IDEAL 5255 - Blade and Cutting Stick Replacement (Continuing); Installing the New Blade

- 40 -
IDEAL 4855 • IDEAL 5255 • IDEAL 6655
4.
2.
B
A
1.
A
2.
1.
3.
•
Blade and cutting stick replacement
• •
Position the main switch to "0" (1.)
Remove the 2 blade screws on the
elongated holes (2.). Then put the blade
changing tool (A) into place and fasten
it to the blade (3.).
Remove 2 blade screws (1.)
IDEAL 4855 and 3 blade screws (1.)
IDEAL 5255, IDEAL 6655.
Loosen the grips (2.) of the blade changing
tool (A) lightly and allow the blade to be taken
downwards out of the machine (3.). Place the
blade into the blade carrier (B) and screw it
into place (4).
27.
4.
2.
B
A
1.
      
IDEAL 485
5
   
(1.) IDEAL 525
5, IDEAL 6655
(A)   
(2.)   
.(3.)    
(B)      
.(4. )    
