SpeedHook
®
OPERATOR’S MANUAL
6
TECHNICAL SPECIFICATIONS
SpeedHook
®
Length 42 in (105 cm)
Width 3.5 in (8.9 cm)
Weight of Rail 18 lbs (8 kg)
Distance from cut line to of
anchors, A
3.25 in (83 mm)
Distance from cut line to
outside rail, B
1.5 in (38 mm)
C
L
C
L
C
L
3.25 in (83 mm)
1.5 in (38 mm)
Cut Line
Tools Required:
823H / 853PRO / 880F4 / 890 Series Hydraulic Saws
1. Scrench
701-A Series Pneumatic Saw
1. Scrench
813M & 814PRO Hydraulic Saws
1. 3/16" Allen wrench
2. Pliers
