The underlined parts have been updated from the addendum of the previous version, or from the original page.
5-18g
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
[MAIN UNIT] (for IC-A210 and IC-A210E)
REF PART
DESCRIPTION M.
H/V
NO. NO.
LOCATION
[MAIN UNIT] (for IC-A210 and IC-A210E)
REF PART
DESCRIPTION M.
H/V
NO. NO.
LOCATION
(Amended page)
July 2019
C41 4030018980 S.CER C1608 JB 1H 104K-T [#01] B 44.9/91.5
4030018980 S.CER C1608 JB 1H 104K-T [#02]
4030023870 S.CER 0603B104K500CT [#03]
Eqv. 4030026160 S.CER MG18B104K500CT [#03]
C41 4030018980 S.CER C1608 JB 1H 104K-T [#05] B 44.9/91.5
4030018980 S.CER C1608 JB 1H 104K-T [#11]
4030018980 S.CER C1608 JB 1H 104K-T [#21]
4030023870 S.CER 0603B104K500CT [#23]
4030018980 S.CER C1608 JB 1H 104K-T [#25]
C42 4030006860 S.CER C1608 JB 1H 102K-T [#01] T 20.1/68.4
4030006860 S.CER C1608 JB 1H 102K-T [#02]
4030023850 S.CER 0603B102K500CT [#03]
Eqv. 4030026460 S.CER MG18B102K500CT [#03]
C42 4030006860 S.CER C1608 JB 1H 102K-T [#05] T 20.1/68.4
4030006860 S.CER C1608 JB 1H 102K-T [#11]
4030006860 S.CER C1608 JB 1H 102K-T [#21]
4030023850 S.CER 0603B102K500CT [#23]
4030006860 S.CER C1608 JB 1H 102K-T [#25]
C43 4030006860 S.CER C1608 JB 1H 102K-T [#01] T 20.1/63.8
4030006860 S.CER C1608 JB 1H 102K-T [#02]
4030023850 S.CER 0603B102K500CT [#03]
Eqv. 4030026460 S.CER MG18B102K500CT [#03]
C43 4030006860 S.CER C1608 JB 1H 102K-T [#05] T 20.1/63.8
4030006860 S.CER C1608 JB 1H 102K-T [#11]
4030006860 S.CER C1608 JB 1H 102K-T [#21]
4030023850 S.CER 0603B102K500CT [#23]
4030006860 S.CER C1608 JB 1H 102K-T [#25]
C44 4030006860 S.CER C1608 JB 1H 102K-T [#01] B 71.6/49.8
4030006860 S.CER C1608 JB 1H 102K-T [#02]
4030023850 S.CER 0603B102K500CT [#03]
Eqv. 4030026460 S.CER MG18B102K500CT [#03]
C44 4030006860 S.CER C1608 JB 1H 102K-T [#05] B 71.6/49.8
4030006860 S.CER C1608 JB 1H 102K-T [#11]
4030006860 S.CER C1608 JB 1H 102K-T [#21]
4030023850 S.CER 0603B102K500CT [#23]
4030006860 S.CER C1608 JB 1H 102K-T [#25]
C45 4030018980 S.CER C1608 JB 1H 104K-T [#01] T 122.1/116.4
4030018980 S.CER C1608 JB 1H 104K-T [#02]
4030023870 S.CER 0603B104K500CT [#03]
Eqv. 4030026160 S.CER MG18B104K500CT [#03]
C45 4030018980 S.CER C1608 JB 1H 104K-T [#05] T 122.1/116.4
4030018980 S.CER C1608 JB 1H 104K-T [#11]
4030018980 S.CER C1608 JB 1H 104K-T [#21]
4030023870 S.CER 0603B104K500CT [#23]
4030018980 S.CER C1608 JB 1H 104K-T [#25]
C46 4030006900 S.CER C1608 JB 1H 103K-T [#01] B 67.4/66.2
4030006900 S.CER C1608 JB 1H 103K-T [#02]
4030023860 S.CER 0603B103K500CT [#03]
Eqv. 4030026180 S.CER MG18B103K500CT [#03]
C46 4030006900 S.CER C1608 JB 1H 103K-T [#05] B 67.4/66.2
4030006900 S.CER C1608 JB 1H 103K-T [#11]
4030006900 S.CER C1608 JB 1H 103K-T [#21]
4030023860 S.CER 0603B103K500CT [#23]
4030006900 S.CER C1608 JB 1H 103K-T [#25]
C47 4510008500 S.ELE EEE1CA101WP [#01] T 44.5/92.1
4510008500 S.ELE EEE1CA101WP [#02]
4510008130 S.ELE 16 CE 220 BS [#03]
4510008500 S.ELE EEE1CA101WP [#05]
4510008500 S.ELE EEE1CA101WP [#11]
4510008500 S.ELE EEE1CA101WP [#21]
4510008500 S.ELE EEE1CA101WP [#23]
4510008500 S.ELE EEE1CA101WP [#25]
C48 4030006860 S.CER C1608 JB 1H 102K-T [#01] T 50.1/89.2
4030006860 S.CER C1608 JB 1H 102K-T [#02]
4030023850 S.CER 0603B102K500CT [#03]
Eqv. 4030026460 S.CER MG18B102K500CT [#03]
C48 4030006860 S.CER C1608 JB 1H 102K-T [#05] T 50.1/89.2
4030006860 S.CER C1608 JB 1H 102K-T [#11]
4030006860 S.CER C1608 JB 1H 102K-T [#21]
4030023850 S.CER 0603B102K500CT [#23]
4030006860 S.CER C1608 JB 1H 102K-T [#25]
C49 4510005520 ELE 50 ME 330 HC
C51 4550003220 S.TAN TEESVA 1E 105M8R T 50.1/93.4
Eqv. 4550007660 S.TAN F931E105MAABMA
C53 4030006860 S.CER C1608 JB 1H 102K-T [#01] B 83.1/52.6
4030006860 S.CER C1608 JB 1H 102K-T [#02]
4030023850 S.CER 0603B102K500CT [#03]
Eqv. 4030026460 S.CER MG18B102K500CT [#03]
C53 4030006860 S.CER C1608 JB 1H 102K-T [#05] B 83.1/52.6
4030006860 S.CER C1608 JB 1H 102K-T [#11]
4030006860 S.CER C1608 JB 1H 102K-T [#21]
4030023850 S.CER 0603B102K500CT [#23]
4030006860 S.CER C1608 JB 1H 102K-T [#25]
C54 4030017490 S.CER C1608 JB 1A 105K-T T 26.9/62.8
C55 4030017490 S.CER C1608 JB 1A 105K-T T 26.3/70.3
C56 4550007260 S.TAN F931C475MAABMA T 59.3/91.6
C57 4030006960 S.CER C1608 CH 1H 050C-T [#01] B 82.3/61.8
4030006960 S.CER C1608 CH 1H 050C-T [#02]
4030023360 S.CER 0603N5R0C500CT [#03]
4030006960 S.CER C1608 CH 1H 050C-T [#05]
4030006960 S.CER C1608 CH 1H 050C-T [#11]
4030006960 S.CER C1608 CH 1H 050C-T [#21]
4030023360 S.CER 0603N5R0C500CT [#23]
4030006960 S.CER C1608 CH 1H 050C-T [#25]
C58 4030006900 S.CER C1608 JB 1H 103K-T [#01] T 19.6/53.3
4030006900 S.CER C1608 JB 1H 103K-T [#02]
4030023860 S.CER 0603B103K500CT [#03]
Eqv. 4030026180 S.CER MG18B103K500CT [#03]
C58 4030006900 S.CER C1608 JB 1H 103K-T [#05] T 19.6/53.3
4030006900 S.CER C1608 JB 1H 103K-T [#11]
4030006900 S.CER C1608 JB 1H 103K-T [#21]
4030023860 S.CER 0603B103K500CT [#23]
4030006900 S.CER C1608 JB 1H 103K-T [#25]
C59 4030006900 S.CER C1608 JB 1H 103K-T [#01] B 23.3/51.9
4030006900 S.CER C1608 JB 1H 103K-T [#02]
4030023860 S.CER 0603B103K500CT [#03]
Eqv. 4030026180 S.CER MG18B103K500CT [#03]
C59 4030006900 S.CER C1608 JB 1H 103K-T [#05] B 23.3/51.9
4030006900 S.CER C1608 JB 1H 103K-T [#11]
4030006900 S.CER C1608 JB 1H 103K-T [#21]
4030023860 S.CER 0603B103K500CT [#23]
4030006900 S.CER C1608 JB 1H 103K-T [#25]
C60 4030019260 S.CER C3225 JB 1H 335MT [#01] T 92.9/112.3
4030019260 S.CER C3225 JB 1H 335MT [#02]
4030019470 S.CER C3216 JB 1H 474K-T [#03]
4030019260 S.CER C3225 JB 1H 335MT [#05]
4030019260 S.CER C3225 JB 1H 335MT [#11]
4030019260 S.CER C3225 JB 1H 335MT [#21]
4030019260 S.CER C3225 JB 1H 335MT [#23]
4030019260 S.CER C3225 JB 1H 335MT [#25]
C61 4510007321 ELE 50 YXG 470 MEFC 12.5×20
C62 4030006860 S.CER C1608 JB 1H 102K-T [#01] B 101.2/53.9
4030006860 S.CER C1608 JB 1H 102K-T [#02]
4030023850 S.CER 0603B102K500CT [#03]
Eqv. 4030026460 S.CER MG18B102K500CT [#03]
C62 4030006860 S.CER C1608 JB 1H 102K-T [#05] B 101.2/53.9
4030006860 S.CER C1608 JB 1H 102K-T [#11]
4030006860 S.CER C1608 JB 1H 102K-T [#21]
4030023850 S.CER 0603B102K500CT [#23]
4030006860 S.CER C1608 JB 1H 102K-T [#25]
C63 4030011340 S.CER C1608 CH 1H 471J-T [#01] T 20.9/50.3
4030011340 S.CER C1608 CH 1H 471J-T [#02]
4030023730 S.CER 0603N471J500CT [#03]
4030011340 S.CER C1608 CH 1H 471J-T [#05]
4030011340 S.CER C1608 CH 1H 471J-T [#11]
4030011340 S.CER C1608 CH 1H 471J-T [#21]
4030023730 S.CER 0603N471J500CT [#23]
4030011340 S.CER C1608 CH 1H 471J-T [#25]
C64 4030007070 S.CER C1608 CH 1H 330J-T [#01] B 101.1/59.7
4030007070 S.CER C1608 CH 1H 330J-T [#02]
4030023670 S.CER 0603N330J500CT [#03]
4030007070 S.CER C1608 CH 1H 330J-T [#05]
4030007070 S.CER C1608 CH 1H 330J-T [#11]
4030007070 S.CER C1608 CH 1H 330J-T [#21]
4030023670 S.CER 0603N330J500CT [#23]
4030007070 S.CER C1608 CH 1H 330J-T [#25]
C65 4030006860 S.CER C1608 JB 1H 102K-T [#01] B 110.0/53.1
4030006860 S.CER C1608 JB 1H 102K-T [#02]
4030023850 S.CER 0603B102K500CT [#03]
Eqv. 4030026460 S.CER MG18B102K500CT [#03]
C65 4030006860 S.CER C1608 JB 1H 102K-T [#05] B 110.0/53.1
4030006860 S.CER C1608 JB 1H 102K-T [#11]
4030006860 S.CER C1608 JB 1H 102K-T [#21]
4030023850 S.CER 0603B102K500CT [#23]
4030006860 S.CER C1608 JB 1H 102K-T [#25]
C66 4510007321 ELE 50 YXG 470 MEFC 12.5X20
C67 4030018980 S.CER C1608 JB 1H 104K-T [#01] B 134.7/19.3
4030018980 S.CER C1608 JB 1H 104K-T [#02]
4030023870 S.CER 0603B104K500CT [#03]
Eqv. 4030026160 S.CER MG18B104K500CT [#03]
C67 4030018980 S.CER C1608 JB 1H 104K-T [#05] B 134.7/19.3
4030018980 S.CER C1608 JB 1H 104K-T [#11]
4030018980 S.CER C1608 JB 1H 104K-T [#21]
4030023870 S.CER 0603B104K500CT [#23]
4030018980 S.CER C1608 JB 1H 104K-T [#25]
C68 4030006860 S.CER C1608 JB 1H 102K-T [#01] T 131.0/21.9
4030006860 S.CER C1608 JB 1H 102K-T [#02]
4030023850 S.CER 0603B102K500CT [#03]
Eqv. 4030026460 S.CER MG18B102K500CT [#03]
C68 4030006860 S.CER C1608 JB 1H 102K-T [#05] T 131.0/21.9
4030006860 S.CER C1608 JB 1H 102K-T [#11]
4030006860 S.CER C1608 JB 1H 102K-T [#21]
4030023850 S.CER 0603B102K500CT [#23]
4030006860 S.CER C1608 JB 1H 102K-T [#25]
C73 4510008830 S.ELE EEE1CA221P T 64.8/91.5
C74 4030006860 S.CER C1608 JB 1H 102K-T [#01] T 98.9/62.1
4030006860 S.CER C1608 JB 1H 102K-T [#02]
4030023850 S.CER 0603B102K500CT [#03]
Eqv. 4030026460 S.CER MG18B102K500CT [#03]
C74 4030006860 S.CER C1608 JB 1H 102K-T [#05] T 98.9/62.1
4030006860 S.CER C1608 JB 1H 102K-T [#11]
4030006860 S.CER C1608 JB 1H 102K-T [#21]
4030023850 S.CER 0603B102K500CT [#23]
4030006860 S.CER C1608 JB 1H 102K-T [#25]
C75 4030006900 S.CER C1608 JB 1H 103K-T [#01] T 103.5/65.5
4030006900 S.CER C1608 JB 1H 103K-T [#02]
4030023860 S.CER 0603B103K500CT [#03]
Eqv. 4030026180 S.CER MG18B103K500CT [#03]
C75 4030006900 S.CER C1608 JB 1H 103K-T [#05] T 103.5/65.5
4030006900 S.CER C1608 JB 1H 103K-T [#11]
4030006900 S.CER C1608 JB 1H 103K-T [#21]
4030023860 S.CER 0603B103K500CT [#23]
4030006900 S.CER C1608 JB 1H 103K-T [#25]
