IDEAL imax W80P

16
- Installation & Servicing
INSTALLATION
18 FLUE KIT ACCESSORIES
RF 5757
1
2
5
3
4
6
7
8
9
10
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
90º elbow (concentric)
45º elbow (concentric)
90º elbow
45º elbow (pair)
Flat Weather Collar
Pitched Weather Collar
1m Extension (concentric)
1m Extension (pair)
Twin pipe adapter 80/80
Increaser 80-100
152616
152618
n/a
n/a
152611
152609
152400
n/a
n/a
n/a
152617
152619
n/a
n/a
152612
152610
152401
n/a
n/a
n/a
Accessory
80/125 100/150
Part No.
n/a
n/a
158773
158775
158780
158779
n/a
158771
158686
152404
80
n/a
n/a
158774
158776
158780
158779
n/a
158772
n/a
n/a
100
FLUE OUTLET
