ICP OCF105A12C User Manual

22
TABLE 5
Air delivery - CFM with air filter
Model :
RATING AND PERFORMANCE
Firing rate (USGPH) 0.50 0.63 0.75 0.72
Input (BTU/h) 70 000 88 200 105 000 100 800
Heating capacity, chimney installation (BTU/h) 58 000 72 500 85 200
Heating capacity, side-w all installation (BTU/h) 58 200 72 600 85 700 83 000
Minimum - maximum temperature rise
Flue draft, (Chimney), (Side-w all)
Overfire pressure (chimney), (Side-w all)
BECKETT BURNER, CHIMNEY INSTALLATION
Burner tube insertion lenght (inches)
Low firing rate baffle Yes Yes No
Static disc, model 2 3/4 #3383 2 3/4 #3383 2 3/4 #3383
Nozzle (Delavan) 0.50 - 70A 0.50 - 70A 0.60 - 70B
Pump pressure (PSIG) 100 156 156
Combustion air adjustment ( band/shutter ) 0 / 4.5 0 / 8 0 / 7.5
AFUE % (From CSA B212 standard and Canadian regulation) 81.5 81.0 80.3
AFUE % (From ASHRAE 103 standard and US regulation) 81.5 81.0 80.3
RIELLO BURNER, CHIM NEY INSTALLATION
Burner tube insertion lenght (inches)
Nozzle (Delavan) 0.40 - 60A 0.50 - 60A 0.60 - 60A
Pump pressure (PSIG) 156 156 156
Combustion air adjustment (turbulator / damper) 0 / 2 0 / 3 0 / 4
AFUE % (From CSA B212 standard and Canadian regulation) 83.6 83.1 81.6
AFUE % (From ASHRAE 103 standard and US regulation) 81.5 81.0 80.3
BECKETT BURNER, SIDE-WALL INSTALLATION
Burner tube insertion lenght (inches)
Nozzle (Delavan) 0.50 - 60W 0.50 - 60W 0.60 - 60W
Pump pressure (PSIG) 130 140 160
Combustion air adjustment (screw / dial) or (dial only) 3 / 1.5 3 / 3 3 / 4.5
AFUE % (From CSA B212 standard and Canadian regulation) 81.5 81.0 80.3
AFUE % (From ASHRAE 103 standard and US regulation) 81.5 81.0 80.3
RIELLO BURNER, SIDE-WALL INSTALLATION
Burner tube insertion lenght (inches)
Nozzle (Delavan) 0.50 - 60W 0.50 - 60W 0.60 - 60W
Pump pressure (PSIG) 135 140 155
Combustion air adjustment (turbulator / damper) 0 / 3 0 / 6 0 / 7.5
AFUE % (From CSA B212 standard and Canadian regulation) 83.6 83.1 81.6
AFUE % (From ASHRAE 103 standard and US regulation) 81.5 81.0 80.3
ELECTRICAL SYSTEM
Volts - Hertz - Phase
Operating voltage range (Volts)
Electrical load (Amps)
Minimum ampacity for w iring sizing
Max. fuse size (Amps)
Control transformer
Ext. control pow er available, cooling and accessories
BLOWER DATA
Blow er speed at 0.50" W.C. static pressure MED-LO MED-HI HIGH HIGH
Blow er speed at 0.25" W.C. static pressure MED-LO MED-HI HIGH HIGH
Maximum cooling, speed LOW MED-LO MED-HI HIGH
Maximum cooling, tons @ 0.50" W.C. 1.5 2 2.5 3
Motor (HP) / number of speeds
Blow er w heel size (in.)
Filter quantity and size (in.)
OCF105A12C
11 - 24°C (52 - 75°F)
(-0.035" to -0.06") (+0.04" to +0.16")
(0.00" to +0.035") (+0.10" to +0.25")
AFG with F0 head
5 1/8''
40-F3
5 3/16''
AFII-85
4 15/16''
40-BF3 with AL1009 post purge control
5 3/16''
115 - 60 - 1
104 - 132
12.2
13.7
10 X 10
(1) 20 X 20
15
40 VA
30 VA
1/3 HP / 4 speeds
0.1" 0.2" 0.3" 0.4" 0.5" 0.6" 0.7"
LOW
720 700 680 660 640 620 600
MED-LO
818 806 794 782 770 758 746
MED-HI
1114 1078 1042 1006 970 934 898
HIGH
1434 1378 1322 1266 1210 1154 1098
SPEED
ODH53F100LB-3MC, OCF105A12C
EXTERNAL STATIC PRESSURE WITH AIR FILTER
TABLE 4
Technical specifications
445 01 4024 05
