2 - 1
SECTION 2
.
INSIDE
VIEWS
TX/RX INDICA
T
OR LED DRIVERS
(Q13 and Q14)
• FRONT UNIT
CPU
(IC1)
RESET IC
(IC2)
EEPROM
(IC3)
T
ONE FIL
TER
(IC5)
T
ONE FIL
TER SWITCH
(Q3)
CLOCK FREQUENCY
SHIFT DIODE
(D6)
CPU CLOCK
(X1)
KEY BA
CKLIGHT SW
(Q2)
KEY BA
CKLIGHT DRIVER
(Q1)
5
7
