Mexico Super CF 3/100, 3/125, 3/140 - Installation
Boiler Size CF 3/100 CF 3/125 CF 3/140
Boiler MINIMUM kW (Btu/h) 29.5 (100800) 37.5 (127900) 46.1 (157400)
Input Gas Consumption l/s (ft.
3
/h) 0.76 (96.9) 0.97 (123) 1.19 (151)
MID kW (Btu/h) 33.3 (113500) 41.9 (142900) 48.8 (166400)
Gas Consumption l/s (ft.
3
/h) 0.86 (109) 1.08 (138) 1.26 (160)
MAXIMUM kW (Btu/h) 37.0 (126300) 46.1 (157400) 51.9 (177200)
Gas Consumption l/s (ft.
3
/h) 0.96 (121) 1.19 (151) 1.34 (170)
Boiler MINIMUM kW (Btu/h) 23.4 (80000) 29.3 (100000) 36.6 (125000)
Output MID kW (Btu/h) 26.4 (90000) 33.0 (112500) 38.8 (132500)
to Water MAXIMUM kW (Btu/h) 29.3 (100000) 36.6 (12500) 41.0 (140000)
Burner MINIMUM mbar (in w.g.) 8.5 (3.4) 10.2 (4.1) 11.6 (4.6)
Setting MID mbar (in w.g.) 10.6 (4.2) 12.6 (5.0) 13.1 (5.2)
Pressure
(hot) MAXIMUM mbar (in w.g.) 13.3 (5.3) 15.1 (6.0) 14.6 (5.8)
Flue Gas Flow Rate g/s 17.4 21.7 24.4
Flue Gas Temperature
o
C 125 139 128
Seasonal Efficiency (SEDBUK)* % 71.7 71.4 73.0
Boiler Size CF 3/100 CF 3/125 CF 3/140
Gas Supply Connection in. BSP Rc 1/2 (1/2) Rc 3/4 (3/4)
Flue Connection mm (in.) 125 (5) 150 (6) 150 (6)
Number of Boiler Sections 4 5 6
Flow and Return Connections Rc 1 (1" BSP)
Maximum Static Water Head m (ft.) 30.5 (100) (3 bar)
Minimum Static Water Head m (ft.) 1.0 (3.3)
Gas Supply Pressure 20 mb
Gas Type Natural 2 H
Electrical Supply 230 V ~ 50 Hz
External Fuse Rating (Power Consumption) 3 A (5 W)
Water Content litre (gal.) 9.8 (2.1) 12.2 (2.7) 14.6 (3.2)
Dry Weight kg. (lb.) 111 (245) 134 (295) 157 (346)
Boiler Size Height mm (in.) 850 (33.5)
Width mm (in.) 440 (17.4)
Depth mm (in.) 533 (21.0) 600 (23.6) 750 (29.5)
GENERAL
Table 1 - General Data
Table 2 - Performance Data
Key to symbols
GB = United Kingdom IE = Ireland (Countries of destination)
PMS = Maximum operating pressure of water
B
11BS
= An appliance designed for connection to a flue discharging the products
of combustion outside the room, with air for combustion being drawn
directly from the room where the appliance is installed, without a fan
in the combustion products circuit and fitted with a combustion products
discharge safety device.
I
2H
= An appliance designed for use on 2nd Family gas, Group H only.
Note.
Gas consumption is calculated using a calorific value
of 38.7 MJ/m
3
(1038 Btu/ft
3
) gross or 34.9 MJ/m
3
(935
Btu/ft
3
) nett
To obtain the gas consumption at a different calorific
value:-
a. For l/s - divide the gross heat input (kW) by the
gross C.V. of the gas (MJ/m
3
).
b. For ft
3
/h - divide the gross heat input (Btu/h) by the
gross C.V. of the gas (Btu/ft
3
).
*The value is used in the UK government's Standard Assessment Procedure (SAP) for energy rating of dwellings.
The test data from which it has been calculated have been certified by BGplc 0087
