Icom IC-A5 Service Manual

6 - 2
S.=Surface mount
R84 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
[A23] only
R85 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ)
[A23] only
R86 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
[A23] only
R87 7510000980 S.THERMISTOR TBPS1R333K460H5Q [A23] only
R88 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
[A23] only
R89 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
[A23] only
R90 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
[A23] only
R91 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ)
[A23] only
R93 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ)
[A23] only
R94 7030003790 S.RESISTOR ERJ3GEYJ 824 V (820 kΩ)
[A23] only
R95 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
[A23] only
R96 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
[A23] only
R98 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R100 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R101 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R102 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R103 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R104 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R107 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R108 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R109 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R110 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R111 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R112 7030003840 S.RESISTOR ERJ3GEYJ 225 V (2.2 MΩ)
R113 7030003690 S.RESISTOR ERJ3GEYJ 124 V (120 kΩ)
R558 7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ)
[A23] only
R559 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
[A5] only
R560 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ) [A5] only
R561 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R562 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R563 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R564 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
C1 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C2 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C4 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C5 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C6 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C7 4030009650 S.CERAMIC C1608 CH 1H 240J-T-A
C8 4030007060 S.CERAMIC C1608 CH 1H 270J-T-A
C9 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C10 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C11 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C12 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C13 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C18 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C19 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C20 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C22 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C23 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C24 4030008880 S.CERAMIC C1608 JB 1C 223K-T-A
C25 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C26 4550006690 S.TANTALUM ECST1AC476R
C27 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C28 4550006350 S.TANTALUM TEMSVB2 1A 226M-8L
C29 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C31 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C33 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C34 4550006690 S.TANTALUM ECST1AC476R
C35 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C37 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C42 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C43 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C44 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C45 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C47 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C48 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C49 4550005980 S.TANTALUM TEMSVA 1A 475M-8L
C50 4030008920 S.CERAMIC C1608 JB 1C 473K-T-A
C51 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C52 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C53 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C59 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C65 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C66 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C86 4030008860 S.CERAMIC C1608 JB 1C 153K-T-A
C87 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C88 4550006310 S.TANTALUM ECST1AX156R
C89 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C90 4550006250 S.TANTALUM TEMSVA 1A 106M-8L
C91 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C92 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C93 4030012600 S.CERAMIC C2012 JB 1A 105M-T-A
C98 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C99 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C100 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C101 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A [A23] only
C102 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A [A23] only
C103 4550006250 S.TANTALUM TEMSVA 1A 106M-8L [A23] only
C104 4550006150 S.TANTALUM ECST1CY105R [A23] only
C105 4550006250 S.TANTALUM TEMSVA 1A 106M-8L [A23] only
C106 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A [A23] only
C107 4030011600 S.CERAMIC C1608 JB 1C 104KT-N [A23] only
C108 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A [A23] only
C109 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A [A23] only
C110 4550000530 S.TANTALUM TESVA 1V 104M1-8L [A23] only
C111 4550003080 S.TANTALUM TEMSVA 1A 335M-8L [A23] only
C112 4550000530 S.TANTALUM TESVA 1V 104M1-8L [A23] only
C113 4550000530 S.TANTALUM TESVA 1V 104M1-8L [A23] only
C114 4550000530 S.TANTALUM TESVA 1V 104M1-8L [A23] only
C115 4550000530 S.TANTALUM TESVA 1V 104M1-8L [A23] only
C116 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A [A23] only
C117 4550000530 S.TANTALUM TESVA 1V 104M1-8L [A23] only
C118 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A [A23] only
C119 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A [A23] only
C120 4550006350 S.TANTALUM TEMSVB2 1A 226M-8L [A23] only
C121 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A [A23] only
C122 4030011600 S.CERAMIC C1608 JB 1C 104KT-N [A23] only
C123 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C125 4550006250 S.TANTALUM TEMSVA 1A 106M-8L [A23] only
C126 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C127 4550006140 S.TANTALUM ECST1EY474R
C128 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C129 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C130 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C131 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C135 4550006250 S.TANTALUM TEMSVA 1A 106M-8L
C136 4550006250 S.TANTALUM TEMSVA 1A 106M-8L
C137 4030012600 S.CERAMIC C2012 JB 1A 105M-T-A
C138 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C139 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C140 4550006250 S.TANTALUM TEMSVA 1A 106M-8L
C600 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A [A23] only
C601 4030009660 S.CERAMIC C1608 JF 1C 224Z-T-A
J1 6510019860 S.CONNECTOR AXK6S40645P
DS1 5030001860 LCD TTR3845-UPFDCN
DS2 5010000160 S.LED LNJ310M6URA
DS3 5010000160 S.LED LNJ310M6URA
DS4 5010000150 S.LED LT1EP53A
DS5 5010000120 S.LED LN1371G-(TR)
DS6 5010000120 S.LED LN1371G-(TR)
DS7 5010000120 S.LED LN1371G-(TR)
DS8 5010000120 S.LED LN1371G-(TR)
DS9 5010000120 S.LED LN1371G-(TR)
DS10 5010000120 S.LED LN1371G-(TR)
MC1 7700002310 MICROPHONE EM-140
W10 7030003860 S.JUMPER ERJ3GE JPW V
EP1 0910052883 PCB B 5512C
EP2 8930052880 LCD CONTACT SRCN-2378-SP-N-W
REF ORDER
DESCRIPTION
NO. NO.
[LOGIC UNIT]
REF ORDER
DESCRIPTION
NO. NO.
[LOGIC UNIT]
