CONNECTION AND MAINTENANCE
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
D Self ground type microphone hanger con-
nection
Purchase separately
Connect the microphone hanger to
the vehicle’s ground for microphone
on/off hook functions when the op-
tional microphone (HM-152/T) is
used.
When the optional microphone
(HM-152/T) is used:
■ Supplied Accessories
MicrophoneMicrophone
Microphone hanger
and screw set
Microphone hanger
and screw set
Microphone
hanger cable
DC power cable
Sponges*
2
Mounting bracket
Flat washers
Spring washers
Bracket bolts
Mounting screws
(M5×12)
Self-tapping screws
(M5×16)
Nuts
*
2
Used for labelling the pro-
grammable function keys
according to their assinged
functions.
Used for the optional unit
installation.
Ask your dealer for details.
*
1
OR
Non-self ground type Self ground type
Function name
stickers*
1
To Next Page
