Page 10
Specifications:
Displays: 3-3/4 digit LCD with 4000 counts for both displays
Backlight: Green illumination with auto-off after 4.5 minutes
Analog Bargraph: 41 segment LCD with measurements of 20 times per second
Polarity: Automatic, positive implied, negative (-) polarity indication.
Overrange: "OL" indication is displayed.
Zero: Automatic
Measure Rate: Samples 2 times per second, nominal.
Auto Power Off: Approximately after 30 minutes of non-use.
Battery Life: 400 hours continuous with Alkaline (61-764)
200 hours continuous with Alkaline (61-766)
150 hours continuous with Alkaline (61-768)
Low Battery Indication: The " " is displayed when battery voltage drops below
operating level.
Power Supply: (1) 9V battery (NEDA 1604, JIS 006P, IEC 6F22)
Includes an isolated battery compartment.
Accuracy: Stated accuracy at 23°C ±5°C, <75% R.H.
Temperature 0.1 x (specified accuracy) per °C,
Coefficient: (0°C to 18°C, 28°C to 50°C).
Altitude: 6561.7 ft. (2000m)
Operating Environment: 32°F to 122°F (0°C to 50°C) at < 70% R.H.
Storage Environment: -4°F to 140°F (-20°C to 60°C) at < 80% R.H. with battery
removed from meter
Jaw Opening: Accepts a 1.42" (36mm) conductor
Dimensions: 8.7”H x 3.1”W x 1.8”D (222mmH x 80mmW x 45.5mmD)
Weight: 12.3 oz (350g) including battery
Accessories included: Carrying Case, Test Leads with alligator clip, (1) 9V
battery, operating instructions.
Safety: Complies with EN 61010-1, EN 61010-2-032, UL 61010-1,
IEC 61010-2-032, IEC61010-031 specifications,
Cat IV-600V/Cat III-1000V.
Double Insulation
Instrument has been evaluated and complies with insulation category II (overvoltage category II).
Pollution degree 2 in accordance with IEC-644. Indoor use.
