1 - 1
SECTION 1
SPECIFICATIONS
[USA], [CHN] [EXP] [EUR]
GENERAL
• Frequency coverage 400–470 MHz
• Type of emission Wide 16K0F3E (25.0 kHz)
Middle – 14K0F3E (20.0 kHz)
Narrow 11K0F3E (12.5 kHz) 8K50F3E (12.5 kHz)
• Number of programable channels 128 channels (8 zones)
• Antenna impedance
50
Ω
(nominal)
• Operating temperature range −30˚ to +60˚; −22˚F to +140˚F –25˚C to +55˚C
• Power supply requirement
(negative ground)
13.6 V DC (nominal) 13.2 V DC (nominal)
• Current drain
(approx.)
RX
Stand-by 250 mA
Max.audio 700 mA
TX
at 25 W 5.0 A
at 45 W 11.0 A
• Dimensions
[25 W ver.]
150 (W) × 40 (H) × 117.5 (D) mm; (5
29
/
32
(W) × 1
9
/
16
(H) × 4
5
/
8
(D) in)
[45 W ver.]
150 (W) × 40 (H) × 167.5 (D) mm; (5
29
/
32
(W) × 1
9
/
16
(H) × 6
19
/
32
(D) in)
• Weight
[25 W ver.] 0.8 kg (1
3
/
4
Ib)
[45 W ver.] 1.1 kg (2
7
/
16
Ib)
TRANSMITTER
• Transmit output power [25 W ver.] 25 W (High), 10 W (Low2), 2.5 W (Low1) 25 W
[45 W ver.] 45 W (High), 25 W (Low2), 4.5 W (Low1) –
• Modulation Variable reactance frequency modulation
• Max. permissible deviation Wide ±5.0 kHz
Middle – ±4.0 kHz
Narrow ±2.5 kHz
• Frequency error ±2.5 ppm ±1.5 kHz
• Spurious emission
70 dB typ.
0.25
μ
W (
≤
1 GHz),
1.0
μ
W (>1 GHz)
• Adjacent channel power Wide More than 70 dB
Middle – More than 70 dB
Narrow More than 60 dB
• Audio harmonic distortion 3% typ. (with 1 kHz AF 40% deviation)
• FM hum and noise
(without CCITT filter)
Wide More than 40 dB (46 dB typ.) –
Narrow More than 34 dB (40 dB typ.) –
• Residual modulation
(with CCITT filter)
Wide –
More than 45 dB (55 dB typ.)
Middle –
More than 43 dB (53 dB typ.)
Narrow –
More than 40 dB (50 dB typ.)
• Limiting charact of modulation 70–100% of max. deviation
• Microphone impedance 600
Ω
All stated specifications are subject to change without notice or obligation.
Measurements made in accordance with TIA-603 or EN 300 086.
