S.=Surface mount
6 - 3
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
R47 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k
Ω
) B 105.6/55.9
R50 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 64.2/45.9
R52 7030003580 S.RES ERJ3GEYJ 153 V (15 k
Ω
) T 61.6/67.7
R53 7030004050 S.RES ERJ3GEYJ 1R0 V (1
Ω
) T 54.5/64.7
R54 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 58.4/70.3
R55 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) T 55.5/72.8
R56 7030003700 S.RES ERJ3GEYJ 154 V (150 k
Ω
) T 56.3/69.6
R57 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 58.9/72.2
R58 7030004050 S.RES ERJ3GEYJ 1R0 V (1
Ω
) T 53.7/70.9
R59 7030003690 S.RES ERJ3GEYJ 124 V (120 k
Ω
)
[25W] only T 59/67.7
R61 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) B 46.6/57.5
R63 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k
Ω
) [50W] T 50.4/64
7030003570 S.RES ERJ3GEYJ 123 V (12 k
Ω
) [25W] T 50.4/64
R64 7030003400 S.RES ERJ3GEYJ 471 V (470
Ω
)
[50W] only B 51.8/58.8
R65 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) B 51.7/56.9
R66 7030003510 S.RES ERJ3GEYJ 392 V (3.9 k
Ω
) B 53.1/63.9
R67 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 57/58.8
R68 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 54.9/56.2
R69 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) B 58.6/52.9
R70 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) T 63.2/45.8
R71 7030003400 S.RES ERJ3GEYJ 471 V (470
Ω
) T 62.6/42.5
R73 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) T 64.7/45.9
R74 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 64.8/40.6
R75 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 71.2/44.8
R76 7030003280 S.RES ERJ3GEYJ 470 V (47
Ω
) T 69.1/46.6
R77 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 73.4/31.6
R78 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 66.7/37.1
R79 7030005351 S.RES ERA3YED 182V T 59.4/36
R80 7030003410 S.RES ERJ3GEYJ 561 V (560
Ω
) [W/N] B 70.1/37
7030003430 S.RES ERJ3GEYJ 821 V (820
Ω
) [M/N] B 70.1/37
R83 7030005351 S.RES ERA3YED 182V T 68.5/35.8
R84 7030006571 S.RES ERA3YED 392V T 68.2/33.2
R85 7030006571 S.RES ERA3YED 392V T 59.4/33.4
R86 7030003690 S.RES ERJ3GEYJ 124 V (120 k
Ω
) B 61.4/26.7
R89 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 73.4/30.1
R90 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 66.2/24
R91 7030003620 S.RES ERJ3GEYJ 333 V (33 k
Ω
) B 71.3/23.3
R92 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 73.9/24
R93 7030003200 S.RES ERJ3GEYJ 100 V (10
Ω
) B 70.5/28.5
R94 7030003200 S.RES ERJ3GEYJ 100 V (10
Ω
) B 67/30.1
R95 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k
Ω
) B 73.4/33.4
R96 7030003380 S.RES ERJ3GEYJ 331 V (330
Ω
) B 78.2/39.8
R97 7030003600 S.RES ERJ3GEYJ 223 V (22 k
Ω
) B 76.9/39.7
R98 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k
Ω
) B 55.8/49.1
R100 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k
Ω
) B 81.3/27.7
R101 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 75.5/22.2
R102 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) B 85.7/36.9
R103 7030003470 S.RES ERJ3GEYJ 182 V (1.8 k
Ω
) B 80.5/37.2
R104 7030003450 S.RES ERJ3GEYJ 122 V (1.2 k
Ω
) B 93/42.2
R105 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) B 94.3/39.6
R106 7030003670 S.RES ERJ3GEYJ 823 V (82 k
Ω
) B 96.3/40.3
R107 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) B 105.5/36.7
R108 7030003650 S.RES ERJ3GEYJ 563 V (56 k
Ω
) B 109.9/37.7
R109 7410000800 S.ARY EXB-V8V 103JV (10 k
Ω
) T 89/38.8
R110 7030003280 S.RES ERJ3GEYJ 470 V (47
Ω
) B 99.1/42.2
R111 7030003600 S.RES ERJ3GEYJ 223 V (22 k
Ω
) T 99.2/20.3
R112 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 102.9/20.3
R113 7030003750 S.RES ERJ3GEYJ 394 V (390 k
Ω
) T 106.5/17.7
R115 7030003570 S.RES ERJ3GEYJ 123 V (12 k
Ω
) B 108.4/22.5
R116 7030003460 S.RES ERJ3GEYJ 152 V (1.5 k
Ω
) B 107.7/25.7
R117 7030003530 S.RES ERJ3GEYJ 562 V (5.6 k
Ω
) B 105.8/25.1
R118 7030003660 S.RES ERJ3GEYJ 683 V (68 k
Ω
) B 111.6/25.4
R119 7030003710 S.RES ERJ3GEYJ 184 V (180 k
Ω
) B 111.6/24.1
R120 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 116.6/24.1
R121 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 118.4/24.9
R122 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 115.8/26.2
R123 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) T 118.2/21.3
R124 7030003620 S.RES ERJ3GEYJ 333 V (33 k
Ω
) T 114.4/20.8
R125 7030003600 S.RES ERJ3GEYJ 223 V (22 k
Ω
) T 111/23.1
R126 7030003600 S.RES ERJ3GEYJ 223 V (22 k
Ω
) B 118.5/17.8
R127 7030003600 S.RES ERJ3GEYJ 223 V (22 k
Ω
) B 115.4/15.6
R128 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) T 111/21.7
R129 7030003760 S.RES ERJ3GEYJ 474 V (470 k
Ω
) T 109.1/17.7
R130 7030003610 S.RES ERJ3GEYJ 273 V (27 k
Ω
) B 105.8/19.9
R131 7030003660 S.RES ERJ3GEYJ 683 V (68 k
Ω
) T 104.6/17
R132 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) B 102.4/17.5
R133 7030003720 S.RES ERJ3GEYJ 224 V (220 k
Ω
) B 100.7/15.6
R134 7030003700 S.RES ERJ3GEYJ 154 V (150 k
Ω
) B 98.1/12.6
R135 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 100.7/11.5
R136 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) T 102.1/10.8
R137 7410000770 S.ARY EXB-V4V 102JV (1 k
Ω
) T 104.1/5.8
R138 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) T 27.7/15.8
R139 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) T 26.4/15.8
R140 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) T 25.1/15.8
R141 7410000750 S.ARY EXB-V4V 104JV (100 k
Ω
) B 21.7/7.6
R142 7410000750 S.ARY EXB-V4V 104JV (100 k
Ω
) B 24.5/10
R143 7410000750 S.ARY EXB-V4V 104JV (100 k
Ω
) T 45.8/17
R144 7410000750 S.ARY EXB-V4V 104JV (100 k
Ω
) T 41.8/7.8
R145 7410000750 S.ARY EXB-V4V 104JV (100 k
Ω
) T 43.9/7.8
R146 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 87.9/6
R147 7410000750 S.ARY EXB-V4V 104JV (100 k
Ω
) T 40.5/41.5
R148 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 39.2/30.9
R149 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 46/24
R151 7410000750 S.ARY EXB-V4V 104JV (100 k
Ω
) T 50/28.9
R152 7410000750 S.ARY EXB-V4V 104JV (100 k
Ω
) T 37/16.2
R153 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 49.1/30.6
R154 7410000750 S.ARY EXB-V4V 104JV (100 k
Ω
) B 23.1/41.1
R155 7410000750 S.ARY EXB-V4V 104JV (100 k
Ω
) B 23.4/46.2
R156 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) B 40.9/63.8
R157 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 41.4/18.7
R158 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 41.9/27
R159 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 15.2/54.6
R173 7030003800 S.RES ERJ3GEYJ 105 V (1 M
Ω
) B 22/14
R174 7030003800 S.RES ERJ3GEYJ 105 V (1 M
Ω
) B 23.3/12.7
R175 7030003800 S.RES ERJ3GEYJ 105 V (1 M
Ω
) B 25.4/13.4
R176 7030003740 S.RES ERJ3GEYJ 334 V (330 k
Ω
) B 27.3/14
R177 7030003740 S.RES ERJ3GEYJ 334 V (330 k
Ω
) B 27.3/12.7
R178 7030003740 S.RES ERJ3GEYJ 334 V (330 k
Ω
) B 27.3/11.4
R179 7030003620 S.RES ERJ3GEYJ 333 V (33 k
Ω
) B 109/20.6
R180 7030003530 S.RES ERJ3GEYJ 562 V (5.6 k
Ω
) B 111.6/19.3
R181 7030003660 S.RES ERJ3GEYJ 683 V (68 k
Ω
) B 100.4/31
R182 7030003660 S.RES ERJ3GEYJ 683 V (68 k
Ω
) B 96.8/30.9
R185 7030003620 S.RES ERJ3GEYJ 333 V (33 k
Ω
) B 106.3/31.7
R186 7030003630 S.RES ERJ3GEYJ 393 V (39 k
Ω
) B 105.8/29.8
R187 7030003650 S.RES ERJ3GEYJ 563 V (56 k
Ω
) B 110.3/30.9
R188 7030003590 S.RES ERJ3GEYJ 183 V (18 k
Ω
) B 110.3/28.3
R189 7030003610 S.RES ERJ3GEYJ 273 V (27 k
Ω
) B 110.3/29.6
R190 7030004040 S.RES ERJ3GEYJ 4R7 V (4.7
Ω
) B 108.4/29.2
R191 7030003720 S.RES ERJ3GEYJ 224 V (220 k
Ω
) B 20.5/56.8
R192 7030003720 S.RES ERJ3GEYJ 224 V (220 k
Ω
) B 19.8/54.9
R193 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 15.7/56.7
R194 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k
Ω
) B 21.2/59.5
R195 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 14.1/58.6
R196 7030003600 S.RES ERJ3GEYJ 223 V (22 k
Ω
) B 9.6/57.7
R197 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 8.3/54.7
R198 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 7/62.2
R199 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 3.6/89.6
R200 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 15.4/72.1
R201 7030003400 S.RES ERJ3GEYJ 471 V (470
Ω
) T 16.7/71.2
R202 7030000460 S.RES MCR10EZHJ 4.7 k
Ω
T 26.6/60.1
R203 7030000460 S.RES MCR10EZHJ 4.7 k
Ω
T 28.4/60.1
R204 7030000460 S.RES MCR10EZHJ 4.7 k
Ω
T 32/60.1
R205 7030000460 S.RES MCR10EZHJ 4.7 k
Ω
T 33.8/60.1
R206 7030003760 S.RES ERJ3GEYJ 474 V (470 k
Ω
) T 94.5/51.3
R207 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 96.4/50.5
R208 7030004040 S.RES ERJ3GEYJ 4R7 V (4.7
Ω
) T 91.1/50.1
R209 7510001470 S.TMR NTCG20 4AG 473JT B 91.8/35.4
R210 7030005871 S.RES ERA3YKD 104V (100 k
Ω
) B 92.4/38.3
R215 7030003510 S.RES ERJ3GEYJ 392 V (3.9 k
Ω
) T 96.3/27.3
R216 7030003620 S.RES ERJ3GEYJ 333 V (33 k
Ω
) T 96.3/28.8
R217 7030003610 S.RES ERJ3GEYJ 273 V (27 k
Ω
) T 33.8/38.2
R218 7030003610 S.RES ERJ3GEYJ 273 V (27 k
Ω
) B 37.8/43.5
R219 7030003600 S.RES ERJ3GEYJ 223 V (22 k
Ω
) T 110.6/32.8
R220 7030003620 S.RES ERJ3GEYJ 333 V (33 k
Ω
) T 106.8/35.3
R221 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 108.1/36.1
R222 7030003400 S.RES ERJ3GEYJ 471 V (470
Ω
) T 77.1/61.2
R223 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 10.3/29.3
R224 7030003280 S.RES ERJ3GEYJ 470 V (47
Ω
) B 13.8/26.8
R225 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 14/21.2
R226 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 12.9/31.9
R227 7030003800 S.RES ERJ3GEYJ 105 V (1 M
Ω
) B 15.3/30.6
R228 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 13.8/25.5
R229 7030003800 S.RES ERJ3GEYJ 105 V (1 M
Ω
) B 10.3/31.9
R230 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 111/20.3
R231 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) T 97/35.7
R233 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 117.4/22.2
R234 7030003550 S.RES ERJ3GEYJ 822 V (8.2 k
Ω
) T 61.9/44.4
R235 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 67.4/45.3
R236 7030003450 S.RES ERJ3GEYJ 122 V (1.2 k
Ω
) T 97.5/45.1
R237 7030003780 S.RES ERJ3GEYJ 684 V (680 k
Ω
) T 95.5/41.1
R238 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 88.7/6.3
R239 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 23.5/55.3
R240 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 90.8/22.6
R241 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 93.4/21.3
R242 7030003630 S.RES ERJ3GEYJ 393 V (39 k
Ω
) B 93.4/22.6
R243 7030003670 S.RES ERJ3GEYJ 823 V (82 k
Ω
) B 94.9/25.2
R244 7030003750 S.RES ERJ3GEYJ 394 V (390 k
Ω
) B 96.8/25.1
R245 7030003710 S.RES ERJ3GEYJ 184 V (180 k
Ω
) B 98.9/24.2
R246 7030003460 S.RES ERJ3GEYJ 152 V (1.5 k
Ω
) B 36.9/44.8
R247 7030003600 S.RES ERJ3GEYJ 223 V (22 k
Ω
) T 91.9/24.5
R248 7030003600 S.RES ERJ3GEYJ 223 V (22 k
Ω
) T 89.2/24.5
R249 7030003600 S.RES ERJ3GEYJ 223 V (22 k
Ω
) T 88.5/22.5
R250 7030003690 S.RES ERJ3GEYJ 124 V (120 k
Ω
) T 83.3/24.6
R251 7030003660 S.RES ERJ3GEYJ 683 V (68 k
Ω
) T 80.6/13.8
R252 7030003720 S.RES ERJ3GEYJ 224 V (220 k
Ω
) T 82.5/14.5
R253 7030003590 S.RES ERJ3GEYJ 183 V (18 k
Ω
) T 81.9/16.5
R254 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) T 80.7/17.9
R255 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) T 81.7/19.2
R256 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 84.2/25.7
R257 7030003760 S.RES ERJ3GEYJ 474 V (470 k
Ω
) T 80.8/25.1
R258 7030003400 S.RES ERJ3GEYJ 471 V (470
Ω
) B 40.1/44.4
R259 7030003650 S.RES ERJ3GEYJ 563 V (56 k
Ω
) B 37.8/42.2
R260 7030003740 S.RES ERJ3GEYJ 334 V (330 k
Ω
) T 117.4/41.9
R261 7030003600 S.RES ERJ3GEYJ 223 V (22 k
Ω
) T 115.5/41.2
To Next Page
Loading...
Need help?
General
