SECTION 1 SPECIFICATIONS
‘‘
GENERAL
• Frequency coverage : 156.025–157.425 MHz (Tx)
156.025–163.275 MHz (Rx)
• Mode : 16K0G3E (FM)
• Usable channels :
• Power supply requirement : 13.8 V DC ±15% (negative ground)
• Usable temperature range : –20˚C to +60˚C; –4˚F to +140˚F
• Frequency stability : ±10 ppm (–20˚C to +60˚C; –4˚F to +140˚F)
• Current drain (at 13.8 V DC) : Transmit at 25 W 6.0 A
Receive max. audio 1.2 A
• Antenna impedance : 50 Ω (nominal)
• Dimensions (projections not included) : 152(W)×67(H)×144(D) mm; 6(W)×2
5
⁄8(H)×5
2
⁄3(D) in
• Weight : 900 g; 2 lb
‘‘
TRANSMITTER
• Output power (at 13.8 V DC) : High 25 W
Low 1 W
• Modulation : Variable reactance frequency modulation
• Maximum frequency deviation : ±5.0 kHz
• Spurious emissions : 70 dB
• Adjacent channel power : 60 dB
• Residual modulation : 40 dB
• Audio harmonic distortion : Less than 10% at 70% deviation
• Audio frequency response : +1 dB to –3 dB of 6 dB octave from 300 Hz to 3000 Hz
‘‘
RECEIVER
• Receive system : Double conversion superheterodyne system
• Intermediate frequencies : 1st 30.85 MHz
2nd 450 kHz
• Sensitivity : 0.22 µV typical at 12 dB SINAD
• Squelch sensitivity : 0.22 µV typical
• Adjacent channel selectivity : 70 dB typical
• Spurious response : 70 dB typical
• Intermodulation rejection ratio : 70 dB typical
• Hum and noise : 40 dB
• Audio output power (at 13.8 V DC) : 4.0 W typical at 10% distortion with an 4 Ω load
• Audio frequency responce : +2 dB to –8 dB of –6 dB octave from 300 Hz to 3000 Hz
All stated specifications are subject to change without notice or obligation.
