2 - 2
PLL CIRCUIT
• MAIN-A UNIT
(TOP VIEW)
IF IC
(IC1)
LPF
(Q39)
CPU5 LINE REGULATOR
(IC10)
AF AMP
(IC8)
POWER SWITCH
(Q23)
+8 LINE REGULATOR
(IC9)
DISCRIMINATOR SWITCH
(Q5)
POWER SWITCH
(Q24)
APC AMP
(IC2)
2ND IF FILTER SWITCH
(Q40)
1ST IF FILTER
(FI1)
