Page 11
Ranges & Accuracies:
AC Converter: 61-764 model is averaging sensing, rms calibrated
61-766, 61-768 models are true rms sensing.
Accuracy: Accuracy is specified as +/-(a percentage of the reading + a fixed amount) at
23°C±5°C (73.4°F ± 9°F), less than 75% relative humidity.
Temperature Coefficient: 0.1 times the applicable accuracy specification per degree C
from 0°C to 18°C and 28°C to 50°C (32°F to 64°F and 82°F to 122°F)
*Accuracy stated for crest factor ≤ 3 at full scale and ≤ 6 at half scale
**Frequency can be measured through clamp head or with use of test leads.
Input impedance: 400mV: >50MΩ; 4V: 10MΩ; 40V~ 750V: 9.1MΩ
Accuracy
Function
Range and Overload
Resolution
61-764 61-766 61-768
Protection
40.00A
(50-60Hz) N/A 1.7% + 10 N/A
40.00A (60-400Hz) N/A 3.0% + 10 N/A
AC Current*
400.0/600A (50-60Hz) 1.7% + 6 1.7% + 10
600 AAC
400.0/600A (60-400Hz) 3.0% + 6 3.0% + 10
DC Current
400.0/600A
(0~400A) N/A N/A 1.5% + 5
600 ADC
400.0/600A (400~600A) N/A N/A 2.0% + 5
400.0m (50-60Hz) 1.2% + 5 1.2% + 8
1000VDC or
AC Voltage 4.000/40.00/400.0V (50-500 Hz) 1.2% + 5 1.2% + 8
750V (
50-500Hz) 1.5% + 5 1.5% + 8
750VAC rms
DC Voltage 400.0m/4.000/40.00/400.0/1000V 0.5% + 2 1000VDC or 750 VAC rms
400.0/4.000k/40.00k/400.0kΩ 1.0% + 4
Resistance 4.000MΩ 5.0% + 4 9.0% + 4 600 VDC or AC rms
40.00MΩ (specified to 10MΩ) 12.0% + 5 20.0% + 5
4.000µF N/A 3.0% + 10 N/A
Capacitance 40.00µ/400.0µ F N/A 3.0% + 5 N/A 600 VDC or AC rms
4.000mF N/A 5.0% + 20 N/A
0.020k to 0.400k Hz
600 AAC or
Frequency** Sensitivity is 20-100Hz ( ≥ 5A) N/A 0.1% + 3 N/A
100-400 Hz (≥ 10A)
600 VDC or AC rms
Audible indication < 35Ω •••
Continuity
Response time: 500ms • • •
600 VDC or AC rms
