Icom IC-F33GS Service Manual

S.=Surface mount
6 - 4
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
C240 4030017460 S.CER ECJ0EB1E102K B 56.8/29.8
C241 4030017460 S.CER ECJ0EB1E102K B 60.1/14.9
C242 4030017460 S.CER ECJ0EB1E102K B 64.8/8.4
C302 4030016790 S.CER ECJ0EB1C103K T 71.7/31
C303 4030017460 S.CER ECJ0EB1E102K T 74.8/34
C308 4550007090 S.TAN TEESVA 1A 226M8R B 33.8/10.5
C309 4030017490 S.CER C1608 JB 1A 105K-T B 35.8/15.4
C310 4030017490 S.CER C1608 JB 1A 105K-T B 33.3/15.1
C312 4030016780 S.CER ECJ0EB1C153K B 52.3/17.8
C314 4030017740 S.CER ECJ0EB1E821K B 55.2/18.7
C315 4030017330 S.CER ECJ0EF1C104Z B 49.2/20.6
C316 4030017420 S.CER ECJ0EC1H470J B 57.4/19.1
C317 4030017770 S.CER ECJ0EB1E332K B 59/21.7
C318 4030017690 S.CER ECJ0EC1H121J B 57.3/28.5
C319 4030017760 S.CER ECJ0EB1H222K B 58.9/23.8
C320 4030017460 S.CER ECJ0EB1E102K B 60.6/26.9
C321 4030017460 S.CER ECJ0EB1E102K T 91.1/3.1
C322 4030017420 S.CER ECJ0EC1H470J T 100.1/18.6
C323 4030016950 S.CER ECJ0EB1A473K T 94.5/20.4
C324 4550007110 S.TAN SY6-1A107M-RC B 99.4/16.5
C325 4550006250 S.TAN TEESVA 1A 106M8L T 101.4/15.8
C326 4550007080 S.TAN TEESVA 1C 106M8R T 92.9/16.9
C327 4030017330 S.CER ECJ0EF1C104Z T 93.8/13.6
C328 4030017460 S.CER ECJ0EB1E102K T 87.7/20.3
C329 4030017460 S.CER ECJ0EB1E102K T 87.7/21.3
C330 4030017330 S.CER ECJ0EF1C104Z T 92.9/21.1
C331 4030017460 S.CER ECJ0EB1E102K T 101.7/12.4
C332 4030017460 S.CER ECJ0EB1E102K T 82.9/3.7
C333 4550007040 S.TAN ECST0JZ106R T 81.5/4
C334 4030017330 S.CER ECJ0EF1C104Z T 75.7/5.4
C335 4030018870 S.CER ECJ0EF0J105Z B 40/32.9
C336 4030017730 S.CER ECJ0EB1E471K B 40/36.9
C337 4030017490 S.CER C1608 JB 1A 105K-T T 96.4/7.9
C338 4030017330 S.CER ECJ0EF1C104Z B 34.5/20.7
C339 4030016790 S.CER ECJ0EB1C103K B 32.6/18
C340 4030017330 S.CER ECJ0EF1C104Z B 9.6/16.5
C345 4030017330 S.CER ECJ0EF1C104Z B 19/34.9
C346 4030017600 S.CER ECJ0EC1H080C B 27.5/26.4
C347 4030017640 S.CER ECJ0EC1H150J B 27.4/36
C348 4030017400 S.CER ECJ0EC1H220J B 26.6/28
C349 4030017330 S.CER ECJ0EF1C104Z B 26/31.5
C350 4030017330 S.CER ECJ0EF1C104Z B 27.3/33
C351 4030017330 S.CER ECJ0EF1C104Z B 27.4/35
C352 4030017030 S.CER ECJ0EB1A273K B 23.8/41.5
C353 4030016930 S.CER ECJ0EB1A104K B 14/32
C354 4030016790 S.CER ECJ0EB1C103K B 30.8/18
C355 4030017460 S.CER ECJ0EB1E102K B 51.5/7.6
C356 4030017330 S.CER ECJ0EF1C104Z B 15.4/4
C357 4030018560 S.CER C2012 JB 1A 475K-T B 25.9/38.4
C359 4030017330 S.CER ECJ0EF1C104Z B 21.6/38.3
C360 4030017330 S.CER ECJ0EF1C104Z B 49.8/26.5
C368 4030017460 S.CER ECJ0EB1E102K T 94.8/38
C369 4030017430 S.CER ECJ0EC1H101J B 94.6/41.3
C371 4030017330 S.CER ECJ0EF1C104Z B 45.9/32.5
C375 4030017460 S.CER ECJ0EB1E102K T 86/18
C376 4030017460 S.CER ECJ0EB1E102K T 86/17
C377 4030017460 S.CER ECJ0EB1E102K B 30.4/8.7
C378 4030017460 S.CER ECJ0EB1E102K B 37.9/44.2
C379 4030017460 S.CER ECJ0EB1E102K T 84.1/3.7
C380 4030017330 S.CER ECJ0EF1C104Z B 36.8/33.6
C384 4030018100 S.CER ECJ0EB1H681K T 61.7/15.4
C386 4030017330 S.CER ECJ0EF1C104Z T 58.6/13.3
C387 4030017330 S.CER ECJ0EF1C104Z T 59.8/13.3
C388 4030017330 S.CER ECJ0EF1C104Z T 60.9/14.1
C390 4030017420 S.CER ECJ0EC1H470J T 80.7/29.8
C393 4030017330 S.CER ECJ0EF1C104Z T 77.8/16.1
C394 4030017330 S.CER ECJ0EF1C104Z T 78.2/17.4
C398 4030016930 S.CER ECJ0EB1A104K T 67/32.4
C399 4550007120 S.TAN F92 1D 224MPA T 67.4/34.1
C400 4030016930 S.CER ECJ0EB1A104K T 67.3/22.7
C401 4030018860 S.CER ECJ0EB0J105K T 67.3/23.6
C402 4030017460 S.CER ECJ0EB1E102K T 92.9/19.9
C404 4030016790 S.CER ECJ0EB1C103K B 59.1/35.3
C405 4030017460 S.CER ECJ0EB1E102K B 39.4/42.9
C406 4030016930 S.CER ECJ0EB1A104K B 52.3/19.5
C407 4030017460 S.CER ECJ0EB1E102K T 95.9/2.9
C408 4030017460 S.CER ECJ0EB1E102K T 100.9/4.2
C409 4030017460 S.CER ECJ0EB1E102K B 16.6/32.9
C411 4030016930 S.CER ECJ0EB1A104K B 18.6/32.4
C412 4030017420 S.CER ECJ0EC1H470J T 78.4/3.1
C413 4030018110 S.CER ECJ0EB1H272K T 74.8/17.1
C414 4030018870 S.CER ECJ0EF0J105Z B 34.5/34.2
C500 4030017610 S.CER ECJ0EC1H090C B 68.3/30.1
C503 4030017610 S.CER ECJ0EC1H090C B 68.8/28.2
C504 4030017360 S.CER ECJ0EC1H030B B 68/27
C505 4030017360 S.CER ECJ0EC1H030B B 69.2/24.5
C506 4030017580 S.CER ECJ0EC1H060C T 79.9/28.3
C507 4030017350 S.CER ECJ0EC1H020B T 76.9/27.4
C508 4030017380 S.CER ECJ0EC1H050B T 77.7/28.6
C509 4030016930 S.CER ECJ0EB1A104K B 92/33.2
C510 4550007040 S.TAN ECST0JZ106R T 89.1/7.6
C511 4030016790 S.CER ECJ0EB1C103K B 88.8/38.8
C512 4030016930 S.CER ECJ0EB1A104K T 73.9/34
C515 4030017660 S.CER ECJ0EC1H330J B 56.6/41
J2 6450002250 CNR HSJ1456-010320
J3 6450001680 CNR HSJ1122-010010
J4 6510021900 S.CNR BM02B-ASRS-TF T 88.1/4.5
J5 6510018430 S.CNR AXN330C038P B 15.2/9.8
J6 6510024390 S.CNR IMSA-6176S-03Y900 B 88.2/8.8
DS1 5010000160 S.LED LNJ310M6URA T 57.3/6
DS2 5010000160 S.LED LNJ310M6URA T 57.3/39.4
DS3 5030002760 LCD L3-0200HAY-3
MC1 7700002480 MIC SKB-2746 LPC
S1 2230001060 S.SW EVQ-PUL 02K T 102.2/38.1
S2 2260002840 SW SKHLLFA010
S3 2260002800 S.SW SW-167 (SKQTLAE010) B 61.1/44.2
S4 2260002800 S.SW SW-167 (SKQTLAE010) B 51.6/44.2
S5 2260002800 S.SW SW-167 (SKQTLAE010) B 99.6/44.2
S27 2250000180 ECR EC10SP16-47
EP3 6910015370 S.BEA ACZ1005Y-102-T B 59.4/36.9
EP4 6910015370 S.BEA ACZ1005Y-102-T B 37.4/19
EP5 6910015370 S.BEA ACZ1005Y-102-T B 31.9/8.5
EP7 8930063020 LCT SRCN-2721-SP-N-W
EP10 0910058442 PCB B 6194B
EP11 6910015370 S.BEA ACZ1005Y-102-T T 78/11.7
