Características
1. Sujeción con mordazas
2. Palanca
3. Selector de funciones
4. Pantalla de cristal líquido (LCD)
5. Terminal de entrada para voltaje y
resistencia (V-Ω)
6. Terminal de entrada común (COM)
7. Voltaje sin contacto (Non-Contact
Voltage - NCV)
8. Gama ( )
9. Retención de datos
10. Funciones de medida
11. Barrera táctil
Íconos de la pantalla
1. Pantalla de 4000 cuentas
2. Unidades de medida
3. volts
4. amperes
5. ohms
6. Continuidad
7. Está seleccionada la medida de CA
8. Está seleccionada la medida de CC
9. Indicador de polaridad para CC
10. Indicador de batería descargada:
11. Gama ( )
12. Retención de datos
13. Apagado automático (Auto Power
Off – APO)
Símbolos de la unidad
Advertencia: lea el manual de
instrucciones
NCV (Non-Contact Voltage): Voltaje sin
contacto
Cat III: Categoría de seguridad 600 V
