCKR T 84/76
IC6008 1130013440 S.IC SN74LVC2G74DCTR T 92.3/107.7
IC6009 1110006131 S.IC UPC4094G2-E1-A B 88.7/81
IC6010 1130011930 S.IC SN74LVC1G04DCKR T 71.5/106.9
IC6020 1130011930 S.IC SN74LVC1G04DCKR T 92.3/112.3
Q1101 1540000550 S.TRA 2SD1664 T100Q B 4.6/92.4
Q1102 1530003900 S.TRA KTC4075 BL-RTK/P T 7.9/96.5
Q1103 1540000550 S.TRA 2SD1664 T100Q B 4.6/99.1
Q1111 1540000550 S.TRA 2SD1664 T100Q B 4.6/106.7
Q1112 1530003900 S.TRA KTC4075 BL-RTK/P T 7.9/104.1
Q1201 1560001260 S.FET 2SK3018 T106 T 42.9/125.7
Q1202 1590003780 S.TRA KRA304E-RTK/P T 45.2/126
Q1241 1590003770 S.TRA KRA302E-RTK/P T 36.3/123
Q1242 1530003960 S.TRA KTC2875-B-RTK/P T 39.1/123
Q1243 1510000510 S.TRA 2SA1576A T106R B 20.9/120.8
Q1251 1530003960 S.TRA KTC2875-B-RTK/P T 43.3/119.7
Q1252 1590003770 S.TRA KRA302E-RTK/P T 47.5/119.1
Q1253 1590003790 S.TRA KRC404E RTK/P T 59/120.2
Q1254 1560001260 S.FET 2SK3018 T106 T 59.1/110.5
Q1255 1530003900 S.TRA KTC4075 BL-RTK/P T 56.1/110.6
Q1256 1590003680 S.TRA KRC402 RTK/P T 59.3/126.5
Q1257 1590003680 S.TRA KRC402 RTK/P T 59.3/135.6
Q1401 1530003900 S.TRA KTC4075 BL-RTK/P T 57.2/101.7
Q2001 1590003680 S.TRA KRC402 RTK/P T 166.9/145.3
Q2031 1530003900 S.TRA KTC4075 BL-RTK/P T 172.1/148.3
Q2041 1540000451 S.TRA 2SD1623T-TD-E B 187.3/146
Q2042 1530003900 S.TRA KTC4075 BL-RTK/P T179.8/145.3
Q2043 1590003770 S.TRA KRA302E-RTK/P T 184.7/148
Q2051 1530003900 S.TRA KTC4075 BL-RTK/P T 162.6/145.3
S.=Surface mount
[MAIN UNIT]
REF PARTS
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
Q2101 1590003770 S.TRA KRA302E-RTK/P T 159.4/41.8
Q2102 1590003680 S.TRA KRC402 RTK/P T 159.6/39.5
Q2201 1590001650 S.TRA XP4601(TX) T 189.8/40.3
Q2301 1590003680 S.TRA KRC402 RTK/P T 145.7/5.2
Q2302 1590003680 S.TRA KRC402 RTK/P T 139.6/5.2
Q2311 1540000471 S.TRA 2SD1801S-TL-E B 132.5/9.5
Q2312 1560001330 S.FET RSR025N03 T 109.1/16
Q2361 1550000010 S.FET 2SJ364-Q (TX) T 101.5/26.6
Q3001 1530002601 S.TRA 2SC4215-O(TE85R,F) B 145.3/32.9
Q3201 1530003450 S.TRA 2SC4835-R(TX) T 120.3/74.8
Q3202 1530003450 S.TRA 2SC4835-R(TX) T 126.8/74.8
Q3501 1580000751 S.FET 3SK294(TE85L,F) T 108.6/55.6
Q3502 1590003680 S.TRA KRC402 RTK/P T 99.9/60.5
Q3504 1560000561 S.FET 2SK882-GR(TE85L,F) B 114.1/85.7
Q3601 1530003021 S.TRA 2SC4402-3-TL-E B 152.7/82.8
Q3602 1530003021 S.TRA 2SC4402-3-TL-E B 159.2/81
Q3603 1530003842 S.TRA 2SC5501A-4-TR-E T 162.4/86.6
Q6003 1530003900 S.TRA KTC4075 BL-RTK/P T 150.3/119
Q6004 1530003240 S.TRA 2SC4536 QS-T1 T 134/110.5
Q6005 1560000561 S.FET 2SK882-GR(TE85L,F) B 110.5/100.4
Q6006 1530003340 S.TRA 2SC3357-T1 RF T 96.2/132.1
Q6007 1560000561 S.FET 2SK882-GR(TE85L,F) T 114.8/104.4
Q6008 1590003680 S.TRA KRC402 RTK/P T 85.5/107.4
D1001 1790000661 S.DIO MA2J7280GL(TX) B 27.6/104.3
D1002 1790000661 S.DIO MA2J7280GL(TX) B 30.1/104.3
D1101 1750001180 S.DIO KDS122 RTK/P T 7.9/100.3
D1111 1750001180 S.DIO KDS122 RTK/P T 7.9/107.9
D1201 1730002341 S.ZEN MAZ8047GML T 44.5/128.3
D1202 1750001320 S.DIO KDS4148U RTK/P T 47.2/123.3
D1203 1750001320 S.DIO KDS4148U RTK/P B 39.2/122.8
D1204 1750001320 S.DIO KDS4148U RTK/P B 39.2/135.2
D1205 1750001320 S.DIO KDS4148U RTK/P T 36.3/127
D1206 1750001320 S.DIO KDS4148U RTK/P T 36.8/130.1
D1251 1790000661 S.DIO MA2J7280GL(TX) B 44.6/122.8
D1252 1750001320 S.DIO KDS4148U RTK/P T 57.4/112.8
D1302 1750001320 S.DIO KDS4148U RTK/P B 12.2/138.6
D1303 1750001320 S.DIO KDS4148U RTK/P B 23.5/136.6
D1304 1750001320 S.DIO KDS4148U RTK/P B 27.3/126.7
D1401 1750001320 S.DIO KDS4148U RTK/P B 65.2/101.4
D1406 1750001320 S.DIO KDS4148U RTK/P B 17/88
D1407 1750001320 S.DIO KDS4148U RTK/P B 19/88
D1408 1750001320 S.DIO KDS4148U RTK/P B 21/88
D2031 1750001320 S.DIO KDS4148U RTK/P T 172.1/145.1
D2041 1750001320 S.DIO KDS4148U RTK/P T 183.5/145.1
D2101 1790000980 S.DIO MA742(TX) T 169.5/29.6
D2102 1790000980 S.DIO MA742(TX) T 172/29.6
D2131 1750001180 S.DIO KDS122 RTK/P T 171.8/61.5
D2201 1750001320 S.DIO KDS4148U RTK/P T 192.3/37
D2301 1750001320 S.DIO KDS4148U RTK/P B 147.2/6.9
D2302 1750001320 S.DIO KDS4148U RTK/P B 141.1/6.9
D2361 1750001320 S.DIO KDS4148U RTK/P T 101.3/24.5
D3201 1750000431 S.DIO HSB88WSTR-E T 145.5/63
D3202 1750000431 S.DIO HSB88WSTR-E T 137.7/66.1
D3301 1750001320 S.DIO KDS4148U RTK/P B 126.2/33.1
D3302 1750001320 S.DIO KDS4148U RTK/P B 126.2/28.3
D3701 1750000581 S.DIO 1SV307(TPH3,F) B 155.8/93.6
D3702 1750000581 S.DIO 1SV307(TPH3,F) B 148.5/94.8
D3703 1750000431 S.DIO HSB88WSTR-E T 135.1/91
D4001 1750001320 S.DIO KDS4148U RTK/P T 78.6/22.5
D4002 1750001320 S.DIO KDS4148U RTK/P T 78.6/20.7
D4101 1790001041 S.ZEN MAZ8033GLL B 84.1/77.7
D4102 1790001041 S.ZEN MAZ8033GLL B 97.8/69.9
D6001 1750000971 S.DIO CPH5513-TL-E T 162.4/116.5
D6002 1750000441 S.DIO 1SV263-TL-E B 161/120.2
D6003 1750000971 S.DIO CPH5513-TL-E T 160.5/122.8
D6004 1750000431 S.DIO HSB88WSTR-E T 93.4/92.5
D6005 1750000431 S.DIO HSB88WSTR-E T 118.6/127.1
FI3501 2020001070 CER
CFWLA455KDFA-B0 (CFWS455D)
FI3502 2020001510 CER CFWLA455KJFA-B0 (CFWS455IT)
FI5001 2040000790 S.LC EXCCET103U T 37.6/41.4
FI5101 2040000790 S.LC EXCCET103U T 41.1/81
FI6001 2030000290 S.MON DSF753SBF 45 MHz (FL-357) T 111.9/111
X2101 6050012780 S.XTA CR-871 DSX321G 24 MHz T 160.3/25.2
X2131 6050012770 S.XTA CR-870 DSX321G 12 MHz T 164.4/60.8
L1501 6190002000 S.COI SLF12575T-330M3R2-PF T 163.1/13.9
L1901 6200003241 S.COI NLV32T-221J T 145.2/141.7
L1902 6200003241 S.COI NLV32T-221J T 145.2/138.7
L2001 6200002041 S.COI NLV25T-101J T 178/138.7
L2002 6200002041 S.COI NLV25T-101J T 178/135.6
L2003 6200002041 S.COI NLV25T-101J T 178/129.4
L2004 6200002041 S.COI NLV25T-101J T 178/132.5
L2005 6200002041 S.COI NLV25T-101J T 178/126.3
L2006 6200002041 S.COI NLV25T-101J T 178/118
L2007 6200002041 S.COI NLV25T-101J T 178/114.9
L2311 6180003640 COI SZW1012T-142-0.3
L2331 6200002041 S.COI NLV25T-101J B 87.9/10.6
L2501 6200002041 S.COI NLV25T-101J B 179.7/94.9
L2601 6200002041 S.COI NLV25T-101J T 17.1/68.5
L3001 6200001831 S.COI NLV32T-100J B 139.7/37.3
L3002 6200001831 S.COI NLV32T-100J B 139.7/40.3
L3003 6200002520 S.COI ELJNC R18K-F T 147.7/43.3
L3201 6200003520 S.COI ELJFB 102K-F T 125.7/68.9
L3202 6140002810 S.COI LR-317 T 145.5/69
L3203 6140002810 S.COI LR-317 T 145.5/57
L3204 6140002810 S.COI LR-317 T 137.7/60.1
L3205 6140002810 S.COI LR-317 T 137.7/72.1
