Icom IC-F6020 Series Service Manual

8 - 2
MP8 (C) x2
R14 (F)
J1 (F)
MP10 (F)
MP12 (F)
EP2 (F)
W1 (F)
MP3 (F)
FRONT UNIT
Unit abbreviations (F): FRONT UNIT
(MA): MAIN-A UNIT
(C): CHASSIS PARTS
MP5 (F)
MP9 (F)
DS11 (F)
MP2 (F)
MP6 (F)
MP1 (F)
SP1 (F)
MP11 (F)
MP5 (C) x2
MP3 (MA)
MP1 (C)
J1 (C)
MP4 (C) x2
MAIN UNIT
MP3 (C) x8
MP2 (C)
MP7 (C) x4
MP3 (C)
MP1 (MA)
MP5 (MA)
MP2 (MA)
MP6 (C)
J4 (MA)
W2 (MA)
IC8 (MA)
IC3 (MA)
MP8 (F)
MP13 (F) x3
