Functions Programmable to Keys
24
USER SET MODE KEY “SET”
➥Push and hold to enter user set mode.
•
During user set mode, push this key to select an item,
and change the value or condition using push [CH
Up]/[CH Down].
➥Push and hold this key again to exit user set mode.
User set mode is also available via the ‘Power ON
function.’
OPT OUT KEYS “OP1”
“OP2”
“OP3”
Push to control the output signal level of the optional
ports in the optional unit connector.
OPT MOMENTARY KEYS “O1M”
“O2M”
“O3M”
Push and hold to control the output signal level of the
optional ports in the optional unit connector.
DIGITAL BUTTON KEY “BIFN”
(BIIS operation only)
➥ Push to select the call ID list, transmit message and
standby condition. Toggles between queue channel and
received message record indication after queue channel
is selected.
➥ Push and hold to select queue channel indication.
STATUS UP/DOWN KEYS “BIUP”
“BIDN”
(BIIS operation only)
➥While in the standby condition, push to display the
transmit status indication and select a status number.
➥When a received SDM is displayed, push to cancel the
automatic scroll and scroll the message manually.
➥When an SDM that contains more than 12 characters
is displayed, push to scroll the message manually.
¾ Setting example for BIIS operation
The following functions are assigned to each
programmable key for display example. However, the
assigned function can be changed by your dealer. Ask
your dealer for details.
[P0]; Call : Push to transmit a 5-tone/BIIS call
when the selected channel is a 5-tone or BIIS channel.
•
“CALL”
is displayed on the key indicator.
[P1]; Digital Button : Push to select the call list
ID/transmit message, or to display the receive message
record for selection.
•
“BIFN”
is displayed on the key indicator. When
this key is pushed, “BIFN”
is inverted as “
.”
[P2]; Null : No function is assigned.
[P3]; TX Code Enter : Push to enter the ID code edit
mode directly for both 5-tone and BIIS.
•
“TXCE”
is displayed on the key indicator.
[Emer]; Null : No function is assigned.
[Side1]; Moni(Audi) : Push this key after the
communication to send a ‘Clear down’
signal during BIIS
channel operation.
[Side2]/[Side3]; CH Up/Down
: While in the standby condition, selects the
operating channel. After pushing [Digital Button] or [TX
Code CH Select], selects call list or TX code channel,
respectively.
