R5049 7030003270 S.RES ERJ3GEYJ 390 V (39
Ω
)
R5050 7030003580 S.RES ERJ3GEYJ 153 V (15 k
Ω
)
R5051 7030003800 S.RES ERJ3GEYJ 105 V (1 M
Ω
)
R5052 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) [AUS], [UK]
7030003690 S.RES ERJ3GEYJ 124 V (120 k
Ω
) [IC-A3], [EUR], [EUR-1]
R5053 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
)
R5054 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
)
R5055 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
)
R5058 7030003630 S.RES ERJ3GEYJ 393 V (39 k
Ω
)
R5059 7030003630 S.RES ERJ3GEYJ 393 V (39 k
Ω
)
R5060 7030003630 S.RES ERJ3GEYJ 393 V (39 k
Ω
)
R5061 7030003400 S.RES ERJ3GEYJ 471 V (470
Ω
)
R5062 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
)
R5063 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
)
R5064 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
)
R5065 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
)
R5066 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
)
R5070 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k
Ω
)
R5071 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k
Ω
)
R5072 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
)
R5074 7030003650 S.RES ERJ3GEYJ 563 V (56 k
Ω
)
R5075 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
)
R5076 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k
Ω
)
R5077 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
)
R5078 7030003630 S.RES ERJ3GEYJ 393 V (39 k
Ω
)
R5082 7210002670 VAR RV-298 (TP96D00N15F10KB10KA)
R5083 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
)
R5084 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
)
R5085 7030003600 S.RES ERJ3GEYJ 223 V (22 k
Ω
)
R5086 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
)
R5087 4610001530 S.TRI EVM-1XSX50 B13 (102) [IC-A3], [EUR], [UK]
7310004590 S.TRI EVM-2WSX80 B13 (102) [EUR-1], [AUS]
R5088 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
)
R5089 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
)
R5090 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
)
R5091 7030003620 S.RES ERJ3GEYJ 333 V (33 k
Ω
)
R5092 7030000170 S.RES MCR10EZHJ 18
Ω
(180)
R5093 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
)
R5097 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
)
R5098 7310003660 S.TRI EVM-1XSX50 B55 (504) [IC-A3], [EUR], [UK]
7310004670 S.TRI EVM-2WSX80 B55 (504) [EUR-1], [AUS]
R5099 7030003760 S.RES ERJ3GEYJ 474 V (470 k
Ω
)
R5100 7030003760 S.RES ERJ3GEYJ 474 V (470 k
Ω
)
R5101 7030003720 S.RES ERJ3GEYJ 224 V (220 k
Ω
)
R5102 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
)
R5103 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k
Ω
)
R5104 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k
Ω
)
R5105 7030003700 S.RES ERJ3GEYJ 154 V (150 k
Ω
)
R5106 7030003730 S.RES ERJ3GEYJ 274 V (270 k
Ω
) [IC-A3], [EUR], [EUR-1]
7030003880 S.RES ERJ3GEYJ 244 V (240 k
Ω
) [AUS], [UK]
R5107 7030003700 S.RES ERJ3GEYJ 154 V (150 k
Ω
)
R5108 7030003460 S.RES ERJ3GEYJ 152 V (1.5 k
Ω
)
R5112 7030003700 S.RES ERJ3GEYJ 154 V (150 k
Ω
) [AUS], [UK]
7030003720 S.RES ERJ3GEYJ 224 V (220 k
Ω
) [IC-A3], [EUR], [EUR-1]
R5113 7030003600 S.RES ERJ3GEYJ 223 V (22 k
Ω
) [AUS], [UK]
7030003620 S.RES ERJ3GEYJ 333 V (33 k
Ω
) [IC-A3], [EUR], [EUR-1]
R5114 7310003630 S.TRI EVM-1XSX50 BQ4 (473) [IC-A3], [EUR], [UK]
7310004540 S.TRI EVM-2WSX80 BQ4 (473) [EUR-1], [AUS]
R5115 7030003590 S.RES ERJ3GEYJ 183 V (18 k
Ω
) [AUS], [UK]
7030003600 S.RES ERJ3GEYJ 223 V (22 k
Ω
) [IC-A3], [EUR], [EUR-1]
R5116 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
)
R5117 7030003340 S.RES ERJ3GEYJ 151 V (150
Ω
)
R5118 7030003760 S.RES ERJ3GEYJ 474 V (470 k
Ω
)
R5120 7510000960 S.TMR TBPS1R104K475H5Q [IC-A3], [EUR], [EUR-1]
7510001000 S.TMR TBPS1R154K475H5Q [AUS], [UK]
R5121 7030003710 S.RES ERJ3GEYJ 184 V (180 k
Ω
) [IC-A3], [EUR], [EUR-1]
7030003760 S.RES ERJ3GEYJ 474 V (470 k
Ω
) [AUS], [UK]
R5123 7510000970 S.TMR TBPS1R472K440H5Q
R5124 7030003460 S.RES ERJ3GEYJ 152 V (1.5 k
Ω
)
R5125 7030003710 S.RES ERJ3GEYJ 184 V (180 k
Ω
)
R5126 7030003710 S.RES ERJ3GEYJ 184 V (180 k
Ω
)
R5127 7030003740 S.RES ERJ3GEYJ 334 V (330 k
Ω
) [IC-A3]
7030003800 S.RES ERJ3GEYJ 105 V (1 M
Ω
) [AUS], [UK]
7030003840 S.RES ERJ3GEYJ 225 V (2.2 M
Ω
) [EUR], [EUR-1]
R5128 7030003660 S.RES ERJ3GEYJ 683 V (68 k
Ω
)
R5129 7030003650 S.RES ERJ3GEYJ 563 V (56 k
Ω
) [AUS], [UK]
R5130 7030003770 S.RES ERJ3GEYJ 564 V (560 k
Ω
) [AUS], [UK]
C5001 4030006980 S.CER C1608 CH 1H 070D-T
C5002 4030007030 S.CER C1608 CH 1H 150J-T
C5003 4030011600 S.CER C1608 JB 1E 104K-T
C5004 4030006900 S.CER C1608 JB 1H 103K-T
C5005 4030006860 S.CER C1608 JB 1H 102K-T
C5006 4030006900 S.CER C1608 JB 1H 103K-T
C5007 4030006900 S.CER C1608 JB 1H 103K-T
C5008 4030006900 S.CER C1608 JB 1H 103K-T
C5010 4030006870 S.CER C1608 JB 1H 222K-T
C5011 4030006900 S.CER C1608 JB 1H 103K-T
C5012 4030006860 S.CER C1608 JB 1H 102K-T
5 - 8
[MAIN UNIT]
REF ORDER
DESCRIPTION
NO. NO.
IC5001 1110003490 S.IC TA31136FN (D,EL)
IC5002 1130005640 S.IC TC4W53F (TE12L)
IC5003 1110002330 IC TA7368P
IC5004 1110003670 S.IC BA3308F-E2
IC5005 1130007650 S.IC TC75W51FU (TE12L)
IC5006 1180001170 S.IC S-81250SG-QD-T1 [IC-A3], [EUR], [UK]
1180002250 S.IC S-812C50AMC-C3E-T2 [EUR-1], [AUS]
IC5007 1110002860 S.IC TA75S393F (TE85R)
IC5008 1130004200 S.IC TC4S66F (TE85R)
Q5002 1530002600 S.TR 2SC4215-O (TE85R)
Q5003 1530002600 S.TR 2SC4215-O (TE85R)
Q5004 1530003280 S.TR 2SC4211-6-TL
Q5005 1530003280 S.TR 2SC4211-6-TL
Q5006 1520000650 S.TR 2SB1201-S-TL
Q5007 1530003280 S.TR 2SC4211-6-TL
Q5008 1590001140 S.TR UN9210 (TX)
Q5010 1530003280 S.TR 2SC4211-6-TL [IC-A3], [EUR], [EUR-1]
1540000520 S.TR 2SD1819A (TX) R [AUS], [UK]
Q5013 1590001980 S.TR XP4315 (TX)
Q5014 1520000460 S.TR 2SB1132 T100 R
Q5015 1530003280 S.TR 2SC4211-6-TL
Q5016 1520000460 S.TR 2SB1132 T100 R
Q5017 1530003280 S.TR 2SC4211-6-TL
Q5018 1590001130 S.TR UN9110 (TX)
Q5019 1520000460 S.TR 2SB1132 T100 R
Q5020 1530003280 S.TR 2SC4211-6-TL
Q5026 1530003280 S.TR 2SC4211-6-TL
Q5027 1510000880 S.TR 2SA1622-6-TL
Q5028 1520000460 S.TR 2SB1132 T100 R
Q5029 1590001150 S.TR UN9211 (TX)
Q5030 1530002600 S.TR 2SC4215-O (TE85R)
Q5031 1530003280 S.TR 2SC4211-6-TL [IC-A3], [EUR], [EUR-1]
1540000520 S.TR 2SD1819A (TX) R [AUS], [UK]
D5003 1790001280 S.DIO MA111 (TX)
D5005 1790001280 S.DIO MA111 (TX)
D5006 1790001280 S.DIO MA111 (TX)
D5007 1790001280 S.DIO MA111 (TX)
D5008 1790001280 S.DIO MA111 (TX)
D5009 1790000860 S.DIO MA133 (TX)
D5010 1790001280 S.DIO MA111 (TX)
D5011 1790001330 S.ZEN MA8036-L (TX)
D5013 1790001280 S.DIO MA111 (TX)
D5014 1790001280 S.DIO MA111 (TX)
D5015 1790000860 S.DIO MA133 (TX) [AUS], [UK] only
FI5001 2020001070 CER CFWLA455KDFA-B0 (CFWS455D)
X5001 6050008880 XTL CR-458 (35.345106 MHz)
X5002 6070000130 DCR CDBLB455KCAY24-B0 (CDBM455C24)
R5001 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k
Ω
)
R5008 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
)
R5009 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k
Ω
)
R5010 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
)
R5011 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
)
R5012 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k
Ω
)
R5013 7030003730 S.RES ERJ3GEYJ 274 V (270 k
Ω
)
R5014 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
)
R5015 7030003720 S.RES ERJ3GEYJ 224 V (220 k
Ω
)
R5016 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
)
R5017 7030003740 S.RES ERJ3GEYJ 334 V (330 k
Ω
)
R5018 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
)
R5020 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
)
R5021 7030003630 S.RES ERJ3GEYJ 393 V (39 k
Ω
)
R5023 7030003310 S.RES ERJ3GEYJ 820 V (82
Ω
)
R5024 7030003200 S.RES ERJ3GEYJ 100 V (10
Ω
)
R5025 7030003420 S.RES ERJ3GEYJ 681 V (680
Ω
)
R5026 7030003400 S.RES ERJ3GEYJ 471 V (470
Ω
)
R5027 7030003590 S.RES ERJ3GEYJ 183 V (18 k
Ω
)
R5029 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
)
R5030 7030003650 S.RES ERJ3GEYJ 563 V (56 k
Ω
) [AUS], [UK]
7030003660 S.RES ERJ3GEYJ 683 V (68 k
Ω
) [IC-A3], [EUR], [EUR-1]
R5031 7030003650 S.RES ERJ3GEYJ 563 V (56 k
Ω
)
R5035 7030003460 S.RES ERJ3GEYJ 152 V (1.5 k
Ω
)
R5036 7030003400 S.RES ERJ3GEYJ 471 V (470
Ω
)
R5037 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
)
R5043 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
)
R5044 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) [IC-A3], [EUR], [EUR-1]
7030003540 S.RES ERJ3GEYJ 682 V (6.8 k
Ω
) [AUS], [UK]
7030003510 S.RES ERJ3GEYJ 392 V (3.9 k
Ω
) [Others]
R5045 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
)
R5047 7310003610 S.TRI EVM-1XSX50 B14 (103) [IC-A3], [EUR], [UK]
7310004530 S.TRI EVM-2WSX80 B14 (103) [EUR-1], [AUS]
[MAIN UNIT]
REF ORDER
DESCRIPTION
NO. NO.
S.=Surface mount
