Icom IC-F6013H Service Manual

7 - 10
REF PARTS
DESCRIPTION M.
H/V
NO. NO.
LOCATION
[FRONT UNIT]
R133 7030008400 S.RES ERJ2GEJ 182 X (1.8K) B 40.5/20.7
R134 7030008400 S.RES ERJ2GEJ 182 X (1.8K) B 57.6/21.4
R135 7030005030 S.RES ERJ2GEJ 152 X (1.5K) B 27.4/28.4
R136 7030005030 S.RES ERJ2GEJ 152 X (1.5K) B 47.2/28.3
R137 7030005030 S.RES ERJ2GEJ 152 X (1.5K) B 47.2/27.4
R138 7030005030 S.RES ERJ2GEJ 152 X (1.5K) B 78.5/24.2
R139 7030005120 S.RES ERJ2GEJ 102 X (1K) B 54.7/9.2
R140 7030005050 S.RES ERJ2GEJ 103 X (10K) B 63.1/15.8
C2 4030017420 S.CER C1005 CH 1H 470J-T B 84.4/5.1
C3 4030017420 S.CER C1005 CH 1H 470J-T B 34.6/10.2
C4 4030017420 S.CER C1005 CH 1H 470J-T B 45.3/10.8
C5 4030017420 S.CER C1005 CH 1H 470J-T B 57.0/4.2
C8 4030017460 S.CER C1005 JB 1H 102K-T B 13.8/17.2
C10 4030017460 S.CER C1005 JB 1H 102K-T B 7.7/9.2
C12 4030017460 S.CER C1005 JB 1H 102K-T B 5.2/9.2
C14 4030017460 S.CER C1005 JB 1H 102K-T B 32.9/26.6
C15 4030016960 S.CER C1005 JB 1E 183K-T B 32.9/25.7
C16 4030016930 S.CER C1005 JB 1A 104K-T B 32.9/23.9
C17 4030017750 S.CER C1005 JB 1H 122K-T B 31.2/26.6
C19 4030016930 S.CER C1005 JB 1A 104K-T B 36.3/23.9
C20 4030017460 S.CER C1005 JB 1H 102K-T B 34.6/17.6
C21 4030017460 S.CER C1005 JB 1H 102K-T B 32.9/18.5
C22 4030020020 S.CER C1005 CH 1H 391J-T B 30.0/16.0
C23 4030016790 S.CER C1005 JB 1E 103K-T B 32.9/22.1
C24 4030017420 S.CER C1005 CH 1H 470J-T B 28.2/16.0
C25 4030016790 S.CER C1005 JB 1E 103K-T B 25.5/28.4
C26 4030016930 S.CER C1005 JB 1A 104K-T B 23.6/26.6
C27 4030020010 S.CER C1005 CH 1H 271J-T B 25.5/26.6
C28 4030016930 S.CER C1005 JB 1A 104K-T B 29.1/16.0
C30 4030019560 S.CER GRM21BB31C106KE15L B 29.9/12.6
C31 4030016930 S.CER C1005 JB 1A 104K-T B 36.3/11.1
C34 4030017420 S.CER C1005 CH 1H 470J-T B 80.7/10.8
C36 4030016930 S.CER C1005 JB 1A 104K-T B 38.7/27.2
C38 4030017420 S.CER C1005 CH 1H 470J-T B 78.9/10.8
C41 4030017460 S.CER C1005 JB 1H 102K-T B 23.6/28.4
C50 4030017420 S.CER C1005 CH 1H 470J-T B 61.9/9.3
C54 4030017420 S.CER C1005 CH 1H 470J-T B 62.8/9.3
C69 4030017420 S.CER C1005 CH 1H 470J-T B 67.4/1.8
C74 4030017420 S.CER C1005 CH 1H 470J-T B 61.7/1.8
C76 4030016930 S.CER C1005 JB 1A 104K-T B 29.1/26.6
C77 4030016950 S.CER C1005 JB 1A 473K-T B 73.0/12.4
C78 4030017460 S.CER C1005 JB 1H 102K-T B 8.9/17.4
C82 4030017420 S.CER C1005 CH 1H 470J-T T 34.9/65.2
C84 4030017420 S.CER C1005 CH 1H 470J-T T 55.0/61.6
C85 4030017420 S.CER C1005 CH 1H 470J-T T 56.0/61.6
C86 4030017420 S.CER C1005 CH 1H 470J-T [EUR-01] T 81.3/63.8
4030017420 S.CER C1005 CH 1H 470J-T [EXP-01]
C87 4030016930 S.CER C1005 JB 1A 104K-T T 79.8/68.8
C93 4030017460 S.CER C1005 JB 1H 102K-T B 61.9/12.6
C101 4030016930 S.CER C1005 JB 1A 104K-T B 56.0/15.3
C102 4030016930 S.CER C1005 JB 1A 104K-T B 53.8/18.8
C103 4030016930 S.CER C1005 JB 1A 104K-T B 54.7/18.8
C104 4030017400 S.CER C1005 CH 1H 220J-T B 52.1/15.3
C105 4030017600 S.CER C1005 CH 1H 080C-T B 53.4/14.9
C106 4030017640 S.CER C1005 CH 1H 150J-T B 53.4/14.0
C107 4030017030 S.CER C1005 JB 1A 273K-T B 43.8/29.3
C111 4030016930 S.CER C1005 JB 1A 104K-T B 43.8/28.4
C112 4550006780 S.TAN TEESVB2 0J 476M8R B 53.4/21.7
C113 4030018910 S.CER C1608 JB 0J 475K-T B 63.9/12.2
C114 4030017420 S.CER C1005 CH 1H 470J-T B 62.8/12.6
C116 4030016930 S.CER C1005 JB 1A 104K-T B 65.7/12.6
C117 4030016930 S.CER C1005 JB 1A 104K-T B 66.6/12.6
C118 4030016930 S.CER C1005 JB 1A 104K-T B 69.3/12.6
C119 4030016930 S.CER C1005 JB 1A 104K-T B 67.5/12.6
C120 4030016930 S.CER C1005 JB 1A 104K-T B 68.4/12.6
C123 4030017460 S.CER C1005 JB 1H 102K-T B 80.0/14.7
C124 4030016930 S.CER C1005 JB 1A 104K-T B 73.9/30.1
C125 4030016930 S.CER C1005 JB 1A 104K-T B 83.5/6.8
C126 4030017460 S.CER C1005 JB 1H 102K-T B 30.4/14.0
C128 4030016930 S.CER C1005 JB 1A 104K-T T 14.3/19.2
C129 4030017460 S.CER C1005 JB 1H 102K-T T 14.3/17.5
C130 4030017460 S.CER C1005 JB 1H 102K-T B 84.8/8.1
C131 4030018860 S.CER C1005 JB 0J 105K-T B 106.4/27.2
C139 4030017420 S.CER C1005 CH 1H 470J-T B 5.6/17.4
J1 6450002210 CON 3017-8821 <KIN>
J2 6510027960 S.CON 04-6294-040-000-800 B 71.0/5.7
J3 6510022022 S.CON 14FLT-SM2-TB(LF)(SN)(M) B 84.4/28.6
DS1 5040003510 S.LED LNJ426W83RA T 37.5/6.8
DS2 5040003510 S.LED LNJ426W83RA T 67.9/6.8
DS3 5040003510 S.LED LNJ426W83RA T 75.5/27.2
DS4 5040003510 S.LED LNJ426W83RA T 60.3/27.2
DS5 5040003510 S.LED LNJ426W83RA T 45.1/27.2
DS6 5040003510 S.LED LNJ426W83RA T 29.9/27.2
DS7 5040003510 S.LED LNJ426W83RA T 60.3/21.2
DS8 5040003510 S.LED LNJ426W83RA T 45.1/21.2
DS9 5040003510 S.LED LNJ426W83RA T 29.9/21.2
DS10 5040002670 S.LED CL-165HR/YG T 79.8/21.2
SP1 2510001221 SPE C052SB500-14 <OSC>
W1 8900010503 CAB OPC-1046B-1(P0.5N40L55)
<TJM>
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
