Icom IC-M45 - Page 14

S.=Surface mount
IC1 1530007220 S.IC M38223M4-432-HP FX-2040
IC2 1110003500 S.IC S-80742SL-A6-T1
IC3 1130007390 S.IC TC7W02F (TE12L)
IC4 1140005620 S.IC X25080SI-2.7T6
Q1 1530001950 S.TRANSISTOR 2SC2712-GR (TE85R)
Q2 1510000500 S.TRANSISTOR 2SA1162-GR (TE85R)
Q3 1530001950 S.TRANSISTOR 2SC2712-GR (TE85R)
Q4 1590000670 S.TRANSISTOR FMW1 T148
Q5 1520000450 S.TRANSISTOR 2SB1132 T100 Q
D1 1750000060 S.DIODE 1SS196 (TE85R)
D2 1750000110 S.DIODE 1SS272 (TE85R)
D3 1750000060 S.DIODE 1SS196 (TE85R)
D4 1750000060 S.DIODE 1SS196 (TE85R)
X1 6060000630 S.CERAMIC PBRC 4.91 BR
R1 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R2 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R3 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R4 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R5 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R6 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ)
R7 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R8 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R9 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R10 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R11 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ)
R12 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R13 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R14 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R15 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R16 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R17 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R18 7030000190 S.RESISTOR MCR10EZHJ 27 Ω (270)
R19 7030000190 S.RESISTOR MCR10EZHJ 27 Ω (270)
R20 7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 kΩ)
R21 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R22 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ)
R23 7030003650 S.RESISTOR ERJ3GEYJ 563 V (56 kΩ)
R24 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R25 7030003510 S.RESISTOR ERJ3GEYJ 392 V (3.9 kΩ)
R26 7030003490 S.RESISTOR ERJ3GEYJ 272 V (2.7 kΩ)
R27 7030003700 S.RESISTOR ERJ3GEYJ 154 V (150 kΩ)
R28 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R29 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R30 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R31 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R32 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R33 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R34 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
C1 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C2 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C3 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C4 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C5 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C6 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C7 4030009660 S.CERAMIC C1608 JF 1C 224Z-T-A
C8 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C9 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C10 4510005860
S.ELECTROLYTIC ECEV1HA2R2SR
C11 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C12 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C13 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C14 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C15 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C16 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C17 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C18 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C19 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C20 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C21 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
J1 6510019070 S.CONNECTOR 52559-3092
J2 6510018960 S.CONNECTOR B2B-PH-SM3-TB
DS1 5030001373 LCD LD-HU4549J-1 (E-4548-3)
DS2 5080000170 LAMP HRS-7219A-Y2-30
DS3 5080000170 LAMP HRS-7219A-Y2-30
W3 8900005320 FFC OPC-519 (N:30 L:55)
EP1 0910049094 PCB B 5035D
EP2 8930045650 LCD CONTACT SRCN-2040-SP-N-W
R1 7210001500 VARIABLE RK097111102AA (10KA)
W1 8900007790 CABLE OPC-759
EP1 0910049102 PCB B 5036B
R1 7210001010 VARIABLE RK097111000AA (10KB)
EP1 0910049312 PCB B 5055B
IC1 1110003490 S.IC TA31136FN (D,EL)
IC2 1150001540 IC M57710-A/SC-1302
IC3 1130007610 S.IC µPD3140GS-E1 (DS8)
IC4 1130007370 S.IC TA75S558F (TE85L)
IC5 1130007690 S.IC BU4066BCF-T1
IC6 1110003750 S.IC M5218AFP 600C
IC7 1130007700 S.IC BU4094BCF-T1
IC8 1180001070 S.IC TA7805F (TE16L)
IC9 1110003090 IC LA4425A
IC10 1110003640 S.IC BA1604F-T [USA] only
Q1 1560000550 S.FET 2SK882-Y (TE85R)
Q2 1580000540 S.FET 3SK131-T2-LA
Q3 1530002360 S.TRANSISTOR 2SC2714-Y (TE85R)
Q4 1560000330 S.FET 2SK210-GR (TE85R)
Q5 1560000330 S.FET 2SK210-GR (TE85R)
Q6 1560000540 S.FET 2SK880-Y (TE85R)
Q7 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
5 - 1
SECTION 5 PARTS LIST
REF ORDER
DESCRIPTION
NO. NO.
[LOGIC UNIT]
REF ORDER
DESCRIPTION
NO. NO.
[LOGIC UNIT]
[VR-A UNIT]
REF ORDER
DESCRIPTION
NO. NO.
[VR-B UNIT]
REF ORDER
DESCRIPTION
NO. NO.
[MAIN UNIT]
REF ORDER
DESCRIPTION
NO. NO.
[USA]; IC-M45, [EUR]; IC-M45EURO
