© 2012 ICS, Blount International Inc. Specications are subject to change without notice. REV1112 F/N 70569
TITLESpeedHook
®
OPERATOR’S MANUAL
7
SET- UP
STEP 1
Remove WallWalker
®
and spring
823H / 853PRO / 880F4 HYDRAULIC MOUNTING BRACKET INSTALLATION
STEP 3
Mount SpeedHook
®
mounting bracket
over bar mount studs
STEP 6
Complete assembly
STEP 4
Tension bar and chain as described
in the 823H / 853PRO / 880F4
operator's manual
STEP 2
Remove side cover (retain side cover
for future use without SpeedHook
®
)
STEP 5
Insert axle into mounting backet as
shown and firmly tighten knob
