Icom IC-A3E Service Manual

REF ORDER
DESCRIPTION
NO. NO.
REF ORDER
DESCRIPTION
NO. NO.
C4007 4030007050 S.CER C1608 CH 1H 220J-T
C4008 4030007080 S.CER C1608 CH 1H 390J-T
C4009 4030007030 S.CER C1608 CH 1H 150J-T
C4010 4030006860 S.CER C1608 JB 1H 102K-T
C4011 4030006860 S.CER C1608 JB 1H 102K-T
C4012 4030007030 S.CER C1608 CH 1H 150J-T
C4013 4030007030 S.CER C1608 CH 1H 150J-T
C4014 4030006860 S.CER C1608 JB 1H 102K-T
C4015 4030006860 S.CER C1608 JB 1H 102K-T
C4016 4030006860 S.CER C1608 JB 1H 102K-T
C4017 4030006950 S.CER C1608 CH 1H 040C-T
C4018 4030007110 S.CER C1608 CH 1H 680J-T
C4019 4030006860 S.CER C1608 JB 1H 102K-T
C4020 4030007110 S.CER C1608 CH 1H 680J-T
C4023 4030006860 S.CER C1608 JB 1H 102K-T
C4024 4030006860 S.CER C1608 JB 1H 102K-T
C4025 4030006860 S.CER C1608 JB 1H 102K-T
C4027 4030007110 S.CER C1608 CH 1H 680J-T
C4028 4030006860 S.CER C1608 JB 1H 102K-T
C4029 4030007110 S.CER C1608 CH 1H 680J-T
C4031 4030006860 S.CER C1608 JB 1H 102K-T
C4032 4030006860 S.CER C1608 JB 1H 102K-T
C4033 4030007080 S.CER C1608 CH 1H 390J-T
C4034 4030006860 S.CER C1608 JB 1H 102K-T
C4036 4030006980 S.CER C1608 CH 1H 070D-T
C4037 4030006900 S.CER C1608 JB 1H 103K-T
C4038 4030006900 S.CER C1608 JB 1H 103K-T
C4039 4030006860 S.CER C1608 JB 1H 102K-T
C4040 4030006900 S.CER C1608 JB 1H 103K-T
C4042 4030006860 S.CER C1608 JB 1H 102K-T
C4043 4030006860 S.CER C1608 JB 1H 102K-T
C4044 4030006860 S.CER C1608 JB 1H 102K-T
C4045 4030007040 S.CER C1608 CH 1H 180J-T
C4046 4030006860 S.CER C1608 JB 1H 102K-T
C4047 4030007050 S.CER C1608 CH 1H 220J-T
C4048 4030006860 S.CER C1608 JB 1H 102K-T
C4049 4030006860 S.CER C1608 JB 1H 102K-T
C4050 4030006860 S.CER C1608 JB 1H 102K-T
C4051 4030006860 S.CER C1608 JB 1H 102K-T
C4053 4030006860 S.CER C1608 JB 1H 102K-T
C4054 4030006990 S.CER C1608 CH 1H 080D-T
C4055 4030006860 S.CER C1608 JB 1H 102K-T
C4056 4030006860 S.CER C1608 JB 1H 102K-T
C4057 4030006860 S.CER C1608 JB 1H 102K-T
C4058 4030006860 S.CER C1608 JB 1H 102K-T
C4059 4030007080 S.CER C1608 CH 1H 390J-T
C4078 4510004630 S.ELE ECEV1CA100SR
C4080 4510005860 S.ELE ECEV1HA2R2SR
C4090 4030006860 S.CER C1608 JB 1H 102K-T
C4092 4030006860 S.CER C1608 JB 1H 102K-T
C4093 4030006860 S.CER C1608 JB 1H 102K-T
C4094 4510004630 S.ELE ECEV1CA100SR
C4095 4030006860 S.CER C1608 JB 1H 102K-T
C4096 4030006860 S.CER C1608 JB 1H 102K-T
C4097 4030006860 S.CER C1608 JB 1H 102K-T
C4098 4030006860 S.CER C1608 JB 1H 102K-T
C4099 4030007080 S.CER C1608 CH 1H 390J-T
C4100 4030007000 S.CER C1608 CH 1H 090D-T
C4101 4610002080 S.TRI ECR-KN010 C61X
C4102 4550006150 S.TAN ECST1CY105R
C4104 4550006360 S.TAN ECST1VY104R
C4106 4030006860 S.CER C1608 JB 1H 102K-T
C4107 4030006860 S.CER C1608 JB 1H 102K-T
C4108 4030006860 S.CER C1608 JB 1H 102K-T
C4109 4030006860 S.CER C1608 JB 1H 102K-T
C4110 4030006860 S.CER C1608 JB 1H 102K-T
C4111 4030006860 S.CER C1608 JB 1H 102K-T
C4112 4030006860 S.CER C1608 JB 1H 102K-T
C4113 4030007040 S.CER C1608 CH 1H 180J-T
C4114 4030007080 S.CER C1608 CH 1H 390J-T [EUR-1], [AUS], [USA-1] only
C4115 4030006860 S.CER C1608 JB 1H 102K-T
C4116 4030006860 S.CER C1608 JB 1H 102K-T
C4118 4030006860 S.CER C1608 JB 1H 102K-T
C4119 4030006860 S.CER C1608 JB 1H 102K-T
C4121 4030006860 S.CER C1608 JB 1H 102K-T
C4122 4030006860 S.CER C1608 JB 1H 102K-T
C4123 4030006860 S.CER C1608 JB 1H 102K-T
C4124 4030006860 S.CER C1608 JB 1H 102K-T
C4125 4030006860 S.CER C1608 JB 1H 102K-T
C4126 4030006860 S.CER C1608 JB 1H 102K-T
C4127 4030006860 S.CER C1608 JB 1H 102K-T
C4129 4030006860 S.CER C1608 JB 1H 102K-T
C4130 4030006860 S.CER C1608 JB 1H 102K-T
C4134 4510004440 S.ELE ECEV1HA010SR
C4135 4030006860 S.CER C1608 JB 1H 102K-T
C4136 4030006860 S.CER C1608 JB 1H 102K-T
C4137 4030006860 S.CER C1608 JB 1H 102K-T
C4138 4030006860 S.CER C1608 JB 1H 102K-T
C4139 4510004630 S.ELE ECEV1CA100SR
C4140 4030006860 S.CER C1608 JB 1H 102K-T
C4141 4030006860 S.CER C1608 JB 1H 102K-T
C4143 4030006860 S.CER C1608 JB 1H 102K-T
C4144 4030006860 S.CER C1608 JB 1H 102K-T
C4145 4030006860 S.CER C1608 JB 1H 102K-T
C4146 4030006860 S.CER C1608 JB 1H 102K-T
C4147 4030006860 S.CER C1608 JB 1H 102K-T
C4148 4030006860 S.CER C1608 JB 1H 102K-T
C4149 4030006860 S.CER C1608 JB 1H 102K-T
C4150 4030006860 S.CER C1608 JB 1H 102K-T
C4151 4030006860 S.CER C1608 JB 1H 102K-T
C4152 4030006860 S.CER C1608 JB 1H 102K-T
C4153 4030006860 S.CER C1608 JB 1H 102K-T
C4155 4550006220 S.TAN TEESVA 0J 156M8L
C4156 4030006860 S.CER C1608 JB 1H 102K-T
C4158 4030006860 S.CER C1608 JB 1H 102K-T
C4159 4030009510 S.CER C1608 CH 1H 010B-T
C4160 4030009520 S.CER C1608 CH 1H 020B-T
C4161 4030009570 S.CER C1608 CH 1H 0R3B-T
C4162 4030009510 S.CER C1608 CH 1H 010B-T
C4163 4030007070 S.CER C1608 CH 1H 330J-T
C4164 4030010070 S.CER C1608 CH 1H 104J-T
J4002 6450001300 CNR HEC0779-010030
J4003 6450000130 CNR HSJ1102-01-540
J4004 6450001060 CNR HSJ1493-01-010
J4005 6510007090 CNR PI28A-04M
J4006 6510017720 S.CNR IL-FPR-30S-VF-E1500
W4001 7030003860 S.RES ERJ3GE JPW V
W4002 7030003860 S.RES ERJ3GE JPW V
W4003 7030003860 S.RES ERJ3GE JPW V
W4004 7030003860 S.RES ERJ3GE JPW V
W4005 7030003860 S.RES ERJ3GE JPW V
W4006 7030003860 S.RES ERJ3GE JPW V
W4007 7120000380 JMP JPW 01 R-01
W4011 8900005320 FFC OPC-519 (N:30 L:55)
W4012 7030003860 S.RES ERJ3GE JPW V
W4013 7030003860 S.RES ERJ3GE JPW V
W4015 7030003860 S.RES ERJ3GE JPW V
EP4002 8950004480 TUB SR tube 2.9 X 4 CP (L=1M) [USA-1] only
[RF UNIT]
[RF UNIT]
S.=Surface mount
IC5001 1110003490 S.IC TA31136FN (D,EL)
IC5002 1130005640 S.IC TC4W53F (TE12L)
IC5003 1110002330 IC TA7368P
IC5004 1110003670 S.IC BA3308F-E2
IC5005 1130007650 S.IC TC75W51FU (TE12L)
IC5006 1180002250 S.IC S-812C50AMC-C3E-T2
IC5007 1110002860 S.IC TA75S393F (TE85R)
IC5008 1130004200 S.IC TC4S66F (TE85R)
Q5002 1530002600 S.TR 2SC4215-O (TE85R)
Q5003 1530002600 S.TR 2SC4215-O (TE85R)
Q5004 1530003280 S.TR 2SC4211-6-TL
Q5005 1530003280 S.TR 2SC4211-6-TL
Q5006 1520000650 S.TR 2SB1201-S-TL
Q5007 1530003280 S.TR 2SC4211-6-TL
Q5008 1590003270 S.TR UNR9210J-(TX)
Q5009 1590003270 S.TR UNR9210J-(TX)
Q5010 1540000520 S.TR 2SD1819A (TX) R [AUS], [UK], [USA-1] only
Q5013 1590001980 S.TR XP4315 (TX)
Q5014 1520000460 S.TR 2SB1132 T100 R
Q5015 1530003280 S.TR 2SC4211-6-TL
Q5016 1520000460 S.TR 2SB1132 T100 R
Q5017 1530003280 S.TR 2SC4211-6-TL
Q5018 1590003410 S.TR UNR9110J-(TX)
Q5019 1520000460 S.TR 2SB1132 T100 R
Q5020 1530003280 S.TR 2SC4211-6-TL
Q5026 1530003280 S.TR 2SC4211-6-TL
Q5027 1510000880 S.TR 2SA1622-6-TL
Q5028 1520000460 S.TR 2SB1132 T100 R
Q5029 1590003280 S.TR UNR9211J-(TX)
Q5030 1530002600 S.TR 2SC4215-O (TE85R)
Q5031 1540000520 S.TR 2SD1819A (TX) R [AUS], [UK], [USA-1] only
D5003 1790001280 S.DIO MA111 (TX)
D5005 1790001280 S.DIO MA111 (TX)
[MAIN UNIT]
REF ORDER
DESCRIPTION
NO. NO.
5 - 2
