ICT Pro Series User Manual

4 Innovative Circuit Technology Ltd.
INTRODUCTION
Pro Series power supplies from ICT provide a reliable 690 or 1200 Watts of rack-
mountable dc power with optional built-in battery back-up support and a low
voltage disconnect (LVD, option “B”) to power 12, 24, or 48Vdc based systems.
With an efficient wide range power factor corrected input the units are useable
world-wide, and their built in rack mounting ears and bus-bar outputs make
installation simple.
• Wide range Power Factor corrected AC input supports operation world
wide
• Dedicated independently controlled backup battery port with LVD relay
(units with LVD option “B”)
• Selectable charge rates to accommodate lower capacity batteries (units
with LVD option “B”)
• Remote on/off control input for external control of the output
• Floating Form-C alarm contact output supports remote monitoring of unit
operation
Model
1
Output
Voltage (V)
Max Output
Current (A)
Continuous
Current (A)
ICT690-12S(B)
13.8
50
50
ICT690-24S(B)
27.6
25
25
ICT690-48S(B)
55.2
12.5
12.5
ICT1190-12S(B)
13.8
100
87
ICT1190-24S(B)
27.6
50
44
ICT1190-48S(B)
55.2
25
22
CHECK and CONFIGURE UNIT
Perform a quick physical check of the unit as it is being taken out of the box to
ensure it has not been damaged during shipping. Check for the included parts and
accessories shipped with your unit:
• 5 pin Form-C alarm/remote connector plug (installed on unit)
• Power cord (North America 120V 15A)
• 2 (3 for “B” units) ¼-20 Hex bolt, washer, nut sets for bus bar connections
• Output connector shield (installed over output bus bars)
• Instruction Manual
1
Model suffix “B” denotes units equipped with the optional LVD Battery port

ICT Pro Series Specifications
