1 - 2
All stated specifications are subject to change without notice or obligation.
Measurements made in accordance with TIA-603 or EN 300 086.
[USA], [CHN] [EXP] [EUR]
RECEIVER
• Receive system Double-conversion superheterodyne
• Intermediate frequencies 1st IF; 46.35 MHz, 2nd IF; 450 kHz
• Sensitivity
0.25 μV typ. at 12 dB SINAD
−4 dBμV (EMF) typ.
at 20 dB SINAD
• Squelch sensitivity (at threshold) 0.25 μV typ. –4 dBμV (EMF) typ.
• Adjacent channel
selectivity
Wide More than 70 dB (75 dB typ.)
Middle More than 70 dB (75 dB typ.)
Narrow More than 60 dB (65 dB typ.)
• Spurious response More than 70 dB
• Intermodulation More than 70 dB (75 dB typ.) More than 65 dB (67 dB typ.)
• Hum and noise
(without CCITT filter)
Wide More than 40 dB (45 dB typ.)
Narrow More than 34 dB (40 dB typ.)
• Hum and noise
(with CCITT filter)
Wide
More than 45 dB (55 dB typ.)
Middle
More than 43 dB (53 dB typ.)
Narrow
More than 40 dB (50 dB typ.)
• Audio output power 4.0 W typ. at 5% distortion with a 4 Ω load
• Audio output impedance 4
Ω
