- 25 -
A
0.20 inch
5 mm
C
B
B
C
1.
2.
Take the exchange blade carefully out of the
blade box and screw it to the blade changing
tool (A)
• make sure there is a space ot 5 mm
or 0.20 inches (B).
• blade must be covered (C).
Danger! Risk of injury!
Place the blade to be exchanged with the
blade changing tool mounted (1.), into the
blade carrier and push it up to the top and
screw it into place with the grips (2.).
•
Blade and cutting stick replacement
•
