8 - 2
160 ( )
161 ( )
45 (1
25
/
32
)
149.1 ( )
15 (
5
19
/
32
7
/
8
6
15
/
16
6
15
/
16
)
Unit: mm (inch)
FRONT UNIT
J1 (C)
MP1 (C)
MP10 (C)
MAIN UNIT
Black
Red
Unit abbreviations;
(C) : CHASSIS PARTS
(F) : FRONT UNIT
(M) : MAIN UNIT
(CN) : CONNECTOR UNIT
MP501 (F)
SP501 (F)
MP505 (F)
MP506 (F)
MP510 (F)
DS501 (F)
EP502 (F)
MP503 (F)
MP507 (F)
R546 (F)
J503 (F)
MP508 (F)
MP516 (F)
W501 (F)
MP517 (F)
MP2 (C)
MP4 (F)
CONNECTOR UNIT
W601 (CN)
MP13 (C)
J602 (CN)
J602 (CN)
MP14 (C)
IC15 (M)
MP11 (C)
J7 (M)
W2 (M)
EP5 (M)
EP4 (M)
MP9 (C)
MP5 (M)
MP6 (M)
MP9 (C)
MP4 (M)
MP3 (C)
MP9 (C)
MP13 (C)×4
MP13 (C)
MP2 (M)
MP1 (M)
MP9 (C)
MP8 (C)
MP9 (C)
MP9 (C)
