ICP A Series User Manual

440 01 4542 00 21
Specifications subject to change without notice.
Table 7 – Filter Media Pre ssur e Drop (Clean) Versus Face Velocity-- In. W.C. (Pa)
Face Velocity
Factory-Accessory
Washable
Representative
A
fter-Mar
k
et Filter Media*
Fiberglass* Pleated*
FPM (m/s) (1-in. / 2.5 cm) (1-in. / 2.5 cm) (2-in. / 5 cm) (1-in. / 2.5 cm) (2-in. / 5 cm)
200 (1) 0.04 (10) 0.05 (13) 0.08 (20) 0.18 (47) 0.12 (31)
300 (1.5) 0.05 (14) 0.09 (22) 0.13 (34) 0.30 (75) 0.21 (52)
400 (2) 0.07 (17) 0.13 (32) 0.20 (50) - - 0.31 (78)
500 (2.5) 0.08 (21) 0.18 (44) 0.27 (69) - - - -
600 (3) 0.09 (23) 0.23 - - - - - - -
700 (3.6) 0.10 (26) 0.29 - - - - - - -
* Representative estimates from filter manufacturer data sheets.
See manufacturers’ specifications for pressure drop versus airflow data for specific filter media..
See Table 8 for filter size details.
Table 8 – Air Filter Selection and Duct Sizing -- In. (mm)
FURNACE CASING WIDTH
FILTE R SIZE
FILTER TY PE
SIDE RETURN BOTTOM RETURN
1 4 --- 3
/
16{ (360)
16
x
25
x
3/4
(406 x 635 x 19)
14
x
25
x
3/4
(356 x 635 x 19)
Washable*
1 7 --- 1
/
2 (445)
16
x
25
x
3/4
(406 x 635 x 19)
16
x
25
x
3/4
(406 x 635 x 19)
Washable*
21 (533)
16
x
25
x
3/4
(406 x 635 x 19)
20
x
25
x
3/4
(508 x 635 x 19)
Washable*
2 4 --- 1
/
2 (622)
16
x
25
x
3/4
(406 x 635 x 19)
24
x
25
x
3/4
(610 x 635 x 19)
Washable*
* Recommended to maintain air filter face velocity. See Specification for part number.
{ Not all families have these models.
Air Filter Located in Filter Cabinet
FILTER CABINET HEIGHT --- IN (MM) F I LT E R S I Z E --- I N ( M M ) FILTER TY PE
16 (406)
(1) 16
x
25
x
3/4*
(406 x 635 x 19) or
(1) 16 x 25 x 4---5/16
(406 x 635 x 110)
Washable or Media*
20 (508)
(1) 20
x
25
x
3/4*
(508 x 635 x 19) or
(1) 20 x 25 x 4---5/16
(508 x 635 x 110)
Washable or Media*
24 (610)
(1) 24
x
25
x
3/4*or
(610 x 635 x 19) or
(1) 24 x 25 x 4---5/16
(610 x 635 x 110)
Washable or Media*
* Filters with a side return---air may have a different filter size. Measure the filter to obtain the correct size.
* Recommended to maintain air filter face velocity. See Specification for part number.
