Icom IC-A220

The underlined parts have been updated from the addendum of the previous version, or from the original page.
5-46g
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
[MAIN-B UNIT] (for only IC-A220)
REF PART
DESCRIPTION M.
H/V
NO. NO.
LOCATION
[MAIN-B UNIT] (for only IC-A220)
REF PART
DESCRIPTION M.
H/V
NO. NO.
LOCATION
(Amended page)
July 2019
C31 4030023360 S.CER 0603N5R0C500CT B 58.2/61.5
C32 4510009400 S.ELE UUL1V100MCL1GS T 131.3/115.4
C33 4030023670 S.CER 0603N330J500CT T 3.4/106.4
C34 4030010210 S.CER C3216 JB 1C 105M-T T 21.2/66.4
C35 4030010210 S.CER C3216 JB 1C 105M-T T 21.2/60.9
C36 4030023850 S.CER 0603B102K500CT B 68.3/64.1
Eqv. 4030026460 S.CER MG18B102K500CT
C37 4030024290 S.CER 0805B103K500CT T 126.9/113.1
C38 4030023320 S.CER 0603N3R0C500CT B 73.3/57.8
C39 4030023850 S.CER 0603B102K500CT B 68.7/66.2
Eqv. 4030026460 S.CER MG18B102K500CT
C40 4030024290 S.CER 0805B103K500CT T 3.3/108.0
C41 4030023870 S.CER 0603B104K500CT B 44.9/91.5
Eqv. 4030026160 S.CER MG18B104K500CT
C42 4030023850 S.CER 0603B102K500CT T 20.1/68.4
Eqv. 4030026460 S.CER MG18B102K500CT
C43 4030023850 S.CER 0603B102K500CT T 20.1/63.8
Eqv. 4030026460 S.CER MG18B102K500CT
C44 4030023850 S.CER 0603B102K500CT B 71.6/49.8
Eqv. 4030026460 S.CER MG18B102K500CT
C45 4030023870 S.CER 0603B104K500CT T 122.1/116.4
Eqv. 4030026160 S.CER MG18B104K500CT
C46 4030023860 S.CER 0603B103K500CT B 67.4/66.2
Eqv. 4030026180 S.CER MG18B103K500CT
C47 4510009340 S.ELE EEEHA1C101WP T 44.5/92.1
C48 4030023850 S.CER 0603B102K500CT T 50.1/89.2
Eqv. 4030026460 S.CER MG18B102K500CT
C49 4510010970 ELE 63 ME 330 CZ
C54 4030017490 S.CER C1608 JB 1A 105K-T T 120.2/21.6
C55 4030017490 S.CER C1608 JB 1A 105K-T T 118.7/12.0
C56 4550007260 S.TAN F931C475MAABMA B 4.6/23.4
C57 4030023360 S.CER 0603N5R0C500CT B 16.7/24.3
C58 4030023860 S.CER 0603B103K500CT T 54.1/11.0
Eqv. 4030026180 S.CER MG18B103K500CT
C59 4030023860 S.CER 0603B103K500CT T 50.8/11.0
Eqv. 4030026180 S.CER MG18B103K500CT
C60 4030019470 S.CER C3216 JB 1H 474K-T T 47.5/11.0
C61 4510011110 ELE 100ME100AX
C62 4030023850 S.CER 0603B102K500CT B 56.8/8.4
Eqv. 4030026460 S.CER MG18B102K500CT
C63 4030023730 S.CER 0603N471J500CT B 71.6/6.9
C64 4030023670 S.CER 0603N330J500CT B 72.8/6.9
C65 4030023850 S.CER 0603B102K500CT B 110.0/53.1
Eqv. 4030026460 S.CER MG18B102K500CT
C66 4510007321 ELE 50 YXG 470 MEFC 12.5×20
C67 4030023870 S.CER 0603B104K500CT B 21.8/16.7
Eqv. 4030026160 S.CER MG18B104K500CT
C68 4030023850 S.CER 0603B102K500CT B 26.9/16.7
Eqv. 4030026460 S.CER MG18B102K500CT
C69 4030023850 S.CER 0603B102K500CT B 112.8/52.8
Eqv. 4030026460 S.CER MG18B102K500CT
C72 4030017490 S.CER C1608 JB 1A 105K-T B 45.0/133.0
C73 4510008830 S.ELE EEE1CA221P T 64.8/91.5
C74 4030023850 S.CER 0603B102K500CT T 98.9/62.1
Eqv. 4030026460 S.CER MG18B102K500CT
C75 4030023860 S.CER 0603B103K500CT T 103.5/65.5
Eqv. 4030026180 S.CER MG18B103K500CT
C76 4030023860 S.CER 0603B103K500CT B 110.7/67.0
Eqv. 4030026180 S.CER MG18B103K500CT
C77 4030023860 S.CER 0603B103K500CT B 111.1/59.3
Eqv. 4030026180 S.CER MG18B103K500CT
C78 4030017490 S.CER C1608 JB 1A 105K-T T 36.3/65.2
C79 4550008170 S.TAN F931A476MBA T 51.3/64.7
C80 4030023500 S.CER 0603N150J500CT B 113.8/67.7
C81 4030023590 S.CER 0603N221J500CT T 117.8/91.1
C82 4030017490 S.CER C1608 JB 1A 105K-T B 22.3/60.9
C83 4030023870 S.CER 0603B104K500CT T 72.2/88.4
Eqv. 4030026160 S.CER MG18B104K500CT
C84 4030023620 S.CER 0603N270J500CT T 112.2/58.6
C85 4510009691 ELE 50 WA 1000 MEFC 16×20
C86 4030017490 S.CER C1608 JB 1A 105K-T B 84.2/23.4
C87 4030023440 S.CER 0603N0R5C500CT T 93.1/18.6
C88 4030023440 S.CER 0603N0R5C500CT T 182.0/31.0
C89 4030023850 S.CER 0603B102K500CT T 178.6/41.2
Eqv. 4030026460 S.CER MG18B102K500CT
C90 4030023850 S.CER 0603B102K500CT T 186.0/27.7
Eqv. 4030026460 S.CER MG18B102K500CT
C91 4030023520 S.CER 0603N180J500CT T 180.0/41.2
C92 4030023500 S.CER 0603N150J500CT T 184.2/31.8
C93 4030017480 S.CER C1608 JB 1A 474K-T T 84.0/88.1
C94 4030023450 S.CER 0603N100D500CT T 182.6/39.1
C95 4030023850 S.CER 0603B102K500CT T 46.6/72.4
Eqv. 4030026460 S.CER MG18B102K500CT
C96 4030023860 S.CER 0603B103K500CT B 175.6/22.8
Eqv. 4030026180 S.CER MG18B103K500CT
C97 4030023280 S.CER 0603N1R0C500CT B 112.6/67.7
C98 4030023360 S.CER 0603N5R0C500CT T 186.6/29.6
C99 4030023860 S.CER 0603B103K500CT B 192.9/21.9
Eqv. 4030026180 S.CER MG18B103K500CT
C100 4550007610 S.TAN F931E474MAABMA T 49.1/70.7
C101 4030023860 S.CER 0603B103K500CT T 156.1/121.0
Eqv. 4030026180 S.CER MG18B103K500CT
C102 4030023520 S.CER 0603N180J500CT T 185.1/41.2
C103 4030023870 S.CER 0603B104K500CT T 96.5/70.8
Eqv. 4030026160 S.CER MG18B104K500CT
C104 4030010210 S.CER C3216 JB 1C 105M-T T 140.3/112.3
C105 4030023480 S.CER 0603N120J500CT T 189.0/31.7
C106 4030017070 S.CER GRM32MR11H474KA01L
(GRM42-2R) T 32.1/122.3
C107 4030017490 S.CER C1608 JB 1A 105K-T T 53.9/71.5
C108 4030023850 S.CER 0603B102K500CT T 182.8/36.9
Eqv. 4030026460 S.CER MG18B102K500CT
C109 4030023850 S.CER 0603B102K500CT T 187.5/27.7
Eqv. 4030026460 S.CER MG18B102K500CT
C110 4030023730 S.CER 0603N471J500CT B 15.3/54.3
C111 4030023680 S.CER 0603N331J500CT T 133.1/106.3
C112 4030017070 S.CER GRM32MR11H474KA01L
(GRM42-2R) T 42.9/119.5
C113 4030023860 S.CER 0603B103K500CT T 141.4/108.3
Eqv. 4030026180 S.CER MG18B103K500CT
C114 4030017070 S.CER GRM32MR11H474KA01L
(GRM42-2R) T 45.9/119.5
C115 4030023300 S.CER 0603N2R0C500CT T 189.9/43.8
C116 4030023870 S.CER 0603B104K500CT T 143.0/108.3
Eqv. 4030026160 S.CER MG18B104K500CT
C117 4030023860 S.CER 0603B103K500CT T 182.0/33.2
Eqv. 4030026180 S.CER MG18B103K500CT
C118 4510009340 S.ELE EEEHA1C101WP T 147.2/110.0
C119 4030017070 S.CER GRM32MR11H474KA01L
(GRM42-2R) T 51.7/119.5
C120 4030017070 S.CER GRM32MR11H474KA01L
(GRM42-2R) T 54.7/119.5
C121 4030023860 S.CER 0603B103K500CT T 92.9/105.9
Eqv. 4030026180 S.CER MG18B103K500CT
C124 4030023860 S.CER 0603B103K500CT T 193.0/24.5
Eqv. 4030026180 S.CER MG18B103K500CT
C125 4030023580 S.CER 0603N220J500CT T 189.9/45.2
C126 4510008010 S.ELE 20SVP22M-AIC T 98.6/120.9
C127 4540000160 S.TRI JZ100 T 185.7/45.2
C128 4030023460 S.CER 0603N101J500CT B 115.9/112.4
Eqv. 4030026120 S.CER MG18N101J500CT
C130 4030023480 S.CER 0603N120J500CT T 194.5/34.8
C131 4030017490 S.CER C1608 JB 1A 105K-T B 120.5/116.3
C132 4030023590 S.CER 0603N221J500CT T 95.1/95.2
C134 4030023870 S.CER 0603B104K500CT T 86.5/78.9
Eqv. 4030026160 S.CER MG18B104K500CT
C136 4540000160 S.TRI JZ100 T 190.4/35.2
C137 4030023750 S.CER 0603N560J500CT T 189.9/46.4
C138 4030017070 S.CER GRM32MR11H474KA01L
(GRM42-2R) T 86.8/115.9
C139 4030023700 S.CER 0603N390J500CT T 196.3/36.4
C140 4030017480 S.CER C1608 JB 1A 474K-T T 85.8/81.0
C141 4030018780 S.CER C3225 JB 2J 473K-T T 89.9/115.9
C142 4030023320 S.CER 0603N3R0C500CT T 119.3/61.6
C143 4030023480 S.CER 0603N120J500CT T 115.4/61.6
C147 4030023450 S.CER 0603N100D500CT T 122.2/64.1
C148 4030023620 S.CER 0603N270J500CT T 122.3/57.6
C150 4030018910 S.CER C1608 JB 0J 475K-T T 144.0/82.4
C151 4550008480 S.TAN F921C225MPA T 84.9/78.6
C155 4030023520 S.CER 0603N180J500CT T 128.4/58.5
C156 4030023850 S.CER 0603B102K500CT T 134.8/94.7
Eqv. 4030026460 S.CER MG18B102K500CT
C157 4030023870 S.CER 0603B104K500CT T 136.7/91.6
Eqv. 4030026160 S.CER MG18B104K500CT
C158 4030011810 S.CER C1608 JB 1A 224K-T T 133.6/94.7
C159 4550008220 S.TAN F931C106MAA T 124.1/95.0
C160 4030023860 S.CER 0603B103K500CT T 133.4/53.9
Eqv. 4030026180 S.CER MG18B103K500CT
C161 4030023860 S.CER 0603B103K500CT T 136.9/55.0
Eqv. 4030026180 S.CER MG18B103K500CT
C162 4030017490 S.CER C1608 JB 1A 105K-T T 91.2/75.5
C163 4030023850 S.CER 0603B102K500CT T 137.2/94.7
Eqv. 4030026460 S.CER MG18B102K500CT
C165 4030024040 S.CER 0603B472K500CT T 100.1/84.5
C166 4030023860 S.CER 0603B103K500CT T 132.7/60.4
Eqv. 4030026180 S.CER MG18B103K500CT
C167 4030023860 S.CER 0603B103K500CT T 192.8/46.8
Eqv. 4030026180 S.CER MG18B103K500CT
C168 4030023870 S.CER 0603B104K500CT T 138.1/57.5
Eqv. 4030026160 S.CER MG18B104K500CT
C169 4030017490 S.CER C1608 JB 1A 105K-T T 140.8/66.6
C170 4030023460 S.CER 0603N101J500CT T 138.9/60.4
Eqv. 4030026120 S.CER MG18N101J500CT
C171 4030024050 S.CER 0603B473K500CT T 138.2/56.2
C172 4030023860 S.CER 0603B103K500CT T 143.6/93.0
Eqv. 4030026180 S.CER MG18B103K500CT
C174 4030023850 S.CER 0603B102K500CT T 141.6/64.7
Eqv. 4030026460 S.CER MG18B102K500CT
C175 4030023860 S.CER 0603B103K500CT T 150.2/92.6
Eqv. 4030026180 S.CER MG18B103K500CT
C177 4030023920 S.CER 0603B182K500CT T 97.1/86.5
C178 4030023880 S.CER 0603B122K500CT T 147.4/89.9
C179 4030024040 S.CER 0603B472K500CT T 144.5/62.0
C181 4030024390 S.CER 0603N561J500CT T 95.2/87.2
C182 4030023850 S.CER 0603B102K500CT T 156.4/129.8
Eqv. 4030026460 S.CER MG18B102K500CT
C183 4030023870 S.CER 0603B104K500CT T 156.4/128.6
Eqv. 4030026160 S.CER MG18B104K500CT
C184 4030024040 S.CER 0603B472K500CT T 117.0/95.5
C186 4030023860 S.CER 0603B103K500CT T 149.6/85.9
Eqv. 4030026180 S.CER MG18B103K500CT
C187 4030010210 S.CER C3216 JB 1C 105M-T T 157.1/125.3
C189 4030018600 S.CER C1608 CH 1H 152J-T T 112.1/94.4
C190 4510006830 ELE 63 ME 470CZ
C191 4030023870 S.CER 0603B104K500CT T 149.4/58.0
Eqv. 4030026160 S.CER MG18B104K500CT
C193 4030023490 S.CER 0603N121J500CT T 150.5/60.5
C194 4030023490 S.CER 0603N121J500CT T 150.5/59.3
C195 4030023730 S.CER 0603N471J500CT T 114.6/91.8
C196 4030023870 S.CER 0603B104K500CT T 152.3/84.5
Eqv. 4030026160 S.CER MG18B104K500CT
