Apr. 2009
25
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[PREAMP UNIT]
REF PARTS
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
Q4101 1590003680 S.TRA KRC402 RTK/P T 49.4/33.7
Q4102 1590003770 S.TRA KRA302E-RTK/P T 47/31.7
Q4201 1530003851 S.TRA 2SC5551F-TD-E T 43.8/24.4
Q4202 1530003851 S.TRA 2SC5551F-TD-E T 36.3/12.9
Q4203 1590003770 S.TRA KRA302E-RTK/P T 21/10.2
Q4204 1590003770 S.TRA KRA302E-RTK/P T 20.5/4.7
Q4205 1590003770 S.TRA KRA302E-RTK/P B 45.7/24.5
Q4301 1590003770 S.TRA KRA302E-RTK/P T 23.5/25.7
Q4302 1530003851 S.TRA 2SC5551F-TD-E B 6/18.9
Q4303 1590003770 S.TRA KRA302E-RTK/P T 22.7/23.6
Q4304 1590003770 S.TRA KRA302E-RTK/P T 18.9/8.4
Q4305 1590003680 S.TRA KRC402 RTK/P T 16.6/7.3
D4101 1750000581 S.DIO 1SV307(TPH3,F) T 41.9/30.8
D4102 1750000581 S.DIO 1SV307(TPH3,F) T 48.8/26.2
D4201 1750000581 S.DIO 1SV307(TPH3,F) T 37.8/31.7
D4202 1750000581 S.DIO 1SV307(TPH3,F) T 44.5/15.9
D4203 1750001320 S.DIO KDS4148U RTK/P T 21/7.5
D4301 1750000581 S.DIO 1SV307(TPH3,F) T 35.1/32.1
D4302 1750000581 S.DIO 1SV307(TPH3,F) T 48.4/7.4
D4303 1750001320 S.DIO KDS4148U RTK/P T 22.4/21.7
L4101 6200003221 S.COI NLV32T-151J B 47.5/33
L4201 6200003221 S.COI NLV32T-151J T 38/28.6
L4202 6140003800 COI LR-439
L4203 6200009060 S.COI LQH32CN101K23L T 38.1/17.5
L4204 6200009060 S.COI LQH32CN101K23L T 25.4/7.5
L4205 6140003810 COI LR-440
L4206 6140003810 COI LR-440
L4207 6200009060 S.COI LQH32CN101K23L T 31.6/7.5
L4208 6140003800 COI LR-439
L4209 6200003221 S.COI NLV32T-151J B 42.9/23.1
L4210 6200007780 S.COI LQW2BHNR12J03L B 42.4/17.5
L4301 6200003221 S.COI NLV32T-151J T 19.2/26.5
L4302 6140004430 COI LR-500
L4303 6140003900 COI LR-489
L4304 6200009060 S.COI LQH32CN101K23L T 15.1/24.1
L4305 6200003221 S.COI NLV32T-151J T 17.1/12.4
R4101 7030003280 S.RES ERJ3GEYJ 470 V (47) B 42.7/32.3
R4102 7030003280 S.RES ERJ3GEYJ 470 V (47) B 44.7/32.3
R4201 7030003280 S.RES ERJ3GEYJ 470 V (47) T 34.6/27.7
R4202 7030003280 S.RES ERJ3GEYJ 470 V (47) T 41.7/17
R4203 7030003280 S.RES ERJ3GEYJ 470 V (47) T 27.5/6.1
R4204 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 44.5/19.9
R4205 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 41.8/13.1
R4206 7030003490 S.RES ERJ3GEYJ 272 V (2.7K) T 41.8/18.8
R4207 7030003490 S.RES ERJ3GEYJ 272 V (2.7K) T 39.9/15
R4208 7030003280 S.RES ERJ3GEYJ 470 V (47) B 41.6/19.7
R4209 7030003220 S.RES ERJ3GEYJ 150 V (15) B 37.2/23.6
R4210 7030003220 S.RES ERJ3GEYJ 150 V (15) B 28.7/15.2
R4213 7030003280 S.RES ERJ3GEYJ 470 V (47) T 40.6/21.4
R4214 7030003280 S.RES ERJ3GEYJ 470 V (47) T 33.1/12.4
R4301 7030003280 S.RES ERJ3GEYJ 470 V (47) T 21.4/28.4
R4302 7030003510 S.RES ERJ3GEYJ 392 V (3.9K) B 13.3/25.7
R4303 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 13.3/23.3
R4304 7030007860 S.RES ERJ3GEYJ 8R2V (8.2) B 1.6/19.3
R4305 7030003240 S.RES ERJ3GEYJ 220 V (22) B 11.9/28.7
R4306 7030003280 S.RES ERJ3GEYJ 470 V (47) T 15.4/10.3
R4307 7030003200 S.RES ERJ3GEYJ 100 V (10) T 14.3/28.6
R4308 7030003280 S.RES ERJ3GEYJ 470 V (47) B 5.2/26.4
C4101 4030011600 S.CER C1608 JB 1E 104K-T B 47.3/29.4
C4102 4030019320 S.CER C1608 X7R 1C 105K-T T 45.4/29.8
C4103 4030011600 S.CER C1608 JB 1E 104K-T T 48.4/30
C4104 4030011600 S.CER C1608 JB 1E 104K-T T 49.6/31.3
C4201 4030019320 S.CER C1608 X7R 1C 105K-T T 30.2/27.7
C4202 4030011600 S.CER C1608 JB 1E 104K-T T 44.1/28.3
C4205 4030017490 S.CER C1608 JB 1A 105K-T B 33.9/23.6
C4206 4030017490 S.CER C1608 JB 1A 105K-T T 26.7/18.8
C4207 4030017490 S.CER C1608 JB 1A 105K-T T 46.9/22.8
C4208 4030017490 S.CER C1608 JB 1A 105K-T T 40.6/13.1
C4209 4030019320 S.CER C1608 X7R 1C 105K-T B 35/18.9
C4210 4030019320 S.CER C1608 X7R 1C 105K-T B 26.5/8.1
C4211 4030019320 S.CER C1608 X7R 1C 105K-T B 39/16
C4212 4030019320 S.CER C1608 X7R 1C 105K-T B 33.5/8.9
C4213 4030017810 S.CER C1608 CH 1H 102J-T T 34.1/7.8
C4215 4030019320 S.CER C1608 X7R 1C 105K-T B 44/11.5
C4216 4030011600 S.CER C1608 JB 1E 104K-T B 43.7/26.4
C4217 4030007110 S.CER C1608 CH 1H 680J-T B 44.2/14.1
C4218 4030007110 S.CER C1608 CH 1H 680J-T B 42.5/15.6
C4221 4030009510 S.CER C1608 CH 1H 010B-T T 42.6/20.7
C4222 4030009510 S.CER C1608 CH 1H 010B-T T 38.1/10.1
C4223 4030007010 S.CER C1608 CH 1H 100D-T B 38.5/8
C4224 4030017810 S.CER C1608 CH 1H 102J-T T 29.6/18.9
C4225 4030017810 S.CER C1608 CH 1H 102J-T T 43.3/18.8
C4226 4030017810 S.CER C1608 CH 1H 102J-T T 39.4/13.1
C4301 4030011600 S.CER C1608 JB 1E 104K-T T 21.4/25.8
C4302 4030019320 S.CER C1608 X7R 1C 105K-T T 17.3/29.3
C4303 4030017810 S.CER C1608 CH 1H 102J-T B 10.2/24.2
C4304 4030017810 S.CER C1608 CH 1H 102J-T B 10.2/27.2
C4305 4030019320 S.CER C1608 X7R 1C 105K-T T 11.3/18.5
C4306 4030017490 S.CER C1608 JB 1A 105K-T T 14.5/13.3
C4307 4030017810 S.CER C1608 CH 1H 102J-T B 11.1/21.1
C4308 4030011600 S.CER C1608 JB 1E 104K-T T 18/10.3
C4309 4030006990 S.CER C1608 CH 1H 080D-T T 15.5/27.2
C4310 4550006120 S.TAN TEESVA 0G 226M8R T 11.6/25.9
C4311 4550006120 S.TAN TEESVA 0G 226M8R T 6.7/19.3
C4312 4030017490 S.CER C1608 JB 1A 105K-T T 9.8/27.2
C4313 4030017490 S.CER C1608 JB 1A 105K-T T 8.2/21.1
S.=Surface mount
[MCF-M UNIT]
[MCF-N UNIT]
REF PARTS
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
REF PARTS
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
FI5001 2030000740 S.MON FL-425 (HF-734A 64.455M BW6K) T 20/6
L5001 6200012350 S.COI C2520C-R62G-A T 8.9/7.6
L5002 6200012350 S.COI C2520C-R62G-A T 8.9/4.4
L5003 6200012350 S.COI C2520C-R62G-A T 31.2/7.6
L5004 6200012350 S.COI C2520C-R62G-A T 31.2/4.4
C5001 4030006900 S.CER C1608 JB 1H 103K-T T 6.2/6
C5002 4030007010 S.CER C1608 CH 1H 100D-T T 13.6/6.5
C5003 4030007010 S.CER C1608 CH 1H 100D-T T 14.9/6.5
C5004 4030007030 S.CER C1608 CH 1H 150J-T T 17.9/2.6
C5006 4030007010 S.CER C1608 CH 1H 100D-T T 25/5.5
C5007 4030007010 S.CER C1608 CH 1H 100D-T T 26.3/5.5
C5008 4030006900 S.CER C1608 JB 1H 103K-T T 33.9/6
EP5001 6910002161 CAS CASE-BM7H-LF
EP5002 6910002161 CAS CASE-BM7H-LF
FI6001 2030000750 S.MON FL-426 (HF-734A 64.455M BW3K) T 20/6
L6001 6200010960 S.COI C2520C-R47G-A (0.47U) T 8.9/7.6
L6002 6200010960 S.COI C2520C-R47G-A (0.47U) T 8.9/4.4
L6003 6200010960 S.COI C2520C-R47G-A (0.47U) T 31.2/7.6
L6004 6200010960 S.COI C2520C-R47G-A (0.47U) T 31.2/4.4
C6001 4030006900 S.CER C1608 JB 1H 103K-T T 6.2/6
C6002 4030009990 S.CER C1608 CH 1H 200J-T T 13.6/6.5
C6004 4030007030 S.CER C1608 CH 1H 150J-T T 17.9/2.6
C6007 4030009990 S.CER C1608 CH 1H 200J-T T 26.3/5.5
C6008 4030006900 S.CER C1608 JB 1H 103K-T T 33.9/6
EP6001 6910002161 CAS CASE-BM7H-LF
EP6002 6910002161 CAS CASE-BM7H-LF
[MCF-W UNIT]
REF PARTS
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
FI7001 2030000730 S.MON FL-424
(HF-734A 64.455M BW15K) T 20/6
L7001 6200012350 S.COI C2520C-R62G-A T 8.9/7.6
L7002 6200012350 S.COI C2520C-R62G-A T 8.9/4.4
L7003 6200012350 S.COI C2520C-R62G-A T 31.2/7.6
L7004 6200012350 S.COI C2520C-R62G-A T 31.2/4.4
C7001 4030006900 S.CER C1608 JB 1H 103K-T T 6.2/6
C7002 4030007040 S.CER C1608 CH 1H 180J-T T 13.6/6.5
C7005 4030006990 S.CER 8P C1608 CH T 17.9/2.6
C7007 4030007040 S.CER C1608 CH 1H 180J-T T 26.3/5.5
C7008 4030006900 S.CER C1608 JB 1H 103K-T T 33.9/6
EP7001 6910002161 CAS CASE-BM7H-LF
EP7002 6910002161 CAS CASE-BM7H-LF
