iDataLink Maestro HRN-RR-HK2 User Manual

ADS-RR(SR)-HK2-DS-IG-EN maestro.idatalink.com
Kia soul all witH aMP 2012-2013
Automotive Data Solutions Inc. © 2021
5
RADIO WIRE REFERENCE CHART
Wire
Description
Polarity
Wire Color on Maestro
T-Harness
Wire Color on Alpine
cable
Wire Color on Kenwood
cable
Wire Color on Pioneer
cable
Wire Color on Sony
cable
Illumination (+) Orange N/A Orange/White Orange/White Orange
Reverse Light (+) Purple/White Orange/White Purple/White Purple/White Purple/White
E-Brake (-) Lt Green Yellow/Blue Lt Green Lt Green Lt Green
Foot Brake (+) Yellow/Black Yellow/Black N/A Pink N/A
VSS (vehicle speed sensor) (DATA) Pink Green/White Pink Pink N/A
Power Antenna (+) Blue Blue Blue N/A Blue
