3-2
Cloning Software CS-F3060
3-2-1
Basic Setup of Cloning Software
26
Getting started
o This cloning software is designed to perform data
setting and cloning for the IC-F3060/IC-F4060 series
VHF/UHF PORTABLE TRANSCEIVERS.
o HELP WINDOW: CS-F3060 has a help window to
describe functions and operation.
System requirements
To use this program, the following hardware and
software are required:
PC
•
Microsoft®
Windows®
98/98SE/Me/2000/XP is
installed
•
With RS-232C serial port (D-sub 9-pin) or USB port
Other items
•Optional OPC-966 CLONING CABLE (RS-232C type) or
OPC-966U* CLONING CABLE (USB type)
&NOTE:
When using the OPC-966U*, USB type cloning cables,
USB driver installation is necessary. The driver is
supplied with the OPC-966U*. See the OPC-966U*
instruction manual for the installation details.
*The USB driver, supplied with the OPC-966U, is not supported
for Microsoft®
Windows®
98.
Software installation
1.Quit all applications when Windows is running.
2.Insert the CD into the appropriate CD drive.
3.Double-click the “Setup.exe”
contained in the CD.
4.The “Welcome to the InstallShield Wizard for CS-
F3060”
will appear as below. Click [Next>].
1.
The “User Information”
will appear as below, then
type your name, your company name and the
product ID number with the following manner. Then
click [Next >].
•
ID number: 289701-(6 digit serial number)
•
e.g. the serial number on the CD is 000001, enter
“289701-000001”
as the ID number.
1.
The “Choose Destination Location”
will appear as
below. Then click [Next>] to install the software to
the destination folder. (e.g. C:\Program
Files\Icom\CS-F3060)
•
Click [Browse...] to select another destination folder
before clicking [Next >], if desired.
1.
After the installation is completed, the “InstallShield
Wizard Complete”
will appear as below. Then click
[Finish].
1.
Eject the CD.
2.
Program group ‘CS-F3060’
appears in the ‘Programs’
folder of the start menu, and ‘CS-F3060’
short cut
icon appears on the desktop screen.
Note 1: Icom distributes cloning software by CD or license. Depending on this, some information here may not apply as
written, e.g. ID number.
Note 2: Please see other documents provided by Icom regarding to
Microsoft
®
Windows Vista™.
