Icom IC-F2721/D Service Manual

SECTION 6 PARTS LIST
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[FRONT-A UNIT] (for IC-F2700 series)
[FRONT-A UNIT] (for IC-F2700 series)
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
R48 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 74.9/29.4
R49 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 75.8/29.6
R50 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 76.7/29.9
R51 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 77.6/30.2
R52 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 78.5/29.9
R55 7510001470 S.TMR NTCG20 4AG 473JT B 82.3/25.3
R56 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 80.8/26.7
R57 7030003810 S.RES ERJ3GEYJ 125 V (1.2 M
Ω
) B 57.9/33.2
R58 7030003810 S.RES ERJ3GEYJ 125 V (1.2 M
Ω
) B 54.2/29.8
R59 7310005130 S.TRI RH03ADCS5X (470 k
Ω
) B 55/32.2
R60 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 14.5/10.7
R61 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 19.7/8.6
R62 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 21.3/8.6
R63 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) B 26.8/4.7
R64 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) B 26.5/10.2
R65 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) B 28.2/9.3
R66 7030009290 S.RES ERJ2GEJ 562 X (5.6 k
Ω
) B 29.9/9.3
R67 7030009280 S.RES ERJ2GE 331 X (330
Ω
) B 24.7/10.2
R68 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
) B 24.7/9.3
R69 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 81.9/33.3
R70 7410001130 S.ARY EXB28V102JX B 65.2/19.9
R71 7410001130 S.ARY EXB28V102JX B 65.6/17
R72 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 83.7/27.6
R73 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 21.8/30.1
R74 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 21.7/13.3
R75 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 51.1/23.4
R76 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 73/30.1
R77 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 18.1/8.6
C10 4030016930 S.CER ECJ0EB1A104K B 81.7/19
C11 4030017030 S.CER ECJ0EB1A273K B 82.4/32
C12 4030017630 S.CER ECJ0EC1H120J B 83.4/21.8
C13 4030017580 S.CER ECJ0EC1H060C B 83.4/19.9
C14 4030017640 S.CER ECJ0EB1H150J B 83.4/18.1
C15 4030016930 S.CER ECJ0EB1A104K B 81/13.4
C16 4030016790 S.CER ECJ0EB1C103K B 82.7/23.6
C17 4030016930 S.CER ECJ0EB1A104K B 81.1/23.3
C18 4030017420 S.CER ECJ0EC1H470J B 100.7/8.8
C28 4030017460 S.CER ECJ0EB1E102K B 60/26
C30 4030016930 S.CER ECJ0EB1A104K B 79.9/8.1
C31 4030017460 S.CER ECJ0EB1E102K B 90/5.9
C33 4030017460 S.CER ECJ0EB1E102K B 11.1/21.1
C35 4030017420 S.CER ECJ0EC1H470J B 91.5/4.7
C36 4030017460 S.CER ECJ0EB1E102K B 23.8/30.1
C37 4030017420 S.CER ECJ0EC1H470J B 7.8/9.4
C38 4030017420 S.CER ECJ0EC1H470J B 88.7/11.2
C39 4030017460 S.CER ECJ0EB1E102K B 96.1/10.7
C41 4030017420 S.CER ECJ0EC1H470J B 94.2/11.5
C42 4030017420 S.CER ECJ0EC1H470J B 13.2/25.2
C43 4030017460 S.CER ECJ0EB1E102K B 23.9/15
C44 4030017420 S.CER ECJ0EC1H470J B 90.5/11.2
C45 4030018860 S.CER ECJ0EB0J105K B 14.5/9.7
C46 4030017420 S.CER ECJ0EC1H470J B 92/12.8
C47 4030017420 S.CER ECJ0EC1H470J B 17.6/15.2
C48 4030017460 S.CER ECJ0EB1E102K B 29.1/15.3
C49 4030016790 S.CER ECJ0EB1C103K B 25/17.7
C50 4550006540 S.TAN ECST1CY475R B 24.8/20.8
C51 4030017460 S.CER ECJ0EB1E102K B 11.7/18.8
C52 4030017420 S.CER ECJ0EC1H470J B 24.2/12
C53 4030004760 S.CER C2012 JF 1H 104Z-T B 83.2/5.9
C54 4510006120 S.ELE ECEV1ES4R7SR B 75.3/6.6
C55 4030004760 S.CER C2012 JF 1H 104Z-T B 85.1/5.9
C56 4030006900 S.CER C1608 JB 1H 103K-T B 78/7.7
C57 4550006050 S.TAN TEESVA 0J 106M8L B 82.2/10.3
C58 4030017730 S.CER ECJ0EB1E471K B 101.9/14
C59 4030017730 S.CER ECJ0EB1E471K B 100.1/14
C60 4030016930 S.CER ECJ0EB1A104K B 80.8/27.6
C61 4030016930 S.CER ECJ0EB1A104K B 52.8/34.1
C62 4030016930 S.CER ECJ0EB1A104K B 51.2/33.7
C63 4030016930 S.CER ECJ0EB1A104K B 51.2/32.8
C64 4030016930 S.CER ECJ0EB1A104K B 51.1/31.6
C65 4030016930 S.CER ECJ0EB1A104K B 52/31.6
C66 4030017490 S.CER C1608 JB 1A 105K-T B 51.6/26.3
C67 4030017490 S.CER C1608 JB 1A 105K-T B 51.6/24.8
C68 4030017460 S.CER ECJ0EB1E102K B 50.7/21.7
C69 4030017460 S.CER ECJ0EB1E102K B 87.9/5.9
C70 4030017460 S.CER ECJ0EB1E102K B 26.5/12.9
C71 4030017460 S.CER ECJ0EB1E102K B 22.2/9.5
C72 4510004630 S.ELE ECEV1CA100SR B 20.3/5.7
C73 4550006050 S.TAN TEESVA 0J 106M8L B 29.7/6.2
C74 4030016930 S.CER ECJ0EB1A104K B 26.5/9.3
C75 4030016930 S.CER ECJ0EB1A104K B 28.2/8.3
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
IC2 1110005770 S.IC S-80942CNMC-G9C-T2 B 81.9/29.8
IC3 1140010770 S.IC HD64F3687FP B 73.5/21.4
IC4 1130005720 S.IC TC7W04F (TE12L) B 63.1/28.7
IC5 1130008560 S.IC TC75S51F (TE85L) B 26.9/15.7
IC6 1110005350 S.IC NJM2870F05-TE1 B 80.4/5.9
IC7 1130009120 S.IC SED1526F0A B 40.6/21.1
IC8 1130005640 S.IC TC4W53F (TE12L) B 18.2/11.9
IC9 1110005310 S.IC AN6123MS B 25.3/6.9
Q1 1590001330 S.TR DTA114EUA T106 B 59.8/34.9
Q2 1590000680 S.TR DTC114EUA T106 B 63.9/24.2
Q3 1530002850 S.TR 2SC4116-BL (TE85R) B 67.7/8.9
Q4 1590001050 S.TR DTC114TUA T106 B 70.6/8.9
Q5 1590001050 S.TR DTC114TUA T106 B 70.1/11.4
Q6 1590001050 S.TR DTC114TUA T106 B 100.3/12.1
Q7 1590001050 S.TR DTC114TUA T106 B 102.9/12.1
D1 1790000620 S.DIO MA77 (TX) B 82.2/15.3
D4 1790001250 S.DIO MA2S111-(TX) B 60/31.3
D5 1790000950 S.ZEN MA8056-M (TX) B 22.7/28.7
D6 1790000950 S.ZEN MA8056-M (TX) B 22.7/32.6
D7 1790000950 S.ZEN MA8056-M (TX) T 19.3/16
D8 1750000550 S.DIO 1SS355 TE-17 B 86.7/12.6
D9 1750000130 S.DIO DA204U T106 B 59.1/9.9
D10 1750000130 S.DIO DA204U T106 B 56.5/9.9
D11 1750000130 S.DIO DA204U T106 B 52.4/9.6
D12 1790001250 S.DIO MA2S111-(TX) B 69.6/29.5
X1 6050011720 S.XTL CR-764 (19.6608 MHz) B 86.6/20.5
L1 6200003640 S.COL MLF1608E 100K-T B 12.3/9.7
R4 7030008010 S.RES ERJ2GEJ 123 X (12 k
Ω
) B 83.4/13.4
R5 7030008010 S.RES ERJ2GEJ 123 X (12 k
Ω
) B 82.9/16.7
R6 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) B 82.4/20.8
R7 7030008010 S.RES ERJ2GEJ 123 X (12 k
Ω
) B 81.1/17
R8 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) B 81.1/20.8
R9 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 53.5/21.1
R12 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 59.5/29.6
R14 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 62.3/32
R15 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 59.8/27.2
R16 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
) B 59.5/33
R18 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) B 61.3/25.2
R19 7030009280 S.RES ERJ2GE 331 X (330
Ω
) B 67.3/10.6
R20 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 18.6/14.6
R21 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 21.8/31.2
R22 7030009140 S.RES ERJ2GEJ 272 X (2.7 k
Ω
) B 67.8/11.6
R24 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 28.3/17.9
R25 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) B 26.5/11.1
R26 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) B 24.8/16.5
R28 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) B 26.5/12
R29 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 26.7/17.9
R30 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 17.6/16.1
R31 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 12.1/21.1
R32 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 11.7/19.7
R33 7030009160 S.RES ERJ2GEJ 181 X (180
Ω
) B 50.9/4.8
R34 7030009160 S.RES ERJ2GEJ 181 X (180
Ω
) B 65.1/8.5
R35 7210003050 VAR EVU-F2KFK3 B14 (10KB)
R36 7030009160 S.RES ERJ2GEJ 181 X (180
Ω
) B 64.1/8.4
R37 7030009160 S.RES ERJ2GEJ 181 X (180
Ω
) B 63.2/8.9
R38 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 86.9/11.2
R39 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 88.6/13.9
R40 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 51.7/6.9
R41 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 54.4/8.8
R42 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 60.6/7.8
R43 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 97.6/12.6
R44 7030005010 S.RES ERJ2GEJ 681 X (680
Ω
) B 104.8/12.5
R47 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 83.4/34.2
S.=Surface mount
[REPLACEMENT UNITS]
ORDER NO. UNIT NAME
0327810101
0327811102
U F1721 #01 FRONT-A
[F2721/D], [F2710]
U F1821 #11 FRONT-B
[F2821/D], [F2810]
6 - 1
