M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT]
REF PARTS
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
EP1608 6910015970 S.BEA MMZ1608B 301CT-AS T 3.7/126
EP1609 6910012350 S.BEA MMZ1608Y 102BT T 12.5/125.3
EP1610 6910012350 S.BEA MMZ1608Y 102BT T 12.5/124
EP1611 6910012350 S.BEA MMZ1608Y 102BT T 15.2/122.9
EP1612 6910014690 S.BEA MPZ1608S221A-T T 12.5/121
EP1613 6910014690 S.BEA MPZ1608S221A-T T 12.5/119.3
EP1614 6910014690 S.BEA MPZ1608S221A-T T 12.5/118
EP1615 6910014690 S.BEA MPZ1608S221A-T T 3.7/116
EP1616 6910014690 S.BEA MPZ1608S221A-T T 3.7/114.8
EP1617 6910014640 S.BEA MPZ2012S221A-T T 4/110.5
EP1618 6910014690 S.BEA MPZ1608S221A-T T 3.7/124.7
EP1701 6910014690 S.BEA MPZ1608S221A-T T 130/139.9
EP1702 6910012350 S.BEA MMZ1608Y 102BT T 128.7/139.9
EP1703 6910012350 S.BEA MMZ1608Y 102BT T 127.4/139.9
EP1704 6910014690 S.BEA MPZ1608S221A-T T 126.1/139.9
EP1705 6910012350 S.BEA MMZ1608Y 102BT T 124.8/139.9
EP1706 6910012350 S.BEA MMZ1608Y 102BT T 122.4/139.9
EP1707 6910014690 S.BEA MPZ1608S221A-T T 121.1/139.9
EP1708 6910014690 S.BEA MPZ1608S221A-T T 119.8/139.9
EP1709 6910014690 S.BEA MPZ1608S221A-T T 118.5/139.9
EP1710 6910014640 S.BEA MPZ2012S221A-T T 115.8/139.9
EP1801 6910014690 S.BEA MPZ1608S221A-T T 41.7/142.5
EP1802 6910014690 S.BEA MPZ1608S221A-T T 43/142.5
EP1803 6910014690 S.BEA MPZ1608S221A-T T 44.3/142.5
EP1804 6910014690 S.BEA MPZ1608S221A-T T 47/142.5
EP1805 6910014690 S.BEA MPZ1608S221A-T T 48.3/142.5
EP1901 6910018930 S.BEA MPZ2012S601A T 154.6/143
EP1902 6910018930 S.BEA MPZ2012S601A T 158.2/143.1
EP2001 6910014690 S.BEA MPZ1608S221A-T T 178.8/121.5
EP2002 6910014690 S.BEA MPZ1608S221A-T T 178.8/124.1
EP2003 6910014690 S.BEA MPZ1608S221A-T T 174.5/112.8
EP2004 6910014690 S.BEA MPZ1608S221A-T T 178.8/120.2
EP2031 6910014690 S.BEA MPZ1608S221A-T T 181.8/144.8
EP2101 6910012350 S.BEA MMZ1608Y 102BT B 192.2/62.7
EP2102 6910012350 S.BEA MMZ1608Y 102BT B 183.7/62.7
EP2103 6910012350 S.BEA MMZ1608Y 102BT T 175.3/30.3
EP2104 6910012350 S.BEA MMZ1608Y 102BT T 172.7/26.3
EP2121 6910012350 S.BEA MMZ1608Y 102BT T 173.8/36.1
EP2131 6910012350 S.BEA MMZ1608Y 102BT T 158/58.7
EP2132 6910012350 S.BEA MMZ1608Y 102BT T 158/60.4
EP2201 6910012350 S.BEA MMZ1608Y 102BT T 195.2/37
EP2301 6910014730 S.BEA MPZ2012S331A-T B 188.7/11.5
EP2302 6910014730 S.BEA MPZ2012S331A-T B 183/19.2
EP2303 6910014730 S.BEA MPZ2012S331A-T B 186.4/17
EP2304 6910014730 S.BEA MPZ2012S331A-T B 196.1/20
EP2401 6910015970 S.BEA MMZ1608B 301CT-AS B 193.5/79.5
EP2402 6910015970 S.BEA MMZ1608B 301CT-AS B 197.2/79.6
EP3001 6910012350 S.BEA MMZ1608Y 102BT B 136.9/38.8
EP3601 6910012350 S.BEA MMZ1608Y 102BT B 135.5/27.8
EP3602 6910012350 S.BEA MMZ1608Y 102BT B 132.5/25.6
EP3715 6910015970 S.BEA MMZ1608B 301CT-AS T 140.1/99
EP4101 6910014730 S.BEA MPZ2012S331A-T B 2.3/79.1
EP5001 6910014690 S.BEA MPZ1608S221A-T T 29.5/36.8
EP5101 6910014690 S.BEA MPZ1608S221A-T T 38.9/76.6
EP6001 6910015970 S.BEA MMZ1608B 301CT-AS T 146.8/110.7
S.=Surface mount
[PLL UNIT]
REF PARTS
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
IC1 1180000421 S.IC TA78L05F(TE12R,F) B 94.4/59.7
IC2 1130009691 S.IC TC74HCT7007AF(F) S T 133.6/64.3
IC3 1130011530 S.IC CD74HC4094M96 T 122.4/64.6
IC4 1130011530 S.IC CD74HC4094M96 T 133/75.2
IC101 1190002101 S.IC AD9951YSVZ <FE> T 110.6/100.7
IC102 1130010560 S.IC SN74AHC244PWR T 126.1/95.9
IC103 1180003190 S.REG UPD120N33TA-E1-A T 115.7/86.4
IC104 1180003200 S.REG UPD120N18TA-E1-A T 115.8/91.4
IC192 1130013010 S.IC SN74AHC1G08DCK3 T 77.6/36.8
IC320 1110007400 S.IC BGA616 T 43.3/67.2
IC381 1130013270 S.IC ADF4116BRUZ <FE> T 70/70.3
IC401 1130013010 S.IC SN74AHC1G08DCK3 T 114/3.1
IC402 1130003831 S.IC TC7S04F(TE85R,F) T 90.5/9.5
IC403 1140007881 S.IC
TC190G08EFG0046JDZ/SC1246A
T 104.1/13.6
IC405 1130013010 S.IC SN74AHC1G08DCK3 T 75.2/53.2
IC620 1110007400 S.IC BGA616 T 38.4/47.5
IC681 1130013270 S.IC ADF4116BRUZ <FE> T 29.3/39.8
IC701 1140014960 S.IC TC190G02EFG-0058/SC1287A T 130.6/15.3
Q1 1590003680 S.TRA KRC402 RTK/P T 138.4/75.4
Q51 1530003890 S.TRA KTC3880S Y-RTK/P T 101.5/41.6
Q61 1530004011 S.TRA KTC3770U-C-RTK/P T 109.9/41.5
Q71 1530003890 S.TRA KTC3880S Y-RTK/P T 109.5/51.1
Q87 1530003890 S.TRA KTC3880S Y-RTK/P T 133.1/87.2
Q121 1590003770 S.TRA KRA302E-RTK/P T 85.8/93.8
Q122 1590003680 S.TRA KRC402 RTK/P B 87.2/92.2
Q123 1590003770 S.TRA KRA302E-RTK/P T 85.2/96.3
Q124 1590003680 S.TRA KRC402 RTK/P B 87.6/95.2
Q125 1590003770 S.TRA KRA302E-RTK/P T 85.8/91.1
Q126 1590003680 S.TRA KRC402 RTK/P B 86.9/89.2
Q127 1590003770 S.TRA KRA302E-RTK/P T 86/99
Q128 1590003680 S.TRA KRC402 RTK/P B 87.9/98.2
Q151 1530003900 S.TRA KTC4075 BL-RTK/P T 82.7/70.2
Q152 1530003340 S.TRA 2SC3357-T1 RF B 117.3/106.5
Q181 1530003900 S.TRA KTC4075 BL-RTK/P T 53.9/78.1
Q201 1560000491 S.FET 2SK508-T2B-A K52 T 74.1/96.5
Q202 1530003960 S.TRA KTC2875-B-RTK/P T 73.6/102.5
Q221 1560000491 S.FET 2SK508-T2B-A K52 T 57.2/96.5
Q222 1530003960 S.TRA KTC2875-B-RTK/P T 56.8/102.5
Q251 1560000491 S.FET 2SK508-T2B-A K52 T 40.1/96.5
Q252 1530003960 S.TRA KTC2875-B-RTK/P T 40/102.5
Q271 1560000491 S.FET 2SK508-T2B-A K52 T 23.1/96.5
Q272 1530003960 S.TRA KTC2875-B-RTK/P T 23.1/102.5
Q301 1530004011 S.TRA KTC3770U-C-RTK/P T 33.2/76
Q361 1590003680 S.TRA KRC402 RTK/P B 20.9/77.3
Q402 1530003900 S.TRA KTC4075 BL-RTK/P T 93.2/20.9
Q403 1530003900 S.TRA KTC4075 BL-RTK/P T 115.6/12.5
Q404 1590003770 S.TRA KRA302E-RTK/P T 94.1/4.8
Q421 1590003770 S.TRA KRA302E-RTK/P T 81.3/9.9
Q422 1590003680 S.TRA KRC402 RTK/P T 83.1/12.4
Q423 1590003770 S.TRA KRA302E-RTK/P T 81.3/7.4
Q424 1590003680 S.TRA KRC402 RTK/P T 82.7/5
Q425 1590003770 S.TRA KRA302E-RTK/P T 81.7/14.3
Q426 1590003680 S.TRA KRC402 RTK/P T 83.1/16.6
Q427 1590003770 S.TRA KRA302E-RTK/P T 81.3/18.6
Q428 1590003680 S.TRA KRC402 RTK/P T 83.1/20.8
Q451 1560000331 S.FET 2SK210-GR(TE85R,F) T 61/44
Q452 1530003900 S.TRA KTC4075 BL-RTK/P T 61.9/34.8
Q481 1530003900 S.TRA KTC4075 BL-RTK/P T 22.8/34.1
Q501 1560000491 S.FET 2SK508-T2B-A K52 T 30.8/13.4
Q502 1530003960 S.TRA KTC2875-B-RTK/P T 31.2/7.5
Q521 1560000491 S.FET 2SK508-T2B-A K52 T 14/13.5
Q522 1530003960 S.TRA KTC2875-B-RTK/P T 14.3/7.5
Q551 1560000491 S.FET 2SK508-T2B-A K52 T 47.6/13.4
Q552 1530003960 S.TRA KTC2875-B-RTK/P T 47.9/7.5
Q571 1560000491 S.FET 2SK508-T2B-A K52 T 64.5/13.5
Q572 1530003960 S.TRA KTC2875-B-RTK/P T 64.7/7.5
Q601 1530004011 S.TRA KTC3770U-C-RTK/P T 41/37
Q661 1590003680 S.TRA KRC402 RTK/P B 5.1/27.9
Q681 1590003770 S.TRA KRA302E-RTK/P T 67.8/51.5
Q701 1530003900 S.TRA KTC4075 BL-RTK/P B 123.9/12.4
Q702 1530003900 S.TRA KTC4075 BL-RTK/P T 141.9/19.2
Q801 1530003890 S.TRA KTC3880S Y-RTK/P T 127.9/46.7
Q831 1560000561 S.FET 2SK882-GR(TE85L,F) T 149.4/37.4
Q851 1590003680 S.TRA KRC402 RTK/P T 138/52.1
Q852 1590003770 S.TRA KRA302E-RTK/P T 137.8/49.8
Q853 1590003680 S.TRA KRC402 RTK/P B 109.5/55.3
Q854 1590003770 S.TRA KRA302E-RTK/P T 106.6/54.7
Q1502 1590003680 S.TRA KRC402 RTK/P T 73/63.6
Q1521 1590003680 S.TRA KRC402 RTK/P B 21.5/62.4
Q1522 1590003770 S.TRA KRA302E-RTK/P T 21.2/64.1
Q2501 1590003680 S.TRA KRC402 RTK/P T 85.1/50.4
Q2511 1590003680 S.TRA KRC402 RTK/P B 7.2/47.5
Q2512 1590003770 S.TRA KRA302E-RTK/P T 5.6/45.5
D81 1750000581 S.DIO 1SV307(TPH3,F) B 97/49.7
D201 1720000831 S.VAR KV1770STL-G T 74.5/88.8
D202 1720000831 S.VAR KV1770STL-G B 74.3/88.7
D221 1720000831 S.VAR KV1770STL-G T 57.5/88.7
D222 1720000831 S.VAR KV1770STL-G B 57.5/88.7
D251 1750001720 S.VAR 1SV215(TPH3,F) T 39.1/87.9
D252 1750001720 S.VAR 1SV215(TPH3,F) T 41.4/87.9
D253 1750001720 S.VAR 1SV215(TPH3,F) B 41.4/88
D254 1750001720 S.VAR 1SV215(TPH3,F) B 39.1/87.9
D271 1750001720 S.VAR 1SV215(TPH3,F) T 22.3/87.2
D272 1750001720 S.VAR 1SV215(TPH3,F) T 24.6/87.1
D273 1750001720 S.VAR 1SV215(TPH3,F) B 24.5/87.9
D274 1750001720 S.VAR 1SV215(TPH3,F) B 22.3/88
D361 1750000581 S.DIO 1SV307(TPH3,F) T 22.7/75.5
D362 1750000581 S.DIO 1SV307(TPH3,F) T 26.1/75.4
D401 1750001320 S.DIO KDS4148U RTK/P B 88.9/6.7
D451 1720000681 S.VAR 1SV262(TPH2,F) T 64.7/33.5
