icos - Users
Introduction
The icos is a wall mounted, room sealed, super efficient
condensing boiler featuring full sequence automatic spark
ignition and fan assisted combustion.
Due to the very high efficiency, condensate is produced from
the flue gases and this is drained to a suitable disposal point
through the plastic waste pipe at the right lower rear of the
boiler. A condensate 'plume' will also often be visible at the
flue terminal.
Safety
Current Gas Safety (Installation & Use)
Regulations or rules in force.
In your own interest, and that of safety, it is the law that this
boiler must be installed by a CORGI registered installer.
In IE the installation must be carried out by a competent
person and installed in accordance with the current edition of
I.S. 813 “domestic Gas Installations”, the current Building
Regulations and reference should be made to the current
ETCI rules for electrical installation.
It is essential that the instructions in this booklet are strictly
followed, for safe and economical operation of the boiler.
Electricity Supply
The appliance must be earthed.
Supply 230 V - 50 Hz. The fusing should be 3A.
This appliance is intended to be connected to the supply via a
double-pole switch, having a 3mm contact separation in both
poles, serving only the boiler and system controls. Alternatively,
a 3-pin UNSWITCHED socket may be used.
Important Notes
• This appliance must not be operated without
the casing correctly fitted and forming an adequate seal.
• If the boiler is installed in a compartment then the compartment
MUST NOT be used for storage purposes.
• If the boiler is installed with a loft air grille and roof flue, the loft
must not be used as a living space and care must be taken to
ensure that the loft air grille is not blocked.
• If the appliance is fitted with a twin flue system using a loft air
grille and both the boiler and grille are installed within a
cupboard or compartment, then permanent air vents are
required and care must be taken to ensure that the air vents
are not blocked.
• Under NO circumstances should any of the sealed components
on this appliance be used incorrectly or tampered with.
• If it is known or suspected that a fault exists on the boiler
then it MUST NOT BE USED until the fault has been
corrected by a CORGI registered installer or in IE a
competent person.
Destination Countries: GB, IE
icos HE30, HE36
(Natural Gas Only)
HE30 G.C. Appliance No. 41-399-10
HE36 G.C. Appliance No. 41-399-16
• This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.
• Children should be supervised to ensure that they do not
play with the appliance.
In cases of repeated or continuous shutdown a CORGI
registered installer or in IE a competent person should be called
to investigate and rectify the condition causing this and carry out
an operational test after each intervention on the device. Only the
manufacturers original parts should be used for replacement.
Minimum Clearances
Clearances of 165mm (6 1/2") above, 150mm (6") below,
15mm (5/8") at the sides and 450mm (17 3/4") at the front of the
boiler casing must be allowed for servicing.
The minimum front and bottom clearance allowed when built
into a cupboard is 5mm.
To light the boiler (Refer to Frame 1)
1. CHECK THAT THE ELECTRICITY SUPPLY TO THE BOILER
IS OFF.
2. Set the mains on/off switch (A) to off and the CH thermostat
knob (C) to maximum.
3. Switch on the electricity supply to the boiler and check that all
external controls, e.g. programmer, room thermostat, etc are
on.
4. Set the mains on/off switch to ON.
The boiler will commence the ignition sequence, supplying heat
to the system when required.
Operation
In normal operation the control unit display (F) will show the
codes:
O - Standby (no demand for heat)
C - CH or DHW being supplied
P - Boiler frost protection (boiler will fire when temperature is
less than 3
o
C)
During ignition the LED (E) will flash.
During normal running the LED will remain illuminated.
Note. If the boiler fails to light after 3 attempts the fault code 'L' 'F'
will be displayed.
Press and hold the reset button for 2 seconds then release.
The boiler will repeat the ignition sequence. If the boiler fails to
light consult a CORGI registered installer or in IE a competent
person.
All CORGI registered installers carry a CORGI ID card, and have a registration number. Both should be recorded
in the Benchmark Commissioning Checklist. You can check your installer by calling CORGI direct on 01256 372300.
THE BENCHMARK SERVICE INTERVAL RECORD MUST BE COMPLETED AFTER EACH SERVICE
Ideal Stelrad Group is a member of the Benchmark initiative and fully supports the aims of
the programme. Benchmark has been introduced to improve the standards of installation and
commissioning of central heating systems in the UK and to encourage the regular servicing of
all central heating systems to ensure safety and efficiency.
