ICP DLF4AH09J1A - Product Specifications - Indoor Unit

SERVICE MANUAL R−410A Ductless Split System: DLF4(A/H), DLC4(A/H)
2 421 01 9204 00
PRODUCT SPECIFICATIONS
Model − Indoor Unit DLF4AH09J1A DLF4HH09J1A
Function Cooling Cooling Heating
Rated Voltage 115V 115V
Frequency
(Inverter different
Compressor speed)
High Hz 70 70 63
Standard Hz 41 41 44
Low Hz 15 15 15
Total Capacity
(Inverter different
Compressor speed)
High W/Btuh 3100 / 10600 3100 / 10600 3250 / 11100
Standard W/Btuh 2650 / 9000 2650 / 9000 2820 / 9500
Low W/Btuh 1300 / 4435 1300 / 4435 930 / 3200
Power Input
(Inverter different
Compressor speed)
High W 1050 1050 1100
Standard W 634 634 700
Low W 180 180 220
Rated Input
High W 1050 1050 1100
Standard W 634 634 700
Rated Current
High A 16.8 16.8 17.0
Standard A 7.0 7.0 7.5
Air Volume
CFM 370 370
Dehumidifying Volume I/h 0.8 0.8
EER / C.O.P 14.2 14.2
SEER / HSPF 22 22 / 9.8
Indoor Unit DLF4AH09J1A DLF4HH09J1A
Fan Motor
Speed
SH r/min 1260 1260 1320
H r/min 1050 1050 1200
M r/min 920 920 1100
L r/min 730 730 950
Output W 20 20
Capacitor mF 4.0 4.0
RLA A 0.38 0.38
Fan
Type Cross Flow Fan Cross Flow Fan
Diameter−Length Inch f3.6x25.4 f3.6x25.4
Evaporator
Aluminum Fin Copper Tube Aluminum Fin Copper Tube
Pipe Diameter Inch f0.3 f0.3
Row−Fin Gap Inch 2−0.06 2−0.06
Coil length (I) x height
(H) x coil width (L)
Inch 25.4 x 10.5 x 1 25.4 x 10.5 x 1
Swing Motor
Model MP24AA MP24AA
Output W 2.4 2.4
Fuse A 3.15 3.15
Sound Pressure Level
H dB (A) 34 34
M dB (A) 30 30
L dB (A) 26 26
Sound Pressure Level
H dB (A) 44 44
M dB (A) 40 40
L dB (A) 36 36
Dimension (WxHxD) Inch 33 x 11 x 7 33 x 11 x 7
Dimension of Package (WxHxD) Inch 36 x 14 x 10 36 x 14 x 10
Net Weight / Gross Weight Inch 29 / 38 29 / 38
