Apr. 2009
19
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[PLL UNIT]
REF PARTS
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
C2222 4030008560 S.CER C1608 CH 1H 300J-T T 9.6/46.6
C2223 4030009530 S.CER C1608 CH 1H 030B-T T 10.3/44.8
C2224 4030007070 S.CER C1608 CH 1H 330J-T T 9.6/42.9
C2225 4030009520 S.CER C1608 CH 1H 020B-T T 11.4/37.3
C2226 4030007050 S.CER C1608 CH 1H 220J-T T 7/38.7
C2227 4030007100 S.CER C1608 CH 1H 560J-T T 7.9/36.6
C2228 4030011280 S.CER C1608 CH 1H 271J-T T 7.1/34.4
C2229 4030007100 S.CER C1608 CH 1H 560J-T T 8.8/34.4
C2230 4030006900 S.CER C1608 JB 1H 103K-T B 4.9/34.1
C2231 4030007010 S.CER C1608 CH 1H 100D-T T 11.5/41.3
C2232 4030006900 S.CER C1608 JB 1H 103K-T B 5.7/42.5
C2511 4030006900 S.CER C1608 JB 1H 103K-T B 9.5/47.3
C2512 4030006900 S.CER C1608 JB 1H 103K-T T 5.7/47.1
J1 6510022581 S.CON 24FMN-BMTTR-A-TBT(LF)(SN) T 147.7/71
J51 6510007020 CON TMP-J01X-V6
J81 6510007020 CON TMP-J01X-V6
J351 6510007020 CON TMP-J01X-V6
J651 6510007020 CON TMP-J01X-V6
J701 6510007020 CON TMP-J01X-V6
J831 6510007020 CON TMP-J01X-V6
J851 6510007020 CON TMP-J01X-V6
EP1 6910019900 S.BEA MPZ1608S601AT T 142.1/60.5
EP2 6910015970 S.BEA MMZ1608B 301CT-AS B 148.3/59.4
EP3 6910015970 S.BEA MMZ1608B 301CT-AS B 142.5/59
EP4 6910019900 S.BEA MPZ1608S601AT T 142.1/62.9
EP5 6910019900 S.BEA MPZ1608S601AT B 149.3/67.5
EP6 6910015970 S.BEA MMZ1608B 301CT-AS B 141.8/70.5
EP7 6910015970 S.BEA MMZ1608B 301CT-AS B 149.3/71.5
EP8 6910015970 S.BEA MMZ1608B 301CT-AS B 141.8/72.5
EP9 6910015970 S.BEA MMZ1608B 301CT-AS B 149.3/73.5
EP103 6910012350 S.BEA MMZ1608Y 102BT T 103/101.4
EP204 6910012350 S.BEA MMZ1608Y 102BT B 71.1/101.2
EP224 6910012350 S.BEA MMZ1608Y 102BT B 62.8/105.3
EP254 6910012350 S.BEA MMZ1608Y 102BT B 48.1/105.7
EP274 6910012350 S.BEA MMZ1608Y 102BT B 20.7/101.2
EP382 6910012350 S.BEA MMZ1608Y 102BT T 66/75.1
EP401 6910012350 S.BEA MMZ1608Y 102BT T 106.1/4.2
EP402 6910015970 S.BEA MMZ1608B 301CT-AS B 106.7/5.4
EP403 6910015970 S.BEA MMZ1608B 301CT-AS B 96.7/3.2
EP404 6910015970 S.BEA MMZ1608B 301CT-AS B 108.3/5.4
EP405 6910015970 S.BEA MMZ1608B 301CT-AS B 96/1.8
EP406 6910015970 S.BEA MMZ1608B 301CT-AS B 109.9/5.4
EP407 6910015970 S.BEA MMZ1608B 301CT-AS T 115.2/6.3
EP504 6910012350 S.BEA MMZ1608Y 102BT B 37/4.6
EP524 6910012350 S.BEA MMZ1608Y 102BT B 20.5/4.3
EP554 6910012350 S.BEA MMZ1608Y 102BT B 53.9/4.4
EP574 6910012350 S.BEA MMZ1608Y 102BT B 71/4.1
EP682 6910012350 S.BEA MMZ1608Y 102BT T 25.2/33.5
EP1503 6910015970 S.BEA MMZ1608B 301CT-AS T 39.6/65.4
EP2501 6910015970 S.BEA MMZ1608B 301CT-AS T 28.4/47.7
S.=Surface mount
[RF UNIT]
REF PARTS
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
IC161 1190001930 S.IC PS7122AL-1A-E3 T 134.8/91.3
IC201 1110007400 S.IC BGA616 T 4.1/33.2
IC301 1130011530 S.IC CD74HC4094M96 B 40.1/13.4
IC303 1130011530 S.IC CD74HC4094M96 B 40.1/24.3
IC305 1130011530 S.IC CD74HC4094M96 B 29/19
IC1401 1110006420 S.IC UPC2708TB-E3-A T 53.6/40
Q101 1590003680 S.TRA KRC402 RTK/P T 9.2/68
Q102 1590003680 S.TRA KRC402 RTK/P T 5.6/68.4
Q103 1530003900 S.TRA KTC4075 BL-RTK/P B 74.7/71.7
Q104 1590003770 S.TRA KRA302E-RTK/P B 72.4/73.2
Q151 1590003680 S.TRA KRC402 RTK/P T 46.8/83.2
Q152 1590003680 S.TRA KRC402 RTK/P T 44/81.2
Q153 1590003680 S.TRA KRC402 RTK/P T 49.5/83.3
Q161 1590003680 S.TRA KRC402 RTK/P B 115.2/81
Q162 1590003680 S.TRA KRC402 RTK/P T 143/85.6
Q201 1590003770 S.TRA KRA302E-RTK/P T 7.5/27.8
Q202 1590003680 S.TRA KRC402 RTK/P T 8/30.8
Q203 1590003680 S.TRA KRC402 RTK/P T 9.5/34.5
Q204 1590003680 S.TRA KRC402 RTK/P T 6.7/34.4
Q303 1590003680 S.TRA KRC402 RTK/P T 44.5/13.5
Q307 1590003680 S.TRA KRC402 RTK/P T 38/13.3
Q308 1590003770 S.TRA KRA302E-RTK/P T 38.2/7.9
Q309 1590003680 S.TRA KRC402 RTK/P T 38/16.2
Q310 1590003770 S.TRA KRA302E-RTK/P T 40.3/7.9
Q311 1590003680 S.TRA KRC402 RTK/P T 43.6/9.6
Q312 1590003770 S.TRA KRA302E-RTK/P T 44/7
Q313 1590003680 S.TRA KRC402 RTK/P T 34/11.5
Q314 1590003770 S.TRA KRA302E-RTK/P T 31.7/11.1
Q317 1590003680 S.TRA KRC402 RTK/P T 43.4/24.3
Q318 1590003770 S.TRA KRA302E-RTK/P T 28.3/6.5
Q319 1590003680 S.TRA KRC402 RTK/P T 39.3/23.1
Q320 1590003770 S.TRA KRA302E-RTK/P T 27.9/9.7
Q321 1590003680 S.TRA KRC402 RTK/P B 31.1/7.5
Q322 1590003770 S.TRA KRA302E-RTK/P B 28.6/5.7
Q323 1590003680 S.TRA KRC402 RTK/P B 32.4/11.1
Q324 1590003770 S.TRA KRA302E-RTK/P B 27.8/8.3
Q325 1590003680 S.TRA KRC402 RTK/P T 33/25.1
Q326 1590003770 S.TRA KRA302E-RTK/P T 25.4/8.3
Q327 1590003680 S.TRA KRC402 RTK/P B 28.5/12.5
Q328 1590003770 S.TRA KRA302E-RTK/P B 27/10.3
Q329 1590003680 S.TRA KRC402 RTK/P T 32.9/27.6
Q330 1590003770 S.TRA KRA302E-RTK/P T 30.1/28.2
Q331 1590003680 S.TRA KRC402 RTK/P B 29/29.3
Q332 1590003770 S.TRA KRA302E-RTK/P B 28.5/32.1
Q333 1590003680 S.TRA KRC402 RTK/P B 24.9/31.4
Q334 1590003770 S.TRA KRA302E-RTK/P B 22.2/30.9
Q335 1590003680 S.TRA KRC402 RTK/P B 24.9/28.8
Q336 1590003770 S.TRA KRA302E-RTK/P B 22.1/28.3
Q337 1590003680 S.TRA KRC402 RTK/P T 26.5/17.8
Q338 1590003770 S.TRA KRA302E-RTK/P T 26/20.9
Q339 1590003680 S.TRA KRC402 RTK/P B 24.9/26.2
Q340 1590003770 S.TRA KRA302E-RTK/P B 22.1/25.7
Q341 1590003680 S.TRA KRC402 RTK/P T 27.7/25
Q342 1590003770 S.TRA KRA302E-RTK/P T 25.2/24.4
Q343 1590003680 S.TRA KRC402 RTK/P T 26.3/27.7
Q344 1590003770 S.TRA KRA302E-RTK/P T 23.8/27.1
Q345 1590003680 S.TRA KRC402 RTK/P T 24.9/30.4
Q346 1590003770 S.TRA KRA302E-RTK/P T 22.4/29.8
Q1001 1560000641 S.FET 2SK1740-4/5-TB-E T 72.6/26.6
Q1002 1560000641 S.FET 2SK1740-4/5-TB-E T 72.6/23.5
Q1003 1560000641 S.FET 2SK1740-4/5-TB-E B 92.6/27.5
Q1004 1560000641 S.FET 2SK1740-4/5-TB-E T 90.1/31.9
Q1005 1560000641 S.FET 2SK1740-4/5-TB-E T 90.1/24.1
Q1006 1560000641 S.FET 2SK1740-4/5-TB-E B 92.6/23.4
Q1007 1530003900 S.TRA KTC4075 BL-RTK/P T 106.8/33.2
Q1008 1530003340 S.TRA 2SC3357-T1 RF T 107.6/20.6
Q1101 1530003340 S.TRA 2SC3357-T1 RF T 81.1/19.7
Q1201 1560000641 S.FET 2SK1740-4/5-TB-E T 72.3/48.5
Q1202 1560000641 S.FET 2SK1740-4/5-TB-E T 72.3/45.5
Q1203 1560000641 S.FET 2SK1740-4/5-TB-E B 92.6/49.9
Q1204 1560000641 S.FET 2SK1740-4/5-TB-E T 89.2/51.1
Q1205 1560000641 S.FET 2SK1740-4/5-TB-E T 89.2/45.5
Q1206 1560000641 S.FET 2SK1740-4/5-TB-E B 92.6/46.5
Q1207 1530003900 S.TRA KTC4075 BL-RTK/P T 103.3/58.6
Q1208 1530003340 S.TRA 2SC3357-T1 RF T 108.5/51.8
Q1209 1530003851 S.TRA 2SC5551F-TD-E B 98.9/56.2
Q1301 1530003340 S.TRA 2SC3357-T1 RF T 75.5/62.4
Q1551 1560000561 S.FET 2SK882-GR(TE85L,F) B 121/70.1
Q1901 1590003680 S.TRA KRC402 RTK/P T 130.9/27.2
Q1902 1590003770 S.TRA KRA302E-RTK/P T 130.9/29.5
Q2001 1560000641 S.FET 2SK1740-4/5-TB-E T 106.6/76
D101 1790000980 S.DIO MA742(TX) B 83.2/72.4
D104 1750000581 S.DIO 1SV307(TPH3,F) B 14.1/79.4
D105 1750001320 S.DIO KDS4148U RTK/P B 77.4/74.7
D106 1750001320 S.DIO KDS4148U RTK/P T 59.4/77.7
D107 1750001320 S.DIO KDS4148U RTK/P T 67/75.1
D108 1750001320 S.DIO KDS4148U RTK/P B 86.2/75
D109 1750001320 S.DIO KDS4148U RTK/P B 94.7/75.7
D151 1750000581 S.DIO 1SV307(TPH3,F) T 46/86
D152 1750000581 S.DIO 1SV307(TPH3,F) B 16.4/82.1
D161 1750001320 S.DIO KDS4148U RTK/P B 111/83.4
D201 1750000581 S.DIO 1SV307(TPH3,F) B 2.9/77.8
D501 1750000581 S.DIO 1SV307(TPH3,F) T 20.5/71.8
D502 1750000581 S.DIO 1SV307(TPH3,F) T 28.8/41.8
D551 1750000581 S.DIO 1SV307(TPH3,F) T 31/74.8
D552 1750000581 S.DIO 1SV307(TPH3,F) T 33/44.6
D601 1750000581 S.DIO 1SV307(TPH3,F) T 21.4/75.2
D602 1750000581 S.DIO 1SV307(TPH3,F) T 25.7/74.5
D603 1750000581 S.DIO 1SV307(TPH3,F) T 28.8/43.6
D604 1750000581 S.DIO 1SV307(TPH3,F) B 42/44.9
