Icom IC-E90 Service Manual

5 - 2
to [MIC]
to the antenna connector
RF power meter
0.1 10 W/50
Frequency
counter
Attenuator
40 dB or 50 dB
FM
deviation meter
Standard signal generator
0.1 V to 32 mV
( 127 dBm to 17 dBm)
Audio generator
CAUTION:
DO NOT transmit while
an SSG is connected to
the antenna connector.
Optional SMA BNC adaptor
1/8" (3.5 mm)
3-conductor plug
68 k
+
to [SP] jack
Power supply
11 V / 3 A
JIG
AD-92SMA
• CONNECTION
