IDEAL 61-744

Accuracy
Function
Range and Overload
Resolution
61-744 61-746
Protection
AC Current*
40.00A//400.0A/600A (50Hz - 60Hz) 1.7% + 6 digits 1.7% + 10 digits
600AAC
40.00A/400.0A/600A (60Hz - 400Hz) 3.0% + 6 digits 3.0% + 10 digits
AC Voltage
400.0V (50Hz - 500Hz) 1.2% + 5 digits 1.2% + 8 digits
600 VDC or AC rms
600V (50Hz - 500Hz) 1.5% + 5 digits 1.5% + 8 digits
DC Voltage 400.0V/600V 0.5% + 2 digits 600 VDC or AC rms
400.0Ω/4.000kΩ/40.00kΩ/
1.0% + 4 digits
400.0k Ω
Resistance
4.000MΩ 1.5% + 4 digits
600 VDC or AC rms
40.00MΩ 3.0% + 5 digits
Continuity
Audible indication < 25Ω
N/A 600 VDC or AC rms
Response time: 500ms
* Accuracy stated for crest factor ≤ 3
Input Impedance is 10MΩ.
Temperature Coefficient: 0.1 times the applicable accuracy specification per
degree C from 0°C to 18°C and 28°C to 50°C (32°F to 64°F and 82°F to 122°F)
Page 11
