4. SPECIFICATIONS
FX15+ Version 6.01 onwards (P6.01 is shown at switch-on), 2019 onwards
Supply Voltage: Nominal .... 12V DC
Maximum .... 19V DC
Reverse polarity protection diode fitted.
Low Battery Indication: Below approximately 11.6V the LOW BAT pointer s will be on.
The FX15+ switches off at approximately 10V.
Supply Current: Approximately 150 mA including loadbar set.
Temperature Range: -5ºC to +50ºC
Zero Tracking: Small residual weights left on the scale between weighings (dirt build up) are
automatically 'zero-tracked' out and the scale restored to zero. As this occurs
the ZERO pointer s will indicate that ZERO has been reached.
The zero-tracking amount is set to 0.5% of the weight displayed after the last
press of WEIGH, with a 2.2kg maximum.
At switch-on the zero-tracking amount is initialised to 0.015% of capacity
(0.3kg for 2000kg loadbar set).
Resolution: Autoranges in graduated steps from the zero point of the scale.
Scale 1:
Standard Loadbars Metric Model Resolution Imperial Model Resolution
0 - 20 kg 0.1 kg 0 - 40 lb 0.2 lb
20 - 50 kg 0.2 kg 40 - 100 lb 0.5 lb
50 - 200 kg 0.5 kg 100 - 400 lb 1 lb
200 - 500 kg 1 kg 400 - 1000 lb 2 lb
500 - 2000 kg 2 kg 1000 - 4000 lb 5 lb
Minimum Capacity: 20kg
(The 0-20kg range is available but is not part of the EMC specification).
Scale 2:
Vet Scale 0 - 100 kg 0.05 kg 0 - 200 lb 0.1 lb
100 - 300 kg 0.1 kg 200 - 600 lb 0.2 lb
Scale 3:
Heavy-Duty Loadbars 0 - 100 kg 0.5 kg 0 - 200 lb 1 lb
100 - 200 kg 1 kg 200 - 400 lb 2 lb
200 - 1000 kg 2 kg 400 - 2000 lb 5 lb
1000 - 3000 kg 5 kg 2000 - 6000 lb 10 lb
Accuracy: ± 0.5% of Displayed Reading ± 1 Division (where 1 division is 0.1kg, 0.5kg
etc. depending on weight range)
RF Immunity: Maximum additional error in a 3V/m RF field in the range 27 - 500 MHz is:
± 2 divisions for 20 - 50kg
± 1 division for 50 - 200kg
± 0 division for 200 - 2000kg
EMC Approvals: Meets or exceeds the following standards:
IEC801-2 Electrostatic discharge
EM50081-1 Free radiation measurements
EM50082-1 RF immunity
FX15+ Manual 06Nov19 Page 9
