Apr. 2012
Eqv.= This component is equivalent to the REF No. component listed above, and
may be substituted on parts orders and repairs.
5
REF PARTS
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
J5 6510021901 S.CON BM02B-ASRS-TF(LF)(SN) [I] T 50.4/11.7
6510021901 S.CON BM02B-ASRS-TF(LF)(SN) [J]
6510021901 S.CON BM02B-ASRS-TF(LF)(SN) [K]
6510021901 S.CON BM02B-ASRS-TF(LF)(SN) [L]
6510021901 S.CON BM02B-ASRS-TF(LF)(SN) [M]
6510021901 S.CON BM02B-ASRS-TF(LF)(SN) [N]
F1 5210001160 S.FUS ERBRE3R00V T 98.0/14.8
DS1 5040002670 S.LED CL-165HR/YG T 102.8/12.4
MC1 7700002750 MIC EM9745P-38-G <HOR>
S1 2260001900 SWI SW-149 (SKHLLD)
S2 2260002800 S.SWI SW-167 (SKQTLAE010) B 99.5/44.3
S3 2260002800 S.SWI SW-167 (SKQTLAE010) B 61.0/44.3
S4 2250000490 ENC TP70TF5163-15.9F-2775 [A]
2250000490 ENC TP70TF5163-15.9F-2775 [B]
2250000490 ENC TP70TF5163-15.9F-2775 [C]
2250000490 ENC TP70TF5163-15.9F-2775 [D]
2250000490 ENC TP70TF5163-15.9F-2775 [E]
2250000490 ENC TP70TF5163-15.9F-2775 [F]
2250000490 ENC TP70TF5163-15.9F-2775 [G]
2250000490 ENC TP70TF5163-15.9F-2775 [H]
2250000490 ENC TP70TF5163-15.9F-2775 [P]
2250000490 ENC TP70TF5163-15.9F-2775 [O]
EP2 6910015600 S.BEA ACZ1005Y-241 (240) T 77.4/22.2
EP3 6910015370 S.BEA ACZ1005Y-102-T T 34.7/32.0
EP4 6910015370 S.BEA ACZ1005Y-102-T B 55.5/30.5
EP6 6910015370 S.BEA ACZ1005Y-102-T T 44.3/35.9
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
To Next Page
