7 - 1
SECTION 7 PARTS LIST
IC2 1110002751 S.IC TA75S01F(TE85RF) T 60/54.9
IC3 1150002423 IC RA60H1317M1A-222
IC4 1110007320 S.IC NJM2591V-TE1-#ZZZB T 57.8/24.7
IC5 1110006230 S.IC NJM2711F-TE1-#ZZZB T 36.0/26.9
IC6 1110002751 S.IC TA75S01F(TE85RF) B 59.9/17.4
IC7 1130011741 S.IC TC7W66FK(TE85LF) T 85.8/12.3
IC8 1130015270 S.IC AK1541P-L B 78.2/23.7
IC1001 1180003660 S.REG XC6408EN22PR-G B 96.9/10.8
IC1002 1180003500 S.REG NJM7808DL1A-TE1-#FZZB T 123.3/45.7
IC1004 1110002751 S.IC TA75S01F(TE85RF) B 119.7/13.0
IC1005 1110007630 S.IC NJM2783V-TE1-#ZZZH T 47.4/18.9
IC1006 1110007290 S.IC AK2330P-L B 53.7/11.5
IC1007 1110005320 S.IC NJM13403V-TE1-#ZZZB B 37.4/17.0
IC1008 1130009981 S.IC TC7W53FK(TE85LF) T 40.3/19.7
IC1009 1110003091 IC LA4425A-E
IC2001 1180003680 S.REG TPS62204DBVR B 35.1/6.5
IC2002 1190002900 S.IC ADS7886SDCKR B 14.8/9.3
IC2006 1110007770 S.IC PCM3008T/2K T 16.3/8.3
IC2007 1140013290 S.IC TMS320VC5509AZHH T 18.0/18.4
IC2008 1130015620 S.IC EN25Q40-100GIP <MSK> B 12.5/25.3
IC2009 1110006230 S.IC NJM2711F-TE1-#ZZZB B 26.7/12.7
Q1 1590004090 S.TRA LDTC114YET1G <SLVJ> B 47.2/27.1
Q2 1530002851 S.TRA 2SC4116-BL(TE85RF) T 107.8/33.4
Q3 1560000541 S.FET 2SK880-Y(T5RICOMF) T 77.2/24.5
Q4 1530002851 S.TRA 2SC4116-BL(TE85RF) B 67.9/25.4
Q5 1530002851 S.TRA 2SC4116-BL(TE85RF) T 41.6/26.2
Q6 1530002921 S.TRA 2SC4226-T1 Y25 (R25) B 100.6/25.8
Q7 1530002921 S.TRA 2SC4226-T1 Y25 (R25) B 105.4/32.9
Q8 1590004090 S.TRA LDTC114YET1G <SLVJ> T 103.6/36.6
Q9 1560001360 S.FET 2SK3019 TL T 52.2/26.3
Q10 1590004500 S.TRA DMC561040R T 101.2/34.2
Q11 1530003260 S.TRA 2SC5006-T1 B 97.4/31.0
Q12 1530003260 S.TRA 2SC5006-T1 B 100.7/32.8
Q13 1590004090 S.TRA LDTC114YET1G <SLVJ> B 57.6/27.2
Q14 1530003311 S.TRA 2SC5107-O(TE85RF) T 64.8/24.9
Q15 1530003260 S.TRA 2SC5006-T1 B 93.8/33.8
Q17 1530003340 S.TRA 2SC3357-T1 RF B 88.5/55.2
Q18 1590004090 S.TRA LDTC114YET1G <SLVJ> T 81.5/40.8
Q19 1580000731 S.FET 3SK293(TE85LF) B 71.3/38.4
Q20 1580000731 S.FET 3SK293(TE85LF) B 41.5/38.7
Q21 1530002851 S.TRA 2SC4116-BL(TE85RF) [USA-01] T 60.0/49.8
1530002851 S.TRA 2SC4116-BL(TE85RF) [EXP-02]
Q22 1560000841 S.FET 2SK1829(TE85RF) T 33.7/39.7
Q23 1590004090 S.TRA LDTC114YET1G <SLVJ> T 62.7/50.3
Q24 1590004090 S.TRA LDTC114YET1G <SLVJ> T 49.5/24.8
Q1001 1590004090 S.TRA LDTC114YET1G <SLVJ> T 110.6/44.1
Q1003 1550000190 S.FET 2SJ506STR-E T 115.3/45.4
Q1004 1590004090 S.TRA LDTC114YET1G <SLVJ> T 114.0/26.7
Q1005 1590004090 S.TRA LDTC114YET1G <SLVJ> T 114.0/24.7
Q1007 1590004090 S.TRA LDTC114YET1G <SLVJ> B 116.3/8.1
Q1008 1590000990 S.TRA DTC363EK T146 B 128.9/17.8
Q1009 1590001451 S.FET 2SJ144-GR (TE85RF) B 113.8/11.1
Q1010 1590004090 S.TRA LDTC114YET1G <SLVJ> B 116.1/10.9
Q1011 1540000550 S.TRA 2SD1664 T100Q B 125.1/47.6
Q1012 1590004090 S.TRA LDTC114YET1G <SLVJ> B 130.9/20.7
Q1013 1510000920 S.TRA 2SA1577 T106 Q T 107.7/44.3
Q1014 1520000460 S.TRA 2SB1132 T100 R B 123.5/21.1
Q1015 1590001190 S.TRA XP6501-(TX).AB B 118.9/20.4
Q1016 1590004090 S.TRA LDTC114YET1G <SLVJ> T 107.8/39.2
Q1017 1520000460 S.TRA 2SB1132 T100 R T 120.1/35.2
Q1018 1590004090 S.TRA LDTC114YET1G <SLVJ> B 126.4/43.3
Q1019 1590001190 S.TRA XP6501-(TX).AB B 123.8/35.8
Q1020 1590004090 S.TRA LDTC114YET1G <SLVJ> T 42.6/22.5
Q1021 1590004090 S.TRA LDTC114YET1G <SLVJ> B 126.4/41.3
D2 1750001910 S.DIO HVD144AKRF-E T 7/17.1
D3 1750001910 S.DIO HVD144AKRF-E B 17.7/10.6
D4 1750000771 S.VAR HVC376BTRF-E B 93.9/22.2
D5 1750000771 S.VAR HVC376BTRF-E B 91.4/22.2
D6 1750000771 S.VAR HVC376BTRF-E B 105.6/23.2
D7 1750000771 S.VAR HVC376BTRF-E B 107.2/22.1
D8 1750001910 S.DIO HVD144AKRF-E B 43.4/27.3
D9 1750001910 S.DIO HVD144AKRF-E B 43.4/28.6
D10 1750001570 S.VAR HVL355CMKRF-E B 104.1/25.8
D11 1750000721 S.VAR HVC375BTRF-E B 99.7/22.1
D12 1750000721 S.VAR HVC375BTRF-E B 103.0/28.1
D13 1750001910 S.DIO HVD144AKRF-E T 68.3/28.1
D14 1750001910 S.DIO HVD144AKRF-E T 69.5/28.1
D15 1750001890 S.DIO HVD142AKRF-E B 83.4/41.8
D16 1750001890 S.DIO HVD142AKRF-E B 83.2/39.3
D17 1750001910 S.DIO HVD144AKRF-E T 70.6/41.6
D18 1750001910 S.DIO HVD144AKRF-E T 74.5/41.6
D21 1750001780 S.VAR HVB350BYPTL-E B 55.1/41.1
D24 1750002060 S.DIO RN752TE-21 T 35.1/56.8
D25 1750001890 S.DIO HVD142AKRF-E [EUR-01] T 21.7/51.8
1750001890 S.DIO HVD142AKRF-E [EXP-01]
D26 1750001890 S.DIO HVD142AKRF-E [EUR-01] T 21.7/53.0
1750001890 S.DIO HVD142AKRF-E [EXP-01]
D27 1750001820 S.DIO LRB706F-40T1G <SLVJ> B 42.0/58.2
D28 1750002060 S.DIO RN752TE-21 [USA-01] T 24.4/54.7
1750002060 S.DIO RN752TE-21 [EXP-02]
D29 1750001820 S.DIO LRB706F-40T1G <SLVJ> B 21.8/54.2
D30 1790001241 S.DIO MA2S7280GL T 31.8/39.7
D31 1750000721 S.VAR HVC375BTRF-E B 33.3/38.3
D32 1750001890 S.DIO HVD142AKRF-E B 25.3/46.8
REF PARTS
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
D34 1750000370 S.DIO DA221 TL T 33.7/37.1
D35 1750001820 S.DIO LRB706F-40T1G <SLVJ> B 8.2/49.9
D37 1750000721 S.VAR HVC375BTRF-E B 30.5/38.3
D1002 1790000700 DIO DSA3A1
D1003 1750000370 S.DIO DA221 TL B 114.0/8.2
D1004 1750000370 S.DIO DA221 TL B 114.1/6.1
D1005 1750000370 S.DIO DA221 TL T 113.2/7.4
D1006 1750000370 S.DIO DA221 TL T 113.0/10.3
D1007 1750001810 S.DIO L1SS400T1G <SLVJ> B 129.0/20.7
D1008 1750000370 S.DIO DA221 TL B 124.0/43.3
D2002 1790001241 S.DIO MA2S7280GL T 24.9/18.0
D2003 1790001241 S.DIO MA2S7280GL B 10.7/30.5
D2004 1790001241 S.DIO MA2S7280GL B 22.2/20.8
D2005 1790001241 S.DIO MA2S7280GL B 17.5/26.3
D2006 1790001241 S.DIO MA2S7280GL T 12.0/25.3
FI1 2020002570 CER LTM450HW <JJE>
FI2 2020002410 CER LTM450FW <JJE>
FI3 2020002610 S.CER LTUCG450G <JJE> B 32.8/27.0
FI4 2030000870 S.MON MFT46.3P3 46.350 MHz (FL-442) T 66.9/34.9
FI5 2010002760 S.XTA MFT46.3J 46.350 MHz (FL-448) T 75.8/34.9
FI6 2040001440 S.LC NFE31PT152Z1E9L
(NFM60R20T152) [USA-01] B 97.7/64.9
2040001440 S.LC NFE31PT152Z1E9L
(NFM60R20T152) [EXP-02]
FI7 2040001440 S.LC NFE31PT152Z1E9L
(NFM60R20T152) B 97.7/61.5
FI8 2040001440 S.LC NFE31PT152Z1E9L
(NFM60R20T152) B 97.7/58.1
X1 6070000310 S.DIS JTBM450CX70 <JJE> B 51.4/22.5
X2 6050013000 S.XTA CR-892 TTS14VSB-A8 15.3 MHz B 71.5/21.0
X2001 6050013170 S.XTA CR-914 TTS18VSE-A11
12.288 MHz B 27.0/18.2
L1 6200007850 S.COI ELJNC R82K-F B 94.3/19.7
L2 6200002001 S.COI NLV25T-3R3J B 104.0/19.9
L3 6200012760 S.COI 0.35-1.6-7TL 37.5N <COMO> B 91.5/19.7
L4 6200005550 S.COI ELJFC 100K-F B 96.8/19.7
L5 6200013020 S.COI 0.25-1.9-7TL 61N <COMO> B 107.0/20.0
L6 6200003640 S.COI MLF1608E 100K-T B 106.8/24.6
L7 6200009910 S.COI C6342A-88NG-A B 93.6/26.2
L8 6200013020 S.COI 0.25-1.9-7TL 61N <COMO> B 107.0/28.7
L9 6200012170 S.COI MLG1608S R18J-T B 65.8/24.7
L10 6200002001 S.COI NLV25T-3R3J T 97.4/19.5
L11 6200002190 S.COI MLF2012A 4R7K-T T 102.8/24.5
L12 6200012170 S.COI MLG1608S R18J-T B 62.3/22.4
L13 6200007901 S.COI ELJRF 22NJFB T 85.1/32.1
L14 6200007120 S.COI ELJND 1R0J T 100.1/31.1
L15 6200011001 S.COI ELJRF 56NJFB B 95.8/31.0
L16 6200007871 S.COI ELJRF 39NJFB B 99.0/34.3
L17 6200011021 S.COI ELJRF 82NJFB B 92.7/35.3
L19 6200007001 S.COI ELJRE 82NGFA B 85.9/59.3
L20 6200010090 S.COI ELJND R82JF B 68.1/40.6
L21 6200005741 S.COI ELJRE 47NGFA [EUR-01] B 88.6/59.3
6200005741 S.COI ELJRE 47NGFA [EXP-01]
L24 6200006981 S.COI ELJRE R10GFA B 73.5/38.5
L25 6200010720 S.COI C2520C-56NG-A B 58.9/40.5
L26 6200010050 S.COI AS080547-47N B 38.7/64.5
L27 6200010420 S.COI FHW1210HC 1R0JGT <JJE> T 39.5/57.9
L28 6200010720 S.COI C2520C-56NG-A B 49.0/39.8
L29 6200010050 S.COI AS080547-47N T 30.0/51.1
L30 6200010050 S.COI AS080547-47N B 25.4/58.6
L31 6200010940 S.COI C2520C-39NG-A B 26.7/49.7
L32 6200011410 S.COI C2520C-82NG-A B 35.6/38.3
L33 6200010050 S.COI AS080547-47N B 12.7/56.4
L34 6200010000 S.COI C2012C-56NG-A B 24.8/44.8
L35 6200010050 S.COI AS080547-47N B 9.4/62.7
L36 6200011410 S.COI C2520C-82NG-A B 28.2/39.9
L1001 6200004660 S.COI MLF1608A 1R8K-T T 79.8/13.3
L2001 6200014160 S.COI VLCF4028T-100M1R0-2 T 35.9/7.6
L2002 6200007830 S.COI ELJFC 4R7K-F B 31.2/11.2
L2003 6200007830 S.COI ELJFC 4R7K-F T 29.6/6.2
R1 7030000620 S.RES MCR10EZHJ 100 K (104) B 17.4/64.6
R4 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 18.8/54.2
R5 7030005060 S.RES ERJ2GEJ 333 X (33K) [EUR-01] B 24.1/53.8
7030005060 S.RES ERJ2GEJ 333 X (33K) [EXP-01]
7030005720 S.RES ERJ2GEJ 563 X (56K) [USA-01]
7030005720 S.RES ERJ2GEJ 563 X (56K) [EXP-02]
R6 7030005060 S.RES ERJ2GEJ 333 X (33K) [EUR-01] B 11.2/49.6
7030005060 S.RES ERJ2GEJ 333 X (33K) [EXP-01]
7030005720 S.RES ERJ2GEJ 563 X (56K) [USA-01]
7030005720 S.RES ERJ2GEJ 563 X (56K) [EXP-02]
R7 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 8.2/53.2
R8 7030006070 S.RES ERJ12YJ101U (100) B 45.7/51.9
R9 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 38.6/58.6
R10 7030005060 S.RES ERJ2GEJ 333 X (33K) [EUR-01] B 44.8/57.9
7030005060 S.RES ERJ2GEJ 333 X (33K) [EXP-01]
7030005720 S.RES ERJ2GEJ 563 X (56K) [USA-01]
7030005720 S.RES ERJ2GEJ 563 X (56K) [EXP-02]
R11 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 31.9/38.4
R12 7030004980 S.RES ERJ2GEJ 101 X (100) B 39.2/39.5
R13 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 31.9/39.7
To Next Page
