S.=Surface mount
6 - 4
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
R262 7030003590 S.RES ERJ3GEYJ 183 V (18 k
Ω
) T 115.5/38.6
R263 7030003720 S.RES ERJ3GEYJ 224 V (220 k
Ω
) T 113.6/39.4
R264 7030003490 S.RES ERJ3GEYJ 272 V (2.7 k
Ω
) T 115.1/34.7
R265 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) T 111.9/32.8
R266 7030003510 S.RES ERJ3GEYJ 392 V (3.9 k
Ω
) T 84.7/13
R267 7030003600 S.RES ERJ3GEYJ 223 V (22 k
Ω
) B 53.1/28.8
R268 7030003650 S.RES ERJ3GEYJ 563 V (56 k
Ω
) B 53.1/27.5
R269 7030003710 S.RES ERJ3GEYJ 184 V (180 k
Ω
) B 53.1/26.2
R270 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) T 86/13
R271 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) T 87.3/13
R272 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) T 88.7/13
R273 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) T 92.1/13.8
R274 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) T 91.4/15.7
R275 7030003610 S.RES ERJ3GEYJ 273 V (27 k
Ω
) T 92.9/15.7
R276 7030003570 S.RES ERJ3GEYJ 123 V (12 k
Ω
) T 50.5/36.8
R277 7030003570 S.RES ERJ3GEYJ 123 V (12 k
Ω
) T 49/40.8
R278 7030003570 S.RES ERJ3GEYJ 123 V (12 k
Ω
) T 45.8/39.7
R280 7030003200 S.RES ERJ3GEYJ 100 V (10
Ω
) T 42.8/39
R281 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 59.2/13.9
R282 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 53/21.3
R284 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 29.4/16.1
R285 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) T 94.5/19.6
R286 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) T 52.8/9
R287 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 15.8/49.1
R288 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 50.5/42.1
R289 7030004050 S.RES ERJ3GEYJ 1R0 V (1
Ω
) T 89.1/55.2
R290 7030003400 S.RES ERJ3GEYJ 471 V (470
Ω
) B 95.2/48.6
R291 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 63.9/20
R292 7030003720 S.RES ERJ3GEYJ 224 V (220 k
Ω
) B 61.8/21.9
R293 7410000950 S.ARY EXB-V8V 102JV B 41.4/8
R294 7410000950 S.ARY EXB-V8V 102JV T 46.8/7.8
R295 7410000950 S.ARY EXB-V8V 102JV B 43/17.4
R296 7410000770 S.ARY EXB-V4V 102JV (1 k
Ω
) B 46/17.4
R297 7030005651 S.RES ERA3YKD 304V (300 k
Ω
) B 35.5/55.1
R298 7030005871 S.RES ERA3YKD 104V (100 k
Ω
) B 40.7/47.2
R299 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 42.7/42.7
R302 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 76.6/59.3
R303 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 11.1/10.4
R304 7030003650 S.RES ERJ3GEYJ 563 V (56 k
Ω
) B 17.2/51
R305 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 60.3/30.2
R306 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) B 104.2/42.4
R307 7030003650 S.RES ERJ3GEYJ 563 V (56 k
Ω
) B 110.3/41.4
R308 7030003800 S.RES ERJ3GEYJ 105 V (1 M
Ω
) B 107.4/38.3
R312 7030003510 S.RES ERJ3GEYJ 392 V (3.9 k
Ω
) T 85.4/10.4
R316 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 44.5/21.8
R317 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 25.7/50.4
R318 7030003570 S.RES ERJ3GEYJ 123 V (12 k
Ω
) B 16.5/54.8
R319 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) T 120.2/28.5
R320 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k
Ω
) T 122/27.7
R322 7030004050 S.RES ERJ3GEYJ 1R0 V (1
Ω
) B 82.5/43
R323 7030004050 S.RES ERJ3GEYJ 1R0 V (1
Ω
) T 89.6/41.8
R324 7030003660 S.RES ERJ3GEYJ 683 V (68 k
Ω
) B 18.5/52.8
R500 7030003450 S.RES ERJ3GEYJ 122 V (1.2 k
Ω
) T 74.7/31.1
R501 7030003290 S.RES ERJ3GEYJ 560 V (56
Ω
) B 49.3/60
R502 7030003340 S.RES ERJ3GEYJ 151 V (150
Ω
) B 55.3/61.4
R503 7030003510 S.RES ERJ3GEYJ 392 V (3.9 k
Ω
) B 55.7/64
R504 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 63.9/26
R507 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) T 66.2/30.5
R508 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k
Ω
) T 63.5/40.6
R509 7030003400 S.RES ERJ3GEYJ 471 V (470
Ω
) B 66.4/41.3
R510 7030003550 S.RES ERJ3GEYJ 822 V (8.2 k
Ω
) T 60/41.2
R511 7030003400 S.RES ERJ3GEYJ 471 V (470
Ω
) B 61.4/43.3
R512 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k
Ω
) T 71/46.7
R513 7030003450 S.RES ERJ3GEYJ 122 V (1.2 k
Ω
) B 70/43.5
R515 7030003370 S.RES ERJ3GEYJ 271 V (270
Ω
) B 104.4/59
R516 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 20.1/15.4
R517 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 48.2/44.5
R518 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) T 99.4/35.3
R519 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) B 90.2/35.4
R520 7510001650 S.TMR NTCG16 4BH 222KT B 87/39.9
R521 7030003450 S.RES ERJ3GEYJ 122 V (1.2 k
Ω
) B 87/36.9
R522 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) B 85.7/39.9
R523 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) B 87/42.6
R524 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 84.6/44.9
R525 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 78.7/43.1
R526 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) B 79.2/37.2
R527 7030003460 S.RES ERJ3GEYJ 152 V (1.5 k
Ω
) B 75.3/40.2
R528 7030003290 S.RES ERJ3GEYJ 560 V (56
Ω
) B 75.6/44.2
R529 7030003580 S.RES ERJ3GEYJ 153 V (15 k
Ω
)
[25W] only T 57/61
R530 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k
Ω
) B 76.4/42.3
R534 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 111.6/42.4
R535 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) B 107.4/43
R536 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) B 109.2/43.8
R537 7030003380 S.RES ERJ3GEYJ 331 V (330
Ω
) T 49.9/69.9
R538 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 49.9/71.2
R539 7030003460 S.RES ERJ3GEYJ 152 V (1.5 k
Ω
) T 45.9/68.5
R540 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k
Ω
) [25W] T 48/70.6
7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) [50W] T 48/70.6
R541 7030003420 S.RES ERJ3GEYJ 681 V (680
Ω
) T 48.7/68.6
R542 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 32.6/30.9
R543 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
)
[50W] only T 59.6/63.7
R544 7030003700 S.RES ERJ3GEYJ 154 V (150 k
Ω
)
[50W] only T 54.5/62.1
R546 7520000160 S.POS PRF21BD471QB3RA [50W] only B 75.1/74.7
R547 7030003590 S.RES ERJ3GEYJ 183 V (18 k
Ω
) [50W] T 59.7/65.8
7030004050 S.RES ERJ3GEYJ 1R0 V (1
Ω
) [25W] T 59.7/65.8
R548 7030003700 S.RES ERJ3GEYJ 154 V (150 k
Ω
) B 62.6/20
C1 4030011120 S.CER GRM31M2C2H100JV01L B 106.9/100.2
C2 4030011120 S.CER GRM31M2C2H100JV01L B 106.9/90.4
C3 4030011340 S.CER C1608 CH 1H 471J-T B 110.4/88.3
C4 4030008560 S.CER C1608 CH 1H 300J-T B 111.9/75.6
C5 4030011340 S.CER C1608 CH 1H 471J-T B 112.6/73.7
C6 4030011210 S.CER GRM31M2C2H330JV01L T 117.1/78.4
C7 4030011190 S.CER GRM31M2C2H270JV01L [50W] T 112.1/69.6
4030011510 S.CER GRM31M2C2H560JV01L [25W] T 112.1/69.6
C8 4030011210 S.CER GRM31M2C2H330JV01L T 108.2/70
C9 4030011170 S.CER GRM31M2C2H180JV01L T 99.7/64.1
C10 4030006860 S.CER C1608 JB 1H 102K-T B 117.6/88.9
C11 4030006860 S.CER C1608 JB 1H 102K-T B 106.1/72.5
C12 4030011340 S.CER C1608 CH 1H 471J-T B 88.8/66.4
C13 4030007090 S.CER C1608 CH 1H 470J-T B 79/63
C14 4030017200 S.CER GRM31BR32J102KY01L
[25W] only B 105.5/63.5
C15 4030011210 S.CER GRM31M2C2H330JV01L T 88.8/65.9
C17 4030007010 S.CER C1608 CH 1H 100D-T [25W] B 89/63
4030009920 S.CER C1608 CH 1H 050B-T [50W] B 89/63
C18 4030011770 S.CER C1608 CH 1H 060B-T B 99.3/59.8
C19 4030006860 S.CER C1608 JB 1H 102K-T B 93.2/63.8
C20 4030006860 S.CER C1608 JB 1H 102K-T B 96.6/58.9
C21 4030009500 S.CER C1608 CH 1H 0R5B-T B 96.6/60.2
C22 4030009540 S.CER C1608 CH 1H 1R5B-T B 95.7/57.6
C23 4030006860 S.CER C1608 JB 1H 102K-T B 93.4/61.9
C24 4030006860 S.CER C1608 JB 1H 102K-T T 83.3/66.2
C25 4030011770 S.CER C1608 CH 1H 060B-T B 97.3/62.1
C26 4030006860 S.CER C1608 JB 1H 102K-T B 93.1/56.1
C27 4030006860 S.CER C1608 JB 1H 102K-T B 90.7/58.8
C28 4030006860 S.CER C1608 JB 1H 102K-T T 82/66.2
C29 4030009920 S.CER C1608 CH 1H 050B-T B 93.1/57.4
C30 4030007050 S.CER C1608 CH 1H 220J-T B 93.1/54.8
C32 4030006860 S.CER C1608 JB 1H 102K-T B 87.7/53.7
C33 4030007090 S.CER C1608 CH 1H 470J-T T 93.1/48.2
C34 4030006860 S.CER C1608 JB 1H 102K-T T 91.8/48.2
C35 4030006860 S.CER C1608 JB 1H 102K-T B 90.5/50.7
C37 4030006860 S.CER C1608 JB 1H 102K-T T 87.8/56.7
C38 4030006860 S.CER C1608 JB 1H 102K-T B 72.3/44.5
C39 4030006860 S.CER C1608 JB 1H 102K-T B 85.8/54.7
C40 4030009540 S.CER C1608 CH 1H 1R5B-T B 84.3/51.6
C41 4030009350 S.CER C1608 CH 1H 3R5B-T B 80.8/53.4
C42 4030006860 S.CER C1608 JB 1H 102K-T B 86.5/59.1
C43 4030006860 S.CER C1608 JB 1H 102K-T T 80.7/66.2
C44 4030009520 S.CER C1608 CH 1H 020B-T B 82.6/54.2
C45 4030007170 S.CER C1608 CH 1H 221J-T B 84.3/54.2
C46 4030006860 S.CER C1608 JB 1H 102K-T T 79.4/66.2
C47 4030006860 S.CER C1608 JB 1H 102K-T B 82/57.8
C48 4030007090 S.CER C1608 CH 1H 470J-T B 77.6/49.7
C49 4030006990 S.CER C1608 CH 1H 080D-T B 72.4/54
C50 4030006860 S.CER C1608 JB 1H 102K-T B 76.3/49.7
C51 4030006860 S.CER C1608 JB 1H 102K-T B 78.9/49.8
C52 4030007020 S.CER C1608 CH 1H 120J-T B 80.8/51.6
C53 4030006900 S.CER C1608 JB 1H 103K-T T 78.3/52.1
C54 4030006860 S.CER C1608 JB 1H 102K-T T 80.1/53.9
C55 4030006990 S.CER C1608 CH 1H 080D-T T 81.2/46.3
C56 4030007050 S.CER C1608 CH 1H 220J-T T 84.2/50.1
C58 4030006860 S.CER C1608 JB 1H 102K-T B 90.4/47.8
C59 4030011600 S.CER C1608 JB 1E 104K-T T 89.7/51.4
C60 4030006860 S.CER C1608 JB 1H 102K-T B 94.2/50.5
C61 4030007130 S.CER C1608 CH 1H 101J-T T 97.4/46.7
C62 4030007120 S.CER C1608 CH 1H 820J-T T 100/54
C63 4030006860 S.CER C1608 JB 1H 102K-T T 96.4/51.8
C64 4030011340 S.CER C1608 CH 1H 471J-T T 98.6/58.5
C65 4030006860 S.CER C1608 JB 1H 102K-T T 95.8/48.6
C66 4030006860 S.CER C1608 JB 1H 102K-T B 99.8/51.8
C67 4030006860 S.CER C1608 JB 1H 102K-T T 100.4/46.4
C69 4030011330 S.CER C1608 CH 1H 391J-T B 102.4/53.9
C70 4030011330 S.CER C1608 CH 1H 391J-T B 105/53.9
C71 4030011600 S.CER C1608 JB 1E 104K-T B 102.5/49.9
C72 4030011600 S.CER C1608 JB 1E 104K-T B 95.7/32.8
C74 4030011600 S.CER C1608 JB 1E 104K-T B 89.7/31.8
C75 4550006050 S.TAN TEESVA 0J 106M8L T 109.8/57
C76 4030006900 S.CER C1608 JB 1H 103K-T T 53.7/66.7
C77 4030006860 S.CER C1608 JB 1H 102K-T T 54.5/63.4
C78 4030006860 S.CER C1608 JB 1H 102K-T T 59.7/70.3
C79 4030011810 S.CER C1608 JB 1A 224K-T T 56.3/70.9
C80 4030011600 S.CER C1608 JB 1E 104K-T T 60.3/67.7
C81 4030006860 S.CER C1608 JB 1H 102K-T T 48.5/67.3
C82 4030011270 S.CER GRM31M2C2H200JV01L
[25W] only T 96.7/73.7
C83 4030011270 S.CER GRM31M2C2H200JV01L
[25W] only T 76.8/73.9
C84 4030007090 S.CER C1608 CH 1H 470J-T T 65.9/70.4
C85 4030006860 S.CER C1608 JB 1H 102K-T T 65.9/69.1
C86 4030007090 S.CER C1608 CH 1H 470J-T T 46.6/73.8
