6 7
TOP TIP:
Once assembled, check
each step again to ensure all
fastenings are safe and secure.
Slide head rest 14 onto the top of the back
rest 6, by pulling out the spring loaded clip
and releasing when in desired position.
Slide Hand cycle 3 over Hand cycle support
frame 4 and keep in required position using
Large Dial 13
Slide foam back rest 7 onto Seat / Main
frame 6. Secure into position using EVA
Foam Back rest Clips 8.
Slide resistance bands 15 over the front
stabilising feet.
ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS
7.
8.
9.
7.
