PARTS LIST
IC1 1110007320 S.IC NJM2591V-TE1-#ZZZB B 67.8/23
IC2 1110002751 S.IC TA75S01F(TE85RF) B 44.5/31.1
IC3 1150002380 IC RA30H4047M1-101 [EUR-01]
1150002380 IC RA30H4047M1-101 [EXP-01]
1150002400 IC RA60H4047M1-121 [USA-01]
1150002400 IC RA60H4047M1-121 [EXP-03]
1150002400 IC RA60H4047M1-121 [CHN-01]
IC4 1140005991 S.IC MB15A02PFV1-G-BND-ERE1 T 77.8/29.2
IC8 1110003091 IC LA4425A-E
IC9 1180003500 S.REG NJM7808DL1A-TE1-#FZZB T 123.3/45.7
IC10 1180003460 S.REG NJM2831F05-TE1-#ZZZB T 121.6/35.4
IC14 1130011770 S.IC CD4066BPWR B 35.1/16.4
IC15 1110002751 S.IC TA75S01F(TE85RF) B 32.0/6.7
IC16 1110005340 S.IC NJM12902V-TE1-#ZZZB B 20.6/21.1
IC17 1130011760 S.IC CD4094BPWR B 53.1/9.9
IC18 1110007290 S.IC AK2330P-L B 35.9/25.7
IC19 1110002751 S.IC TA75S01F(TE85RF) B 83.7/18.1
IC20 1190001340 S.IC M62334FP 600C B 72.3/26.3
IC21 1110002751 S.IC TA75S01F(TE85RF) T 47.9/17.5
Q1 1560000841 S.FET 2SK1829(TE85RF) T 34.6/40.4
Q2 1580000731 S.FET 3SK293(TE85LF) B 41.5/38.7
Q3 1580000731 S.FET 3SK293(TE85LF) B 71.4/38.4
Q4 1530003311 S.TRA 2SC5107-O(TE85RF) T 64.5/25.3
Q5 1590004070 S.TRA LDTC144EET1G <SLVJ> T 55.7/15.2
Q6 1590004070 S.TRA LDTC144EET1G <SLVJ> T 62.6/52.1
Q8 1530002680 S.TRA 2SC3357-T1 B 90.4/52.8
Q9 1530002921 S.TRA 2SC4226-T1 Y25 (R25) B 84.6/51.8
Q10 1530003311 S.TRA 2SC5107-O(TE85RF) B 92.8/33.1
Q11 1530003311 S.TRA 2SC5107-O(TE85RF) B 100.5/31.7
Q12 1530004110 S.TRA MT3S37T(TE85LF) B 97.6/30.4
Q13 1530002921 S.TRA 2SC4226-T1 Y25 (R25) B 105.2/30.9
Q14 1530002921 S.TRA 2SC4226-T1 Y25 (R25) B 98.3/24.2
Q15 1590004500 S.TRA DMC561040R T 101.0/34.4
Q16 1590004070 S.TRA LDTC144EET1G <SLVJ> T 103.5/36.6
Q17 1530002851 S.TRA 2SC4116-BL(TE85RF) T 107.7/33.8
Q18 1560000541 S.FET 2SK880-Y(T5RICOMF) T 78.0/24.5
Q19 1590004070 S.TRA LDTC144EET1G <SLVJ> T 91.8/11.7
Q20 1530002851 S.TRA 2SC4116-BL(TE85RF) [USA-01] T 60.0/49.8
1530002851 S.TRA 2SC4116-BL(TE85RF) [EXP-03] 1
1530002851 S.TRA 2SC4116-BL(TE85RF) [CHN-01] 1
Q23 1550000190 S.FET 2SJ506STR-E T 115.3/45.1
Q24 1590004070 S.TRA LDTC144EET1G <SLVJ> T 110.5/44.3
Q25 1540000550 S.TRA 2SD1664 T100Q B 125.1/47.6
Q26 1510000920 S.TRA 2SA1577 T106 Q T 107.7/44.3
Q27 1520000450 S.TRA 2SB1132 T100 Q B 123.5/21.1
Q28 1590004590 S.TRA DMC506010R [EUR-01] B 118.7/22.2
1590004590 S.TRA DMC506010R [EXP-01]
1590001190 S.TRA XP6501-(TX).AB [USA-01]
1590001190 S.TRA XP6501-(TX).AB [EXP-03]
1590001190 S.TRA XP6501-(TX).AB [CHN-01]
Q29 1590004150 S.TRA DRC9114T0L B 126.4/43.3
Q30 1590004070 S.TRA LDTC144EET1G <SLVJ> T 107.8/39.3
Q31 1590001451 S.FET 2SJ144-GR (TE85RF) B 114.3/13.1
Q33 1590004070 S.TRA LDTC144EET1G <SLVJ> T 113.7/27.3
Q34 1530002851 S.TRA 2SC4116-BL(TE85RF) B 67.6/25.1
Q35 1590000990 S.TRA DTC363EK T146 B 128.9/17.8
Q36 1590004070 S.TRA LDTC144EET1G <SLVJ> B 118.3/18.4
Q37 1590004070 S.TRA LDTC144EET1G <SLVJ> T 112.0/15.8
Q39 1590004390 S.TRA DMG504010R T 25.2/19.5
Q40 1590004310 S.TRA LDTA114EET1G <SLVJ> T 46.8/33.0
Q44 1590004070 S.TRA LDTC144EET1G <SLVJ> T 53.0/14.3
D1 1750001820 S.DIO LRB706F-40T1G <SLVJ> B 19.2/49.9
D3 1750002060 S.DIO RN752TE-21 T 35.0/56.9
D4 1750001780 S.VAR HVB350BYPTL-E B 35.7/40.9
D5 1750002060 S.DIO RN752TE-21 T 26.5/52.9
D7 1790001621 S.DIO 1SV308(TPL3F) B 25.3/45.3
D8 1750001780 S.VAR HVB350BYPTL-E B 27.1/40.9
D9 1750000711 S.VAR HVC350BTRF-E B 52.8/42.6
D10 1750000711 S.VAR HVC350BTRF-E B 55.5/39.9
D11 1750001820 S.DIO LRB706F-40T1G <SLVJ> B 8.2/49.9
D12 1750001820 S.DIO LRB706F-40T1G <SLVJ> B 22.8/49.9
D14 1750001890 S.DIO HVD142AKRF-E B 82.2/41.8
D15 1750001890 S.DIO HVD142AKRF-E B 82.2/39.2
D16 1750001780 S.VAR HVB350BYPTL-E B 107.1/21.1
D18 1750001650 S.VAR 1SV309(TPH3F) B 101.8/25.9
D19 1750000711 S.VAR HVC350BTRF-E B 61.9/39.9
D22 1790000700 DIO DSA3A1
D23 1750000370 S.DIO DA221 TL B 124.0/43.3
D26 1750001810 S.DIO L1SS400T1G <SLVJ> B 116.7/12.0
D29 1750001810 S.DIO L1SS400T1G <SLVJ> B 119.2/20.2
D33 1750001780 S.VAR HVB350BYPTL-E B 98.1/19.9
D37 1750001810 S.DIO L1SS400T1G <SLVJ> T 79.9/33.4
D42 1160000140 S.DIO DAP222 TL B 37.1/7.2
D43 1160000140 S.DIO DAP222 TL B 35.0/7.2
D44 1750001850 S.DIO LDAN222T1G <SLVJ> B 49.1/5.8
D52 1750000711 S.VAR HVC350BTRF-E B 93.6/24.0
D53 1750000711 S.VAR HVC350BTRF-E B 104.5/21.0
D58 1750000370 S.DIO DA221 TL B 112.7/10.3
D59 1750000370 S.DIO DA221 TL T 113.0/7.1
D60 1750000370 S.DIO DA221 TL B 113.9/8.2
D61 1750000370 S.DIO DA221 TL T 113.0/9.4
D66 1750000370 S.DIO DA221 TL T 34.6/37.8
D67 1790001241 S.DIO MA2S7280GL T 36.2/37.8
D68 1750001910 S.DIO HVD144AKRF-E T 49.0/31.4
REF PARTS
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN-A UNIT] (For low band version)
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN-A UNIT] (Low band version)
D69 1750001910 S.DIO HVD144AKRF-E T 48.1/29.8
D70 1750001910 S.DIO HVD144AKRF-E T 51.5/33.2
D71 1750001910 S.DIO HVD144AKRF-E T 51.5/34.7
FI1 2030000870 S.MON MFT46.3P3 46.350 MHz (FL-442) T 66.6/34.9
FI2 2020002410 CER LTM450FW <JJE>
FI3 2040001440 S.LC NFE31PT152Z1E9L
(NFM60R20T152) B 97.7/55.4
FI4 2040001440 S.LC NFE31PT152Z1E9L
(NFM60R20T152) B 97.7/58.9
FI5 2040001440 S.LC NFE31PT152Z1E9L
(NFM60R20T152) [USA-01] B 97.7/62.2
2040001440 S.LC NFE31PT152Z1E9L
(NFM60R20T152) [EXP-03]
2040001440 S.LC NFE31PT152Z1E9L
(NFM60R20T152) [CHN-01]
FI6 2020002570 CER LTM450HW <JJE>
X1 6070000310 S.DIS JTBM450CX70 <JJE> B 53.0/24.5
X2 6050012050 S.XTA CR-794 TTS14VSB-A6 15.3 MHz B 80.8/23.8
L1 6200010150 S.COI AS080340-15N B 8.4/62.7
L2 6200010150 S.COI AS080340-15N B 12.9/55.5
L3 6200010150 S.COI AS080340-15N B 20.7/55.5
L4 6200013100 S.COI 0.45-1.5-5TL 18.3N <COMO> T 31.1/50.5
L5 6200010420 S.COI FHW1210HC 1R0JGT <JJE> T 38.5/58.4
L6 6200010150 S.COI AS080340-15N B 27.3/55.5
L7 6200012800 S.COI 0.40-1.5-5TL 20N <COMO> B 28.2/37.8
L8 6200012800 S.COI 0.40-1.5-5TL 20N <COMO> B 34.6/37.8
L9 6200011690 S.COI C2520C-12NG-A B 49.0/39.8
L10 6200004660 S.COI MLF1608A 1R8K-T T 78.1/13.3
L11 6200011690 S.COI C2520C-12NG-A B 57.8/40.5
L13 6200010090 S.COI ELJND R82JF B 68.9/40.9
L16 6200010150 S.COI AS080340-15N B 38.2/65.2
L18 6200005701 S.COI ELJRE 22NGFA B 88.1/58.9
L19 6200005711 S.COI ELJRE 27NGFA B 89.9/56.0
L20 6200005701 S.COI ELJRE 22NGFA B 84.6/53.7
L21 6200005711 S.COI ELJRE 27NGFA B 90.8/33.1
L22 6200005721 S.COI ELJRE 33NGFA B 99.5/33.8
L27 6200001770 S.COI ELJNC 47NK-F B 102.2/19.7
L28 6200007370 S.COI ELJFC R82K-F T 94.8/17.3
L33 6200012170 S.COI MLG1608S R18J-T B 62.9/23.3
L35 6200012170 S.COI MLG1608S R18J-T B 65.3/24.3
L36 6200006991 S.COI ELJRE 56NGFA B 73.5/38.5
L37 6200006981 S.COI ELJRE R10GFA T 82.6/62.9
L38 6200013660 S.COI C36-5NH <COMO> B 106.2/24.9
L39 6200013660 S.COI C36-5NH <COMO> B 92.9/20.2
L41 6200005681 S.COI ELJRE 15NGFA B 95.8/29.8
L45 6200005671 S.COI ELJRE 12NGFA B 85.4/31.3
L46 6200007370 S.COI ELJFC R82K-F T 88.9/24.9
L47 6200007370 S.COI ELJFC R82K-F B 102.2/22.2
L53 6200005731 S.COI ELJRE 39NGFA B 78.0/39.2
L54 6200007370 S.COI ELJFC R82K-F T 100.0/30.4
L55 6200003310 S.COI ELJFC R33M-F B 103.7/33.8
L56 6200011690 S.COI C2520C-12NG-A B 64.2/40.5
L57 6200005671 S.COI ELJRE 12NGFA B 94.2/27.4
R1 7030000620 S.RES MCR10EZHJ 100 K (104) B 12.3/65.5
R4 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 16.4/50.6
R5 7030005290 S.RES ERJ2GEJ 682 X (6.8K) [EUR-01] B 11.2/49.6
7030005290 S.RES ERJ2GEJ 682 X (6.8K) [EXP-01]
7030005220 S.RES ERJ2GEJ 223 X (22K) [USA-01]
7030005220 S.RES ERJ2GEJ 223 X (22K) [EXP-03]
7030005220 S.RES ERJ2GEJ 223 X (22K) [CHN-01]
R6 7030005290 S.RES ERJ2GEJ 682 X (6.8K) [EUR-01] B 19.8/48.1
7030005290 S.RES ERJ2GEJ 682 X (6.8K) [EXP-01]
7030008290 S.RES ERJ2GEJ 183 X (18K) [USA-01]
7030008290 S.RES ERJ2GEJ 183 X (18K) [EXP-03]
7030008290 S.RES ERJ2GEJ 183 X (18K) [CHN-01]
R7 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 8.2/53.2
R8 7030006070 S.RES ERJ12YJ101U (100) B 45.7/51.9
R9 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 25.6/50.6
R10 7030005290 S.RES ERJ2GEJ 682 X (6.8K) [EUR-01] B 22.2/48.1
7030005290 S.RES ERJ2GEJ 682 X (6.8K) [EXP-01]
7030008290 S.RES ERJ2GEJ 183 X (18K) [USA-01]
7030008290 S.RES ERJ2GEJ 183 X (18K) [EXP-03]
7030008290 S.RES ERJ2GEJ 183 X (18K) [CHN-01]
R11 7030005050 S.RES ERJ2GEJ 103 X (10K) B 30.9/40.5
R12 7030004980 S.RES ERJ2GEJ 101 X (100) B 39.2/39.5
R13 7030005050 S.RES ERJ2GEJ 103 X (10K) B 31.9/40.5
R14 7030005050 S.RES ERJ2GEJ 103 X (10K) B 31.9/38.8
R15 7030005700 S.RES ERJ2GEJ 274 X (270K) B 39.2/38.6
R16 7030004980 S.RES ERJ2GEJ 101 X (100) B 39.5/40.7
R17 7030005530 S.RES ERJ2GEJ 100 X (10) B 51.5/40.2
R18 7030005050 S.RES ERJ2GEJ 103 X (10K) B 60.8/40.5
R19 7030005090 S.RES ERJ2GEJ 104 X (100K) B 39.2/36.8
R20 7030005120 S.RES ERJ2GEJ 102 X (1K) B 52.8/38.6
R21 7030005050 S.RES ERJ2GEJ 103 X (10K) B 54.1/40.2
R22 7030005050 S.RES ERJ2GEJ 103 X (10K) B 63.7/36.7
R23 7030005050 S.RES ERJ2GEJ 103 X (10K) B 54.1/41.2
R29 7030005570 S.RES ERJ2GEJ 820 X (82) B 74.0/40.6
R30 7030007300 S.RES ERJ2GEJ 332 X (3.3K) B 71.3/40.6
R31 7030004980 S.RES ERJ2GEJ 101 X (100) B 66.9/37.4
R32 7030005530 S.RES ERJ2GEJ 100 X (10) T 68.0/40.2
