IDEAL 3915-95

- 15 -
B
A
C
Operating elements
A
- Front safety guard
B
- Safety two-handed control system
C
- Overload switch
D
- Clamping
E
- Main switch
F
- Backgauge crank
G
- Key switch
H
- Backgauge
I
- Side lay left
Position the main switch to "I" (A). Insert the
key for the control system and move it to the
right (B). Open the safety guard (C). The
machine is now ready for use.
•
Operation
•
