6 - 4
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT]
REF PARTS
DESCRIPTION M.
H/V
NO. NO.
LOCATION
C276 4030016950 S.CER ECJ0EB1A473K T 12.6/34.4
C277 4030016930 S.CER ECJ0EB1A104K T 12.6/37.8
C278 4030017430 S.CER ECJ0EC1H101J T 16.4/39.9
C279 4030018910 S.CER C1608 JB 0J 475K-T T 36.8/21.6
C280 4030018110 S.CER ECJ0EB1H272K T 21.1/27.8
C281 4030017780 S.CER ECJ0EB1E472K T 17.7/26.8
C282 4030017710 S.CER ECJ0EC1H181J T 17.7/29.8
C283 4030018900 S.CER ECJ0EB0J474K T 19.4/31.7
C284 4030016930 S.CER ECJ0EB1A104K T 22.9/39.1
C285 4030016930 S.CER ECJ0EB1A104K T 22.9/40.1
C286 4030017460 S.CER ECJ0EB1E102K B 16.6/41.2
C287 4550006250 S.TAN TEESVA 1A 106M8R B 22.1/40.7
C288 4030017460 S.CER ECJ0EB1E102K B 18.6/39.5
C289 4030016930 S.CER ECJ0EB1A104K B 19.5/30.2
C290 4030017920 S.CER ECJ0EB1A683K T 27.5/16.1
C291 4030016780 S.CER ECJ0EB1C153K T 25.7/10.9
C292 4030016930 S.CER ECJ0EB1A104K T 25.7/13.9
C293 4030017740 S.CER ECJ0EB1E821K T 25.7/11.9
C294 4030016930 S.CER ECJ0EB1A104K T 23.9/13.9
C295 4030018110 S.CER ECJ0EB1H272K T 29/5.1
C296 4030018240 S.CER ECJ0EB1E562K T 29/6.1
C297 4030017710 S.CER ECJ0EC1H181J T 27.1/7.1
C298 4030018090 S.CER ECJ0EB1C822K T 30.8/7.1
C299 4030017510 S.CER ECJ0EC1H680J T 30.8/5.1
C300 4030017450 S.CER ECJ0EB1E271K T 18.4/39.9
C304 4030017460 S.CER ECJ0EB1E102K B 57.7/11.4
C305 4030017460 S.CER ECJ0EB1E102K T 11.3/24.3
C306 4030017460 S.CER ECJ0EB1E102K B 61.7/12
C307 4030017460 S.CER ECJ0EB1E102K B 61.7/10.2
C308 4030017460 S.CER ECJ0EB1E102K T 75.7/9.8
C309 4030017460 S.CER ECJ0EB1E102K B 75.5/11.3
C310 4030016930 S.CER ECJ0EB1A104K T 21.3/11.9
C311 4030017460 S.CER ECJ0EB1E102K B 65.4/8.7
C312 4030017420 S.CER ECJ0EC1H470J B 74.5/6.1
C313 4030017420 S.CER ECJ0EC1H470J B 33.9/7.8
C314 4030017460 S.CER ECJ0EB1E102K T 86.6/3.3
C315 4030017460 S.CER ECJ0EB1E102K T 93.2/5.9
C316 4030016930 S.CER ECJ0EB1A104K T 91.6/2.8
C317 4550007080 S.TAN TEESVA 1C 106M8R B 93/11.3
C318 4030016930 S.CER ECJ0EB1A104K T 90.4/10.1
C319 4030016930 S.CER ECJ0EB1A104K T 89.6/3.7
C320 4030017730 S.CER ECJ0EB1E471K T 88.6/3.7
C321 4030017460 S.CER ECJ0EB1E102K B 19.3/4.2
C322 4030016950 S.CER ECJ0EB1A473K T 94/14
C323 4030016950 S.CER ECJ0EB1A473K T 88.1/10.1
C324 4030017420 S.CER ECJ0EC1H470J T 85.2/14.1
C325 4550006250 S.TAN TEESVA 1A 106M8R T 89.4/17.6
C326 4510008900 S.ELE EEEFC0J101P B 87.8/8.9
C335 4030018860 S.CER ECJ0EB0J105K B 54.6/22.6
C339 4030016930 S.CER ECJ0EB1A104K B 5.9/17.2
C340 4030016930 S.CER ECJ0EB1A104K B 9.3/12.5
C341 4030016930 S.CER ECJ0EB1A104K B 5.9/10.1
C342 4030017630 S.CER ECJ0EC1H120J B 18.3/4.2
C343 4030017580 S.CER ECJ0EC1H060C B 5.6/4.2
C344 4030017640 S.CER ECJ0EC1H150J B 7.6/9.1
C345 4030016930 S.CER ECJ0EB1A104K B 11/11.2
C346 4030016930 S.CER ECJ0EB1A104K B 11/10.1
C347 4030016790 S.CER ECJ0EB1C103K T 8.9/6.3
C348 4030016930 S.CER ECJ0EB1A104K T 6/10
C349 4030016930 S.CER ECJ0EB1A104K T 21.3/14.9
C350 4030017460 S.CER ECJ0EB1E102K T 59.4/43.4
J1 6510021901 S.CNR BM02B-ASRS-TF (LF) (SN) T 86.6/6.8
J2 6450001680 CNR HSJ1122-010010
J3 6450002250 CNR HSJ1456-010320
J4 6510018430 S.CNR AXN330C038P B 11.8/30.6
J5 6510021901 S.CNR BM02B-ASRS-TF (LF) (SN)
[RUS-02], [RUS-05] only T 50.4/11.7
F1 5210000830 S.FUS ERBFE3R00U T 98/14.8
DS1 5040002670 S.LED CL-165HR/YG T 102.8/12.4
MC1 7700002750 MIC EM9745P-38-G <HOR>
S1 2260002840 SW SKHLLFA010
S2 2260002800 S.SW SW-167 (SKQTLAE010) B 99.4/44.2
S3 2260002800 S.SW SW-167 (SKQTLAE010) B 60.9/44.2
S4 2250000490 ECR TP70TF5163-15.9F-2775
[16CH] only
EP2 6910015600 S.BEA ACZ1005Y-241 (240) T 77.4/22.2
EP3 6910015370 S.BEA ACZ1005Y-102-T T 34.7/32
EP4 6910015370 S.BEA ACZ1005Y-102-T B 55.5/30.5
EP6 6910015370 S.BEA ACZ1005Y-102-T T 44.3/35.9
S.=Surface mount
[CONNECT UNIT]
REF PARTS
DESCRIPTION M.
H/V
NO. NO.
LOCATION
C501 4030017460 S.CER ECJ0EB1E102K T 8.3/5.3
C502 4030016930 S.CER ECJ0EB1A104K T 9.3/5.3
J501 6910016390 CNR IMSA-9230B-1-02Z145-PT1
