2 - 1
SECTION 2
.
INSIDE VIEWS
• FRONT UNIT
(BOTTOM VIEW)
CPU
(IC51)
EEPROM
(IC52)
LCD DRIVER
(IC6)
MIC AMP
(IC7)
LIGHT CTRL
(Q5)
CLOCK FREQUENCY
SHIFT DIODE
(D60)
DIM CTRL
(Q1)
DIM CTRL
(Q2)
